Page 1: Lcd Monitor
SyncMaster P1980ER,P2480L LCD Monitor User Manual The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. -
Page 2: Table Of Contents
Power Saving Function ........6-2 Contact SAMSUNG WORLDWIDE ......6-3 Correct Disposal of This Product (Waste Electrical &... -
Page 3: Major Safety Precautions
The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written permission of Samsung Electronics, Co., Ltd. The SAMSUNG logo and SyncMaster are the registered trademarks of Samsung Electronics, Co., Ltd. Microsoft, Windows and Windows NT are the registered trademarks of Microsoft Corporation. -
Page 4: Custody And Maintenance
Custody and Maintenance External Surface and Screen Maintenance Clean the product with a soft dry cloth. • Do not clean the product with an inflammable substance such as benzene or thinner or with a wet cloth. This may result in a problem with the product. -
Page 5: Safety Precautions
Safety Precautions Icons used for safety precautions Icon Name Warning Caution Meaning of Signs Do not perform. Do not disassemble. Do not touch. Power Related The following images are for your reference and may differ depending on models and countries. Warning Avoid using a damaged power cord or plug or a loose power outlet. -
Page 6: Installation Related
Caution Avoid unplugging the power plug while the product is operating. • Otherwise, it may damage the product due to electric shock. When unplugging the power plug from the wall outlet, make sure to hold it by the plug and not by the cord. •... -
Page 7: Cleaning Related
Avoid installing the product in a location exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and installing it within a vehicle. • This may result in electric shock or fire. Avoid installing the product at an easily reachable height where children may reach •... -
Page 8: Usage Related
Before cleaning the product, unplug the power cord. • Otherwise, it may result in electric shock or fire. Caution Avoid spraying cleansing agent directly onto the product. • This may result in discoloration or cracking of the exterior of the product or the panel coming off. - Page 9 When thunder or lighting occurs, unplug the power cord and under no circumstance touch the antenna cable as this is danger- ous. • Otherwise, it may result in electric shock or fire. Avoid moving the product by pulling the power cord or antenna cable. •...
- Page 10 It is important to give your eyes some rest (5 minutes every hour) when viewing the product screen for long periods of time. • This will alleviate any eye strain. Keep small accessories away from the children. Avoid placing a heavy object over the product. •...
-
Page 11: Installing The Product
Installing the Product Package Contents • Unpack the product and check if all of the following contents have been included. • Store the packaging box in case you need to move the Product at a later stage. Installation Manual (Not available in all locations) D-Sub Cable DVI Cable The cleaning cloth is supplied with black high-glossy models only. -
Page 12: Installing The Stand
Installing the Stand Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards. Place a soft cloth over the table to protect the product and place the product onto the cloth so that the front of the product is facing downwards. - Page 13 After the installation of the base, stand the monitor up as shown in the figure. Now you can remove the stopper pin to adjust the stand. - Caution Avoid lifting the product holding only the stand. Disassembly is in the reverse order of the assembly. Installing the Product...
-
Page 14: Installing The Stand For The Wall Mount
Installing the Stand for the Wall Mount Before installation, disassemble the product according to the following steps. Lift up the monitor stand to the maximum angle with your left hand, and remove the back decoration cover with your right hand, as shown in the figure. Remove the screw on the point "A". - Page 15 1. Turn the product off and unplug the power cord from the wall outlet. 2. Place a soft cloth or cushion on a flat surface to protect the panel and place the product down on the cloth so that the front of the product faces downwards.
-
Page 16: Connecting With A Pc
Connecting with a PC The connecting part may differ depending on the product model. 1. Connect the product to a PC depending on the video output supported by the PC. • When the graphics card provides D-Sub (<analog>) output • Connect the [RGB IN] port of the product to the [D-Sub] port of the PC with the D-Sub cable. - Page 17 Switches the LCD Display On/Off. Supplied for the wide models only such as 16:9 or 16:10. When the product is connected to a PC, you can turn the product on and use it. When both the DVI (<digital>) and D-Sub (<analog>) cables are connected, you can select the input signal (Analog/Digital ) by pressing the [ ] button.
