Valley Comfort Systems Blaze King PRINCESS PE1006 Operation & Installation Manual

Solid fuel catalytic stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRINCESS PE1006/PEJ1006
SOLID FUEL CATALYTIC STOVE
PE1006BK
PE1006LBK
PE1006UBK
This heater meets the 2015 U.S. Environmental Protection Agency's particulate emission limits for wood heaters sold after May 15, 2015.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please SAVE THESE INSTRUCTIONS for future reference.
The authority having jurisdiction (such a municipal building department, fi re department, etc.) should be
consulted before installation to determine the need to obtain a permit.
OPERATION & INSTALLATION MANUAL
Manufactured By
Valley Comfort Systems Inc., 1290 Commercial Way, Penticton, BC, V2A 3H5, Canada
Phone: 250-493-7444 w Fax: 250-493-5833 w www.blazeking.com w info@blazeking.com
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
180-PE1006 v1.11
October 3, 2018
