Summary of Contents for iSMA iSMA-D-PD10C-B1
- Page 1 User Manual Global Control 5 Sp. z o.o. Warsaw, Poland www.gc5.pl...
-
Page 2: Table Of Contents
Table of contents Introduction ................................. 3 Revision history .................................. 3 Safety rules ..................................4 EN 55032:2015 ................................... 5 EN 61000-3-2:2014 ................................5 EN 61000-3-3:2013 ................................5 EN 55024:2010 + A1:2015 ............................... 5 EN 60950-1:2006 + A11:2002 + A1:2010 + A12:2011 + A2:2013 ................5 Technical specifications .............................. -
Page 3: Introduction
1 Introduction Revision history Date Description 2015.08.28 First edition Table 1. Revision history version 1.1 www.gc5.pl Page 3 /11... -
Page 4: Safety Rules
Safety rules Note: Incorrect wiring of this product can damage it and lead to other hazards. • Make sure, the product has been correctly wired before turning the power ON. • Before wiring, or removing/mounting the product, be sure to turn the power OFF. -
Page 5: 55024:2010 + A1:2015
EN 55032:2015 Electromagnetic compatibility of multimedia equipment. Emission Requirements. EN 61000-3-2:2014 Electromagnetic compatibility (EMC). Limits for harmonic current emissions for equipment input current ≤ 16 A per phase). EN 61000-3-3:2013 Electromagnetic compatibility (EMC). Limits for voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current ≤... -
Page 6: Technical Specifications
Panel type HD industrial TFT LCD LED ; Backlight lifetime ≥50000h, Screen type Size 10.1’’ Aspect Ratio 16:9 Resolution For iSMA-B-MAC36NL 1280x720, for Panel 1366x768 Luminance 300nit, up to 800nit Contrast 800:1 Active Area 222.7x125.2 mm Display color 16.7M Point distance 0.264mm... -
Page 7: Dimensions
Table 2. Technical specifications Dimensions Figure 1. Dimensions 1.10 Interface Details The Monitor will recognize and select the signal automatically. Figure 2. DC power supply connection version 1.1 www.gc5.pl Page 7 /11... -
Page 8: Operation Guide
2 Operation Guide Rear navigation buttons The buttons are used to navigate in the user menu, turn the device on and off. Figure 3. Rear navigation buttons Symbol Name Using instruction Left Choose + Choosing different submenus, the function of this button is the... -
Page 9: Osd Options / Adjustment
OSD options / Adjustment OSD menu's basic functions: Screen display effect adjustment Automation. Brightness adjustment, Contrast ratio adjustment, Color adjustment...etc. If need to enter OSD Menu interface, can go into trial testing of below parameters by clicking main "MENU" options. -
Page 10: Installation
Figure 7. Information menu 3 Installation • Do not place the monitor next to the radiator or heat source. • Do not let any objects press or twine around the power cable or VGA cable. • Do not place the monitor near to water source or humid places. -
Page 11: Wall-Mount Installation
Wall-mount Installation Figure 2. Wall-mount Installation version 1.1 www.gc5.pl Page 11 /11...