-
Page 18: Kensington Lock
Kensington Lock A Kensington Lock is an anti-theft device that enables users to lock the product so that they can safely use it in public locations. Since the shape and usage of the locking device may differ depending on the model and the manufacturer, for more information, refer to the User Manual supplied with the locking device for more information. -
Page 19: Using The Product
Using the product Setting the Optimal Resolution If you turn the power on after purchasing the product, a message regarding the optimal resolution setting appears on the screen. Select a language and the optimal resolution. • The message appears up to 3 times if the resolution has not been set to the optimal resolution. •... -
Page 20: Standard Signal Mode Table
PC is not one of the following signal modes, a blank screen may be displayed or only the Power LED may be turned on. Therefore, configure it as follows referring to the User Manual of the graphics card. P1980ER Horizontal... - Page 21 Horizontal Display Mode Frequency (kHz) IBM, 720 x 400 31.469 MAC, 640 x 480 35.000 MAC, 832 x 624 49.726 MAC, 1152 x 870 68.681 VESA, 640 x 480 31.469 VESA, 640 x 480 37.861 VESA, 640 x 480 37.500 VESA, 800 x 600 35.156 VESA, 800 x 600...
-
Page 22: Installing The Device Driver
If you install the device driver, you can set up the appropriate resolution and frequency for the product. The device driver is included on the CD-ROM supplied with the product. If the supplied drive file is corrupted, please visit a service center or Samsung Electronics website(http://www.samsung.com/), and download the driver. 1. Insert the driver installation CD-ROM into the CD-ROM drive. -
Page 23: Product Operating Buttons
Even if the OSD Adjustment Lock function is activated, users can adjust the brightness and contrast and can set up the adjustment function assigned to the [ ]. <MagicBright> - <MagicColor> - <Color Effect> (P1980ER) <MagicBright> - <MagicColor> - <Color Effect> - <Image Size> (P2480L) You can set the function of the Customized Key by selecting <SETUP&RESET>... - Page 24 Icon Press [AUTO] button to adjust the screen settings automatically AUTO If the resolution settings are changed in the Display Properties, the AUTO adjustment func- tion is performed. Press this button to turn the product on or off Power LED This LED is turned on when the product works normally.
-
Page 25: Using The Screen Adjustment Menu (Osd: On Screen Display)
Using the Screen Adjustment Menu (OSD: On Screen Display) The Screen Adjustment Menu (OSD: On Screen Display) Structure Top Menus Brightness PICTURE Fine MagicColor COLOR Color Effect H-Position SIZE & POSI- TION Reset SETUP&RESE Auto Source INFORMA- TION PICTURE Menu Controls the screen brightness. - Page 26 Menu Provides preset picture settings optimized for various user environments such as editing a document, surfing the Internet, playing games, watching sports or movies and so on. • <Custom> If the preset picture modes are not sufficient, users can configure the <brightness> and <Contrast>...
-
Page 27: Size & Position
Menu Expresses natural colors more clearly without changing the picture quality using proprietary digital picture quality improvement technology developed by Samsung Electronics. • <Off> - Turns the MagicColor function off. MagicColor • <Demo> - You can compare the pictures processed by MagicColor with the original pictures. - Page 28 Menu Moves the position of the display area on the screen horizontally. This function is only available in analog mode. H-Position When TV signal is input in AV mode ,select <Screen Fit >to adjust horizontal position in 0-6 levels. Moves the position of the display area on the screen vertically. V-Position This function is only available in analog mode.
- Page 29 <5 sec> - <10 sec> - <20 sec> - <200 sec> You can set the function of the Customized Key to one of the following. Customized Key • <MagicBright> - <MagicColor> - <Color Effect> (P1980ER) • <MagicBright> - <MagicColor> - <Color Effect> - <Image Size> (P2480L) INFORMATION...
-
Page 30: Installing The Software
What is Natural Color? This software works only for Samsung products and enables adjusting the displayed colors on the product and matches the colors on the product with the colors of the printed pictures. For more information, refer to the online help of the software (F1). -
Page 31: Magictune
MagicTune What is MagicTune? MagicTune is a software program that helps with monitor adjustments by providing comprehensive descriptions of monitor functions and easy-to-understand guidelines. Users can adjust the product with the mouse and the keyboard without using the operating buttons of the product. Installing the Software 1. - Page 32 3. In the [Add/Remove] window, find and select MagicTune™so that it is highlighted. 4. Click [Change or Remove Programs] to remove the software. 5. Select [Yes] to start removing MagicTune™. 6. Wait until a message box appears informing you that the software has been removed completely. For technical support, the FAQ (frequently asked questions) or information about the software upgrade for MagicTune™, please visit our website.
