OWNER'S OPERATION AND INSTRUCTION MANUAL
MODEL: 1100
CAUTION!
Please read this entire manual before you install or use
your new room heater.
Failure to follow instructions may
result in property damage, bodily injury, or even death.
Improper Installation Could Void
Your Warranty!
SAFETY NOTICE:
If this heater is not properly installed, a house fi re may result.
For your safety, follow the installation instructions. Never
use make-shift compromises during the installation of this
heater. Contact local building or fi re offi cials about permits,
restrictions and installation requirements in your area.
Approved for installation in the USA and Canada
Conforms to UL Std.1482, Certifi ed to ULC Std. S627
Approved for mobile home installation in USA and Canada
Meets EPA particulate matter (smoke) control requirements for noncatalytic wood heaters built on or after July 1, 1990
.
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate emissions standards.
SAVE THESE INSTRUCTIONS
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE
YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
French version is available for download from the United States Stove Company website: http://www.usstove.com/
La version française est disponible pour téléchargement à partir du site United States Stove Company: http://www.usstove.com/
U.S. Stove
227 Industrial Park Rd.
South Pittsburg, TN 37380, USA
Phone: (800)750-2723
www.usstove.com
852094C-1910E

Advertisement

Table of Contents
loading

Summary of Contents for U.S. Stove 1100

  • Page 1 OWNER’S OPERATION AND INSTRUCTION MANUAL MODEL: 1100 CAUTION! Please read this entire manual before you install or use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death. Improper Installation Could Void...
  • Page 2 Future generations will thank you. This manual describes the installation and operation of the U. S. Stove, 1100 wood heater. This heater meets the 2015 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters sold after May 15, 2015. Under specifi c test conditions this heater has been shown to deliver heat at rates ranging from 8,742 to 30,821 Btu/hr.

  • Page 3: Unpack And Inspect

    UNPACK AND INSPECT Remove the packing from the appliance and inspect for any damage. Your appliance is packed with the door handle spring not installed. Remove the door handle spring from the packaging and attach it to the door handle as shown. Ensure that the bricks are positioned correctly and not broken (see illustration for proper brick arrangement).
  • Page 4 ASSEMBLY Step 1. THE BLOWER ASSEMBLY MUST BE DISCONNECTED FROM THE SOURCE OF ELECTRICAL SUPPLY BEFORE ATTEMPTING THE INSTALLATION. With pliers, cut the 4 tabs and remove panel on the back of the stove. Note: Discard the panel. Step 2. Fix the assembly to the back of the stove with the four screws provided.

  • Page 5: Installation

    INSTALLATION SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. • CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE OFFICIALS ABOUT PERMITS, RESTRICTIONS AND INSTALLATIONS REQUIREMENTS IN YOUR AREA. •...

  • Page 6: Corner Installation

    FREE STANDING STOVE CLEARANCES A wood stove must never be installed in a hallway or near a staircase, since it may block the way in case of fi re or fail to respect required clearances. It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove.

  • Page 7: Special Mobile Home Requirements

    SPECIAL MOBILE HOME REQUIREMENTS  WARNING! - Do not install in a sleeping room  CAUTION! - The structural integrity of the mobile home floor, wall, and ceiling/roof must be maintained In addition to the previously detailed installation requirements, mobile home installations must meet the following requirements: •...

  • Page 8: Chimney Connector (Stove Pipe)

    CHIMNEY CONNECTOR (STOVE PIPE) Your chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer in order to insure there will be no problem with the draft. The stove pipe must be made of aluminized or cold roll steel with a minimum thickness of 0.021”...
  • Page 9 CHIMNEY Your wood stove may be hooked up with a 6” factory built or masonry chimney. If you are using a factory built chimney, it must comply with UL 103 or CSA-B365 standard; therefore it must be a Type HT (2100°F). It is extremely important that it be installed according to the manufacturer’s specifi...

  • Page 10: Masonry Chimney

    MASONRY CHIMNEY Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated.

  • Page 11: Factory Built Chimney

    FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, fi restops (where needed), insulation shield, roof fl...

  • Page 12: Combustible Wall Chimney Connector Pass-Throughs

    COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS Method A. 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specifi cation for Clay Fire Linings) or its equivalent.

  • Page 13: Do Not Burn

    WOOD UTILIZATION This heater is designed to burn natural wood only. Higher effi ciencies and lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or to green or freshly cut hardwoods. DO NOT BURN: 1. Garbage; 10.
  • Page 14 Once the updraft movement is initiated, you are ready to ignite the stove by lighting the paper and kindling wood inside the combustion chamber. When you have achieved a good bed of hot embers, we recommend the following burn procedures: 1100 Primary Air Settings Electric Blower Speed Setting (Variable) (Slide Damper is located in center of stove under hearth plate) (Blower is on High when turned “ON”,...
  • Page 15 WARNINGS • NEVER OVERFIRE YOUR STOVE. IF ANY PART OF THE STOVE STARTS TO GLOW RED, OVER FIRING IS HAPPENING. READJUST THE AIR INTAKE CONTROL AT A LOWER SETTING. • THE INSTALLATION OF A LOG CRADLE OR GRATES IS NOT RECOMMENDED IN YOUR WOOD STOVE. BUILD FIRE DIRECTLY ON FIREBRICK.
  • Page 16 If a chimney or creosote fi re occurs, close all dampers immediately. Wait for the fi re to go out and the heater to cool, then inspect the chimney for damage. If no damage results, perform a chimney cleaning to ensure there is no more creosote deposits remaining in the chimney. OPERATIONAL TIPS Operational Tips for Good, Effi...
  • Page 17 IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE MANUFACTURER. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. Description Part # Description Part # 69761 WELDMENT, DAMPER 23783 FIREBRICK (1-1/4 X 2-9/16 X 9) 891987...
  • Page 18 37 42 Part No. Description Qty. 25089 BLOWER HOUSING BACK 25090 BLOWER HOUSING FRONT 80442 80 CFM BLOWER 80090 THERMOSTAT 80109 STRAIN RELIEF BUSHING 80232 POWER SUPPLY CORD 83172 #10 x 1/2 SHEET METAL SCREW...

  • Page 19: How To Order Repair Parts

    WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION AS SHOWN IN THIS LIST: THE PART NUMBER THE PART DESCRIPTION THE MODEL NUMBER: THE SERIAL NUMBER: U.S. Stove 227 Industrial Park Road South Pittsburg, TN 37380 USA Phone: (800)750-2723 www.usstove.com...
  • Page 20 NOTES...
  • Page 21 NOTES...
  • Page 22 NOTES...
  • Page 23 WARRANTY INFORMATION CARD Name__________________________________________ Telephone #: (_____)_____________ City____________________________________________ State_______ Zip_________________ Email Address __________________________________________________________________ Model # of Unit________________________________ Serial #___________________________ Fuel Type: Wood Coal Pellet Gas Other _________________________ Place of Purchase (Retailer)______________________________________________________ City____________________________________________ State_______ Zip_________________ If internet purchase, please list website address___________________________________ Date of Purchase _______________________________________________________________ Alternative Heat Main Heat Source...
  • Page 24   Fold Here Fold Here Fold Here PLACE STAMP HERE U.S. Stove 227 Industrial Park Rd South Pittsburg, TN 37380...
