OPERATING INSTRUCTIONS
Dishwasher DFI643
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DFI643AU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Asko DFI643AU

  • Page 1 OPERATING INSTRUCTIONS Dishwasher DFI643...
  • Page 2: Table Of Contents

    Open the door and press the main power switch. "Welcome to your new ASKO. This is a first time set up." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results. See page 4.
  • Page 3: Safety Instructions

    Safety instructions Child safety NOTE! Children must be watched. Do not allow children Read the operating instructions and keep to use or play with the dishwasher. Be especially them in a safe place! vigilant when the door is open. Some detergent Number of place settings: 14 may remain inside! After adding detergent, al- Never use the dishwasher for any purpose...
  • Page 4: Before Washing For The First Time

    Open the door and press the main power switch. This is important with regard to how much detergent and rinse aid to "Welcome to your new ASKO. This is a first time set up." is shown use. on the display. It is important that you choose the right settings to en- sure good dishwashing results.
  • Page 5: Loading The Dishwasher

    Loading the dishwasher Greener dishwashing Fragile dishes Do not rinse under running water Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand strong heat, others can be damaged Simply scrape off large food particles before loading the dishwasher. by dishwashing detergent.
  • Page 6 Foldable tines The dishwasher's baskets Lower the foldable tines (plate supports) when washing pots and pans. The dishwasher is equipped with an upper basket and a lower basket Release the foldable tines by pressing the catch inwards before adjust- with a cutlery basket. ing their position.
  • Page 7 Cutlery basket with lid The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see below). Accessory Buy an extra cutlery basket. The extra cutlery basket is flexible and can be dismantled and attached to the lower basket or the large cutlery basket to make an extra large cutlery basket.
  • Page 8: Using The Dishwasher

    Using the dishwasher of the detergent to the prewash compartment. Contact the detergent Add detergent manufacturer if you have questions about the detergent. Press to open NOTE! Use only dishwasher detergent! Washing up liquid must not be used as the foam that forms prevents the dishwasher from operating effec- tively.
  • Page 9 Open the door and press the main power switch. Starting the dishwasher START STOP 2:00 Speed mode Select the program Select a program mode Select any options been used without dried-on leftovers can also be washed using this The main power switch program.
  • Page 10 Top up with rinse aid or increase the rinse aid dosage level. Select an Option Activate the Extra Dry option. To select an option, press the option button until the desired option is Activate the High temperature setting. See the chapter Settings. shown on the display.
  • Page 12: Settings

    Settings Open the dishwasher's Settings menu To open the dishwasher's Settings menu, press the Navigation button until Settings menu is shown on the display and confirm your selection using the mode selector To exit the dishwasher's Settings menu, select Exit and confirm your selection using the mode selector Navigation buttons for choosing setting Mode selector to confirm current setting START...
  • Page 13 Settings Options Rinse aid 0/1/2/3/4/5 Setting for rinse aid dosage. The rinse aid dispenser can be adjust- ed between 0 (Off) and 5 (High dosage). Increase the rinse aid dosage: If the dishes have water marks. Decrease the rinse aid dosage: If the dishes have a sticky white/blue film.
  • Page 14: Care And Cleaning

    Care and cleaning 4 Lock the filter in place by turning the handle clockwise to the stop position. The handle should point straight out from the dishwasher. Top up rinse aid When the rinse aid needs topping up, the above symbol lights on the NOTE! display.
  • Page 15 If the dishwasher still does not start and a whirring sound is heard, the overflow protection has been activated. Shut off the water. Remove the plug from the wall socket. Call the service department. The door and the door seal Drainage pump stop Regularly clean the sides of the door and the door seal.
  • Page 16: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling water 1 Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 17 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings blocked. Clean the spray arms. See Chapter Care and cleaning. Unsuitable dishwashing program.
  • Page 18 Problem Possible causes Action Water remains in the dishwasher. The filters are blocked. Clean the coarse and fine filters. The filters are not fitted correctly. Check that the filter handle is locked in the stop position. The handle should point towards the back of the dishwasher.
  • Page 19: Technical Information

    Technical information Information on energy labelling Energy labelling Australian standard: AS/NZS 2007 Number of place settings: Dishwashing programs: ECO wash , no options Program time: 2:35 hours:minutes Connection: Cold water 20 °C Test method for noise measurement: IEC 60704-2-3 This dishwashing program is the standard cleaning cycle used to compile the energy labelling information. It is intended for washing normally dirty dishes and is the most effective program in terms of combined energy and water consumption.
  • Page 20: Installation

    Installation [mm] 1198 30-94 *Remove locking nuts for an installed height of 820-821 mm. **Door length. Nominal dimensions. Actual measurements may vary. It is important that you read through and follow the instructions and Drainage connection directions below. Conduct installation and connection in accordance See the separate installation instructions for necessary information.
  • Page 21: Asko Service

    If you have encountered a problem that you cannot resolve, Once the installation is complete, turn on the water tap and allow the please contact your nearest dealer, see www.asko.com. pressure to settle for a while. Check that all connections are watertight.
  • Page 22: Information For Test Institute

    Information for test institute Request test institute information via e-mail dishwashers@appliance- development.com. The request should include the details on the product’s serial number plate. Include the article number (1) and the serial number (2). ART. NO.: SERIAL NO.:...
  • Page 23: Your Notes

    Your notes...
  • Page 24: Quick Guide

    Use rinse aid to achieve good washing and drying results. (See page 4.) Refill rinse aid indicator. Select a program, a program mode and any options (See page 9.) Press Start/Stop, close the door START STOP ASKO APPLIANCES SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
