PROGRAM MANUAL
Thermal receipt printer TP-80
1. COMMANDS
1.1 Command Notation
[Name]
The name of the command.
[Format]
The code sequence.ASCII,Hex, Decimal 3 kinds of formats, default Decimal format.
[Range]
Gives the allowable ranges for the arguments.
[Description] Describes the command's function.
[Details]
Describes the usage of the command in detail.
[Notes]
Provides important information on setting and using the printer command, if necessary.
[Default]
Gives the default values, if any, for the command parameters.
[Reference] Lists related commands.
2. HT
[Name]
Horizontal tab
[Format]
ASCII
Hex
Decimal
[Description] Moves the print position to the next horizontal tab position.
[Details]
• This command is ignored unless the next horizontal tab position has been set.
• If the next horizontal tab position exceeds the printing area, the printer sets the
printing position to [Printing area width + 1].
• Horizontal tab positions are set with ESC D.
• If this command is received when the printing position is at [printing area width
+ 1], the printer executes print buffer-full printing of the current line and
horizontal tab processing from the beginning of the next line.
• The default setting of the horizontal tab position for the paper roll is font A
(12 ╳ 24) every 8th character (9th, 17th, 25th, ... column).
[Reference]
ESC D
3. LF
[Name]
Print and line feed
[Format]
ASCII
Hex
Decimal
[Description]
Prints the data in the print buffer and feeds one line based on the current line
spacing.
[Note]
This command sets the print position to the beginning of the line.
[Reference]
ESC 2, ESC 3
HT
09
9
LF
0A
10
