Summary of Contents for Quanmax QDSP-2080
- Page 1 Content QDSP-2080 Digital Signage Player with Intel® Haswell Processor User’s Guide...
-
Page 2: Table Of Contents
System tour......................15 Mechanical Dimensions..................18 Chapter 2 Getting Started ....................19 Setting up your PC ....................19 Connecting VESA Mount on QDSP-2080............22 Mounting your PC to a monitor................23 Chapter 3 AMI BIOS Setup ....................24 Overview ........................24 Main Menu ......................25 ... -
Page 3: Figures
Figure 5 Connecting USB mouse & keyboard ..........20 Figure 6 COM port....................20 Figure 7 Network cable with RJ45 connector ...........21 Figure 8 Turning on the system ................21 Figure 9 VESA Mount Assembly .................22 Figure 10 VESA Mount on QDSP-2080.............22 Figure 11 VESA mounting ..................23... -
Page 4: Tables
Tables Tables Table 1 QDSP-2080 Specification ..............14 Table 2 BIOS Main Menu ..................25 Table 3 Advanced Menu ..................26 Table 4 Advanced Menu – Display Configuration..........27 Table 5 Advanced Menu – Super IO Configuration..........28 Table 6 Advanced Menu –Super IO Configuration – Serial Port 1 Configuration ....................28... -
Page 5: Safety Instructions
Safety Instructions Safety Instructions Before You Begin Before handling the product, read the instructions and safety guidelines on the following pages to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section in the Preface for advisory conventions used in this user’s guide, including the distinction between Warnings, Cautions, Important Notes, and Notes. -
Page 6: When Working Inside A Computer
Safety Instructions When Working Inside a Computer Before taking covers off a computer, perform the following steps: Turn off the computer and any peripherals. Disconnect the computer and peripherals from their power sources or subsystems to prevent electric shock or system board damage. This does not apply when hot swapping parts. -
Page 7: Instructions For Lithium Battery
Safety Instructions When unpacking a static-sensitive component from its shipping carton, do not remove the component’s antistatic packing material until you are ready to install the component in a computer. Just before unwrapping the antistatic packaging, be sure you are at an ESD workstation or grounded. This will discharge any static electricity that may have built up in your body. -
Page 8: Preface
Preface Preface How to Use This Guide This guide is designed to be used as step-by-step instructions for installation, and as a reference for operation, troubleshooting, and upgrades. Unpacking When unpacking, follow these steps: After opening the box, save it and the packing material for possible future shipment. - Page 9 Preface receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by your dealer could void the user's authority to operate the equipment. NOTE The assembler of a personal computer system may be required to test the system and/or make necessary modifications if a system is found to cause harmful interference or to be noncompliant with the appropriate standards for its intended use.
-
Page 10: Maintaining Your Computer
Preface Maintaining Your Computer Environmental Factors Temperature The ambient temperature within an enclosure may be greater than room ambient temperature. Installation in an enclosure should be such that the amount of air flow required for safe operation is not compromised. Consideration should be given to the maximum rated ambient temperature. - Page 11 Preface Power Protection The greatest threats to a system’s supply of power are power loss, power spikes, and power surges caused by electrical storms, which interrupt system operation and/or damage system components. To protect your system, always properly ground power cables and one of the following devices. ...
-
Page 12: Chapter 1 Introduction
Chapter 1 Chapter 1 Introduction Overview The QDSP-2080 is a compact size Box PC ideal for space critical applications. This ® embedded hardware platform features 4th Generation Intel Core™ i3/i5/i7 ® Processors, Intel QM87 Express chipset, and DDR3/L1333/1600 MT/S SO-DIMM. It comes with a 2.5”... -
Page 13: Product Specifications
Chapter 1 Product Specifications Metal Housing Construction ® Intel Hasw ell Processor ® 4th Generation Intel Core™ i3/i5/i7 Processors System Board ® Intel QM87 Express Chipset 2x DDR3/ L 1333/ 1600 MT/S SO- DIMM Mem ory ® Intel HD Graphics 4600 supports 4K x 2K Resolution Graphic Front I/O 3x 3.5mm Phone Jack, support 5.1 channel audio output... -
Page 14: Table 1 Qdsp-2080 Specification
Operating: 0°C to 40°C, 0%-90%, non-condensing Tem perature / Storage: -20°C to 80°C, 0%-90%, non-condensing Hum idity 200 x 35 x 153.1 mm (WxHx D) Dim ensions 1 Kg Weight VESA Mount Mounting CE, FCC Class A Certifications Table 1 QDSP-2080 Specification... -
Page 15: System Tour
Chapter 1 System tour Refer to the figures below to identify the components of the system. Front IO Figure 1 Front IO Power Button (with Power LED (Blue) ) The power push button allows powering ON and OFF the system. The power LED will light when the PC is power-on. - Page 16 Chapter 1 S/PDIF S/PDIF output for carrying digital audio signals out to the device. Phone Jack Line Out The stereo headphone jack is used to connect the system’s audio out signal to amplified speakers or headphones. MIC-IN The microphone jack is designed to connect the microphone used for video conferencing, voice narrations, or simple audio recordings.