-
Page 33: Multiscreen
MultiScreen What is MultiScreen ? MultiScreen enables users to use the monitor by partitioning multiple sections. Installing the Software 1. Insert the installation CD into the CD-ROM drive. 2. Select the MultiScreen setup program. If the pop-up screen for the software installation does not appear on the main screen, find and double-click the MultiScreen setup file on the CD-ROM. -
Page 34: Magicrotation
MagicRotation What is MagicRotation? The MagicRotation Software from Samsung Electronics, Inc. provides the user with a rotation feature (0, 90, 180, 270 orientation) that facilitates the optimum utilization of computer display screen, better viewing and improved user productivity. Installing the Software 1. -
Page 35: Removing The Software
• Windows XP Professional • Windows Vista 32Bit • Windows 7 32Bit For MagicRotation, Windows 2000 or later is recommended. Hardware • At least 128MB of memory (recommended) • At least 32MB of free space on the hard disk drive Service Packs •... -
Page 36: Troubleshooting
Troubleshooting Monitor Self-Diagnosis • You can check if the product is working properly using the Self-Diagnosis function. • If a blank screen is displayed and the Power LED blinks even if the product and the PC are properly connected, perform the self-diagnosis function according to the procedures below. -
Page 37: Before Requesting Service
Before Requesting Service Please check the following before requesting After-Sales service. If the problem continues, please contact your nearest Samsung Electronics Service Center. A BLANK SCREEN APPEARS / I CANNOT TURN THE PRODUCT ON Is the power cord connected properly? Is the <Check Signal Cable>... - Page 38 THE COLOR IS DISPLAYED IN 16 BIT (16 COLORS). THE COLOR HAS BEEN CHANGED AFTER CHANGING THE Did you install the device driver for the product? Is the graphics card configured correctly? WHEN I CONNECT THE MONITOR, THE 'UNKNOWN MONITOR, PLUG&PLAY (VESA DDC) MONITOR FOUND' Did you install the device driver for the product? Check if all the Plug&Play (VESA DDC) functions are sup- ported referring to the User Manual of the graphics card.
-
Page 39: Faq
FAQ! How can I change the frequency (refresh rate) of the video signal? How can I change the resolution? How can I use the power saving function? Troubleshooting PLEASE TRY THE FOLLOWING! You have to change the frequency of the graphics card. Windows XP : Change the frequency by selecting Control →... -
Page 40: More Information
Class B (Information Communication equipment for residential use) This device is registered for EMC requirements for home use (Class B). It can be used in all areas. (Class B equipment emits less electromagnetic waves than Class A equipment.) P1980ER inches (48 cm) 376.32 mm (H) x 301.06 mm (V) -
Page 41: Power Saving Function
NORMAL OPERATION POWER SAVING MODE POWER OFF Power Indicator Blinking P1980ER : 21 W Power Consumption Less than 1 watts Less than 1 watts P2480L : 45 W If there is no power cut-off switch, the power consumption is "0" only when the power cord is disconnected. -
Page 42: Contact Samsung Worldwide
Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINA BRAZIL CHILE COLOMBIA COSTA RICA ECUADOR EL SALVADOR GUATEMALA HONDURAS JAMAICA NICARAGUA PANAMA PUERTO RICO REP. - Page 43 0,10/Min) 815-56 480 0 801 1SAMSUNG (172678) 022 - 607 - 93 - 33 80820 - SAMSUNG (726-7864) 0800-SAMSUNG(726-7864) 902 - 1 - SAMSUNG (902 172 678) 0771 726 7864 (SAMSUNG) 0848-SAMSUNG(7267864, CHF 0.08/ min) 0845 SAMSUNG (7267864) 0-800-05-555 088-55-55-555...
- Page 44 TURKEY U.A.E ASIA PACIFIC 3030 8282 1800 110011 1800 3000 8282 1800 266 8282 0800-112-8888 021-5699-7777 0120-327-527 1800-88-9999 0800 SAMSUNG (0800 726 786) 1-800-10-SAMSUNG(726-7864) 1-800-3-SAMSUNG(726-7864) 1-800-8-SAMSUNG(726-7864) 02-5805777 1800-SAMSUNG(726-7864) 0800-329-999 1800-29-3232 02-689-3232 1 800 588 889 MIDDLE EAST & AFRICA 8000-4726...
-
Page 45: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment) - Europe Only
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
