AVB MP-512C User Manual

Avb mp-512c: user guide
Hide thumbs

Advertisement

Quick Links

Download this manual
This product represents a new generation of MP3 players supporting MP1, MP2, MP3, WMA,
WMV, ASF, and WAV.
FEATURES SUMMARY
● Compact size
● Support virtually all music file formats such as: MP1, MP2, MP3, WMA, WMV, ASF, and
WAV.
● Supports firmware update the latest firmware can always be downloaded from the AVB
website (www.avbusa.com).
● Supports FM radio Using Auto-search or manual search, the player can save up to 40
different radio stations. The frequency varies from 87 KHz to 108 KHz.
● No need to have any driver for Windows 2000 or above. The MP3 player can be used as a
removable USB disk
● Disk encrypt and Disk partition using the enclosed software tools it is possible to encrypt
and partition the disk space as you like.
● Record/Repeat With built-in voice recorder the recorded files can be saved in WAV or ACT
file formats. It is possible to mark a recorded segment for subsequent compare or repeat;
useful feature for the language self-study.
● Equalizer settings include Natural, Rock, Pop, Classic, Soft, Jazz, DBB
● 7-color backlight display.
● Music repeat modes include Normal, Folder, Repeat one, Repeat folder, Repeat all,
Random, and Introduction.
●Timing off Automatic off by time and sleep time can be set.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MP-512C and is the answer not in the manual?

Questions and answers

Summary of Contents for AVB MP-512C

  • Page 1 ● Support virtually all music file formats such as: MP1, MP2, MP3, WMA, WMV, ASF, and WAV. ● Supports firmware update the latest firmware can always be downloaded from the AVB website (www.avbusa.com). ● Supports FM radio Using Auto-search or manual search, the player can save up to 40 different radio stations.
  • Page 2 Due to the constant production improvement, the MP3 Player you have purchased might be slightly different then the one described in this manual. We recommend you to visit the www.avbusa.com Know about AVB MP3 Housing Earphone hole •...

  • Page 3: Main Functions

    Buttons usage definition The buttons can be used in 3 different ways: Press: Press the button then release it immediately. Long time press: Press and hold the button for about 2 seconds, then release it. Press and hold: Press and keep holding the button. •...
  • Page 4 o Record mode screen: o Recording playback mode screen: o FM mode screen: o System settings screen: o Connection with PC screen: • Volume adjustment Press “VOL+” to increase the volume. Press “VOL–” to decrease the volume. • Power ON/OFF Press and hold “Play/Pause”...
  • Page 5 While the MP3 is playing, press and hold the “Play/Pause” to turn the MP3 player off. • Play/Pause In the Music mode press the “Play/Pause” button to playback the music. • Record/Pause In the Record mode press this button to start or stop recording, press the button for more than 2 seconds (long time press) to stop the recording.
  • Page 6 • Music playback Please, follow the steps below 1. Connect your earphone to the earphone jack of the MP3 player. 2. Press the “Play/Pause” button for 2 seconds (long time press) to turn your MP3 player on, enter the Music mode, then press “Play/Pause” again to playback the music.
  • Page 7 • Voice recording The MP3 player can save up to 99 recorded files in its memory. ο Recording 1. Enter the Main menu: 2. Press the ” button to select the record mode. 3. Press the “Mode” button to enter the record mode: 4.
  • Page 8 ο Select recording type 1. Enter the Record submenu pressing the “Mode” button 2. Press the “ ” button to select the record type, press “Mode” button to confirm the choice: ο The record type can be one of the following: : Fine Record, .WAV file format, the best quality sound but creates much bigger files.
  • Page 9 VOL+ : Increase volume － :Decrease volume • File recorded in .ACT format can be converted to .WAV Use the supplied utility software to convert the recorded .ACT file to the .WAV file. 1. Run the “Sound Converter” software utility. You will see the following dialog box: 2.
  • Page 10 3 .Click “Convert” to create .WAV file. You can also convert the .WAV file to MP3 format using the same utility.
  • Page 11 FM Radio To use the FM radio please, follow the steps below: 1. Enter the main menu 2. Press the button until you select “FM” 3. Press the “Mode” button to enter the “FM” menu. 4. Auto search for the Radio station Press the “...
  • Page 12 Press the “Play/Pause” button to select and listen to the saved radio station. 8. Volume Control Press Vol+ or Vol- to increase or decrease the volume. : You can save up to 20 radio stations in your MP3 player. : To delete the radio station please refer to the section Delete file below.