-
Page 17: Figure 2 Rear Io
Chapter 1 Rear Rear Figure 2 Rear IO D-Sub 9 pin connector for RS-232/422/485 connection Ethernet The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection to a local network. HDMI HDMI connector for display output DVI-I DVI-I connector for DVI-D or VGA output DC Jack The supplied power adapter converts AC power to DC for use with this jack. -
Page 18: Mechanical Dimensions
Chapter 1 Mechanical Dimensions Dimension: 200 x 35 x 153.1 mm (W x H x D) Figure 3 Mechanical Dimensions... -
Page 19: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your PC ￭ Connect the monitor, mouse and keyboard Connecting the monitor Connect the DVI-I / HD MI cable from your display to the DVI-I / HDMI port. HDMI DVI-I Figure 4 Connect the DVI-I / HDMI cable... -
Page 20: Figure 5 Connecting Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your QDSP-2080 does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. 6xUSB 3.0 Figure 5 Connecting USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 21: Figure 7 Network Cable With Rj45 Connector
Chapter 2 Connecting to a network device Connect one end of a network cable to the LAN port on the system rear panel and the other end to a hub or switch. 2x LAN Figure 7 Network cable with RJ45 connector ... -
Page 22: Connecting Vesa Mount On Qdsp-2080
Take out the VESA mounting kit form your package and facing it onto the bottom of QDSP-2080. Figure 9 VESA Mount Assembly Then tightening the screws on your QDSP-2080 as figures shown below. Following figures are the complete status when you done. Figure 10... -
Page 23: Mounting Your Pc To A Monitor
Firstly, mount your VESA kit on the backside of the monitor with four screws in the package. Secondly, place the QDSP-2080 on the VESA mounting kit and then tightening the screws from the holes on both sides of the VESA bracket - make sure the computer is fitting well on the bracket. -
Page 24: Chapter 3 Ami Bios Setup
Chapter 3 Chapter 3 AMI BIOS Setup Overview This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact with your dealer. NOTE The BIOS menus and selections for your product may vary from those in this chapter. -
Page 25: Main Menu
S e c u r i t y S a v e & E x i t M a i n Produc t Information Produc t Name QDSP-2080 BIOS Version R0.07 (x64) BIOS Build D ate 10/09/2013 ME FW Version 9.0.20.1447 CPU Infor mati on Intel®... -
Page 26: Advanced Menu
Chapter 3 Advanced Menu Table 3 Advanced Menu BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e &... -
Page 27: Table 4 Advanced Menu - Display Configuration
Chapter 3 Table 4 Advanced Menu – Display Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e &... -
Page 28: Table 5 Advanced Menu - Super Io Configuration
Chapter 3 Table 5 Advanced Menu – Super IO Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e &... -
Page 29: Table 7 Advanced Menu -Super Io Configuration - Serial Port
Chapter 3 Table 7 Advanced Menu –Super IO Configuration – Serial Port 2 Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e &... -
Page 30: Table 8 Advanced Menu -Cpu Chipset Configuration
Chapter 3 Table 8 Advanced Menu –CPU Chipset Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d CPU Chipset C onfigurati on EIST [Enabled]... -
Page 31: Table 9 Advanced Menu -Sata Configuration
Chapter 3 Table 9 Advanced Menu –SATA Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d SATA Controller(s) ... -
Page 32: Table 10 Advanced Menu -Usb Configuration
Chapter 3 Table 10 Advanced Menu –USB Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d ... -
Page 33: Table 11 Advanced Menu -Amt Configuration
Chapter 3 Table 11 Advanced Menu –AMT Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Intel AMT [Enabled] ... -
Page 34: Table 13 Advanced Menu -H/W Monitor
Chapter 3 Table 13 Advanced Menu –H/W Monitor BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d PC Health Status ... -
Page 35: Table 14 Power Configuration
Chapter 3 Table 14 Power Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S e r v e r M g m t S a v e & E x i t A d v a n c e d Power Management Configuration ... -
Page 36: Boot Menu
Chapter 3 Boot Menu Table 15 Boot Menu BIOS SETUP UTILITY M a i n A d v a n c e d S e c u r i t y S a v e & E x i t B o o t Boot Configuration ... -
Page 37: Security Menu
Chapter 3 Security Menu Table 16 Security Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t S a v e & E x i t S e c u r i t y Pass word D escription ... -
Page 38: Save & Exit Menu
Chapter 3 Save & Exit Menu Table 17 Save & Exit Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t S e c u r i t y S a v e &... - Page 39 Chapter 3 Save Changes and Exit Exit system setup after saving the changes. Once you are finished making your selections, choose this option from the Exit menu to ensure the values you selected are saved to the CMOS R AM. The CMOS R AM is sustained by an onboard backup battery and stays on even when the PC is turned off.
-
Page 40: Chapter 4 Driver Installation
Chapter 4 Chapter 4 Driver Installation If your QDSP-2080 does not come with an operating system pre-installed, you will need to install an operating system and the necessary drivers to operate it. After you have finished assembling your system and connected the appropriate power source, power it up using the power supply and install the desired operating system.
