MFJ -5124Y3 Instruction Manual

MFJ-5124Y3 Radio Interface
Read Instructions Before Operating
The MFJ-5124Y3 interface cable provides proper control between a Yaesu MP-
series radio and the MFJ-991/993/994/991B/993B/994B IntelliTuner
Automatic Antenna Tuners.
MKV, MP MKV Field and any Yaesu radio compatible with the Yaesu FH-1
Remote Control Keypad.

Connections and Operation

1. Insert the mono end of the cable to the Yaesu radio's REMOTE jack.
2. Insert the stereo end of the cable to the tuner's RADIO INTERFACE
jack.
3. Push the [TUNE] button on the tuner for 0.5 to 2 seconds to initiate
automatic tuning process.
automatically drops to the low-power CW mode and stays in this mode
until tuning of the tuner is complete. See the appropriate Yaesu
manual for setting the low power tune mode.
4. For Yaesu owners who have an FH-1, an inexpensive 1/8" headphone
splitter (mono or stereo) may be used to connect the FH-1 in parallel
with the MFJ-5124Y3.

Technical Assistance

If you have any problem with this unit first check the appropriate section of this
manual. If the manual does not reference your problem or your problem is not
solved by reading the manual you may call MFJ Technical Service at 662-323-
0549 or the MFJ Factory at 662-323-5869. You will be best helped if you have
your unit, manual and all information on your station handy so you can answer
any questions the technicians may ask.
You can also send questions by mail to MFJ Enterprises, Inc., 300 Industrial
Park Road, Starkville, MS 39759; by facsimile (FAX) to 662-323-6551; or by
email to techinfo@mfjenterprises.com. Send a complete description of your
problem, an explanation of exactly how you are using your unit, and a complete
description of your station, and the unit's firmware version number.
© 2006 MFJ Enterprises, Inc.
Supported Yaesu radios are FT-1000MP, MP
The Yaesu MP-series transceiver
Instruction Manual
Rev. 12/20/06
TM