  • Page 13: System Settings

    • How to change the System settings 1. Enter the main menu 2. Press the button to select “SYS” 3. Press “Mode” button to enter the “SYS” system settings submenu. • The system settings are listed below (Record Time) (Back Light) (Back Light Mode) (Language) (Power off )
  • Page 14 • System settings explanation ○ Setting “Record Time” 1. The screen will look as shown below: 2. Press the “Mode” button to enter the submenu. The screen will look as shown below: 3. Press “VOL+” (VOL-)to select the date and time. 4.
  • Page 15 ○ Setting “Language”. Please, operate in a similar fashion as the “Back time” setting. ○ Setting “Power off“. The same as the “Back time”. There are two settings here: Off time: Set your auto-off time, the unit is in seconds Sleep time: Set your sleep mode time, the unit is in minutes, the max setting is 120 minutes.
  • Page 16 • Use MP3 player as a USB Disk This MP3 player can be used as a USB disk. There is no need to install any driver (with exception of Windows 98) under Windows 2000/XP, Mac OS 10.3 or above, Linux Reshat 8.0 or above.
  • Page 17 “firmware update”, then press the “Mode” button to enter the submenu. 5. Connect your MP3 player to PC. 6. Run“MP3 Player Update” utility It’s used in the interface of firmware upgrade. (Please check AVB web : www.avbusa.com for more information)
  • Page 18 8. Select the new firmware file 9. Click the “Begin Upgrading” button to update the player.
  • Page 19 If update is successful the mp3 player will display the following: Firmware update is to improve the mp3 player, however it is not necessary to do that, your MP3 player will work normally without any update. Firmware update used in a wrong way might damage your MP3 player! Before updating please, read the instruction carefully.

  • Page 20: Other Settings

    • Select different directory It is possible to use a different directory rather than the root directory for the recording or music playback. The MP3 player can support up to 9 directories which the MP3 can use to playback files in there. To do that please, follow the steps below 1.
  • Page 21 files and the Radio stations. To do that, follow the steps below: 1. The MP3 should be stopped.(In all modes excluding FM) 3. Press the “ “single file” or “all files”. 5. Press the button to change “NO” to “YES” The choice “Delete All”...
  • Page 22 If you prefer to delete the files from your PC when MP3 is connected to the USB port, make sure you use the Safely Remove Device wizard of Windows before you unplug the MP3 player from the USB port. Otherwise some data might get corrupted. •...
  • Page 23 During the music playback (only for the MP3 file), it is possible to choose different playback speed (speed up or slow down), the volume will not change. 1. During the music playback press the “Mode” button to enter the menu. 2.
  • Page 24 The MP3 will now start to repeat the playback from the point A to the point B. Having repeated the marked fragment for a number of times (this number can be set) the playback will stop. When the player is in the repeat mode it is possible to renew the setting of the points A and B. During the “repeat mode”, you can press the VOL+ or VOL- button to set the “playback speed”.
  • Page 25 1.After you enter the Compare Mode, the icon will display “ ”, then playback the original MP3 file. Press the During the “compare mode”, press “Mode” button to exit the “repeat mode”. ο The number of repeat times Please refer to the “backlight time” system setting. ο...
  • Page 26 3. The following window will be displayed: 4. You can select the size of the encrypted part of the disk, then press the “Start” button 5. Press “OK” and then restart your computer. 6. After computer finishes the reboot, you will see two removable disks on your computer (see the comments above about the operating systems before Windows 2000 SP4).
  • Page 27 8. Now whenever you connect your MP3 player to the computer, you won’t be able to use it until you enter the user name and the password. Note: If you want to encrypt the disk in the way described above, please, first backup your files, all the data will be lost after the encryption.

  • Page 28: Troubleshooting

    No power Check battery Check your power switch No music is heard in 1. Check the Volume level the earphones 2. Check the connection (earphone to the earphone jack) 3. Check if the music file can be played by the MP3 player.

  • Page 29: Specifications

    Outside Dimensions Weight Display area Computer interface Memory Battery lifetime Recording MP3,WMA,WMV,ASF FM Radio SPECIFICATIONS 31mm×70mm×17mm 25g (not including battery) Lattice (128×32) EL Backlight Full Speed USB 2.0 (Read 1000KB, Write 800KB) Flash memory: Nand Flash. Playback up to 10~14 hours. Rate 8KHz Record format...
  • Page 30 Music formats supported Temperature range Language support Operating system Web : www.avbusa.com Support : support@avbusa.com Signal to noise 45dB ratio MP1, MP2, MP3, WMA, WMV, ASF, WAV -5 ~ +40 Degree English, German, Chinese, … Windows98SE/ME/2000/XP,Mac OS 10, Linux 2.4.2...
