Quick Reference Guide CPN-1
Legal Notices
This manual and any examples contained herein are provided "as is". JNC makes no warranty of any kind with regard to this manual,
including, but not limited to, the implied warranties of merchantability, non-infringement and fitness for a particular purpose. JNC shall
not be liable for any errors or for incidental or consequential damages in connection with the furnishing, performance, or use of this
manual or the examples contained herein.
Reproduction, adaptation or translation of this manual is prohibited without prior written permission of JNC Service B.V.
CAUTION: This Quick Reference Guide may be revised or withdrawn at any time without prior notice.
This document provides basic usage instructions and information on setting up your DOKKi docking station.
UNPACKING
Do NOT use a knife to open the package or contents as this may result in damage to the product(s)
Open the outer box on the top-side. Take the CPN-1 from it's box and carefully remove the bubble-foil.
BOX CONTENTS
CPN-1 docking station
•
Promotional items aren't listed here.
The CPN-1 will fit Opticon scanner models OPN-3002i, OPN-3002n, OPN-4000i and OPN-4000n.
The insertion area is as tight as possible to ensure stability for the scanner. This also means that the scanner won't fit
when used in combination with any available sleeve or case (rubber, leather, etc.).
Always check our website for the latest list of models that fit if your model isn't listed here.
Before inserting any scanner in the dock be sure to remove the USB cover
(see note below).
Save the USB cover in case it's needed at a later stage.
By removing the USB cover from the scanner dust and/or moist can penetrate the connector and opening(s) behind
the USB cover more easily. It is possible that the products' IP rating has been altered too.
Removing any original part from the scanner could void warranty. Doing so is at your own risk!
DOKKi.eu is a trademark of JNC Service B.V. ('JNC'). Copyright JNC Service B.V. All rights reserved.
DOKKi
DOKKi CPN-1
CPN-1_QRG-001 / September 2014
.eu
Advertisement
Table of Contents
Related Manuals for Dokki CPN-1
Summary of Contents for Dokki CPN-1
- Page 1 Do NOT use a knife to open the package or contents as this may result in damage to the product(s) Open the outer box on the top-side. Take the CPN-1 from it's box and carefully remove the bubble-foil. BOX CONTENTS CPN-1 docking station •...
- Page 2 DOKKi Quick Reference Guide CPN-1 POSITIONING The CPN-1 has rubber feet on the bottom and can be used on a flat surface. Please make sure the CPN-1 is positioned on a firm background which is level. POWER AND CONNECTION Plug the USB cable into the mini USB connector in the rear of the CPN-1.
- Page 3 TROUBLESHOOTING If you are experiencing any problem with the CPN-1 the first thing to check is if the scanner operates correctly when connected directly to the PC with an USB cable. Do so by plugging the USB cable that came with your scanner into your scanner and make sure the other end of the USB cable goes directly into the PC (bypassing any present HUB).
