- Page 1 All manuals and user guides at all-guides.com REDUNDANT POWER SUPPLY SYSTEM FOR NETGEAR® RPS CAPABLE ETHERNET SWITCHES . RPS5412 ODEL Redundant Power Supply Manual Revision B July 2014 Optimal Power Supplies LLC www.optimal-power.com...
- Page 2 Optimal Power Supplies LLC is not responsible for any kind of damages sustained through the use of this or any other Optimal Power Supplies LLC products. It is entirely the customer’s responsibility to take all the necessary precautionary measures when installing this unit.
-
Page 3: Table Of Contents
Typical System Level Setup…..……………………………………………... Status Indicators and Back Panel Connections…………………………… Back Panel DC Power Connector……………………………………………. Front Panel Status Indicators…………………………………......Compatible NETGEAR® Switch Model Number Table.…….……………... Model No. RPSC5412 (DC Connection Cable).…………………………….. Alarm Systems…………..…………………………………………………... Alarm Monitoring System………………….………………………………... Installation and Maintenance………………………………......Installation………………………………………………………………….. -
Page 4: Rps Power Series - Introduction
Military The RPS Power Series™ is a reliable, efficient and inexpensive solution for all kind of AC to ® DC power supply applications. Optimal Power RPS units are intended for providing redundant power to NETGEAR® switches. 1.2 Main Features: ... -
Page 5: General Rps Power Series Specifications
All manuals and user guides at all-guides.com 1.3 General RPS Power Series Specifications: Input Voltage………………………………...Universal 90VAC to 264VAC Input Frequency……………………………...47Hz to 63Hz Operational Temperature………………….…0°C to 55°C Storage Temperature………………………..-20°C to 85°C Cooling………………………………………Forced Air / Convection Cooling Overload Protection………………………..Auto-Recovery Efficiency…………………………………..80-90% Typical DC OK………………………………………Status LED 1.4 Typical Safety Rating for Internal Power Supply Bricks: Designed in full compliance with……...……UL60950 CSA 22.2 No. -
Page 6: Rps5412
All manuals and user guides at all-guides.com Chapter 2 RPS5412 2.1 RPS5412 Description: The Model RPS5412 is a 1U rack mountable RPS (Redundant power supply) designed to operate with NETGEAR RPS capable switches. Model RPS5412 has built-in universal AC to –52V DC and +12V DC power supplies with one IEC AC input socket. - Page 7 All manuals and user guides at all-guides.com Physical Dimensions 1U (1.75” H x 19” W x 12.12” D) Weight Approx. 11.65 lb = 5.28 kg = 186.40 oz Dimentional Figure Overall Rear View...
-
Page 8: Typical System Level Setup
All manuals and user guides at all-guides.com 2.3 Typical System Level Setup: ® An external Optimal Power RPS unit can be connected to a NETGEAR® switch to provide redundant power in case the primary power supply connected to the NETGEAR® switch fails. -
Page 9: Status Indicators And Back Panel Connections
3.2 Front Panel Status Indicators Description DC Power Supply Status Solid Green 3.3 Compatible NETGEAR® Switch Model Number Table Compatible NETGEAR® Switch Model Number Table ® ® NETGEAR® Optimal Power Optimal Power Switch Model RPS Models DC Cable GSM7224-200 RPS5412 RPSC5412 RPS5412... -
Page 10: Model No. Rpsc5412 (Dc Connection Cable)
All manuals and user guides at all-guides.com 3.4 Model No. RPSC5412 (DC Connection Cable) NETGEAR® Switch Side Connector RPS5412 Side Connector RPSC5412 Package Content Redundant Power Supply Model RPS5412 DC Connection Cable Model RPSC5412 AC Connection Cord (see ordering chart) ... -
Page 11: Alarm Systems
All manuals and user guides at all-guides.com Chapter 4 Alarm Systems 4.1 Alarm Monitoring System The RPS Model RPS5412 has the ability to monitor output DC voltage. If the front panel Green LED is ON that indicates good AC input and good DC output. When the Green LED is OFF that indicates the following: ... -
Page 12: Installation And Maintenance
Mounting Instructions Before you install the RPS Power Supply, consult Section 3.3 of this manual to confirm ® that your switch supports the OPTIMAL POWER RPS Series Model RPS5412. Installing the RPS Power Supply on a Flat Surface You can install the RPS5412 (Redundant Power Supply) RPS on any appropriate level surface that can safely support the weight of the switches, the RPS Power Supply, and their attached cables. - Page 13 ® switches for Optimal Power Power Supply Series™ RPS The figure shows where to connect the Optimal Power® RPS Model RPS5412 on the NETGEAR® switch. Note: The location of the redundant power supply connector on your switch may differ from...
-
Page 14: Maintenance & Safety Instructions
When the power is "OFF", you can remove the cover plate on the rear panel of the NETGEAR® switch as shown on the previous page. Now connect the RPS DC Connection Cable Model RPSC5412 to the appropriate NETGEAR® PoE switch making sure the connections are well secured, and the AC power is "OFF"... -
Page 15: Trouble-Shooting Instructions
Check that AC input power exists and that main switch is in the "ON" position. Check that the required 6A@250V fuse at the back of the RPS is not blown. Check that all the RPS DC Connection Cable Models RPSC5412 are connected and well secured. -
Page 16: Warnings
DO NOT press against the front and/or rear panel. Optimal Power Supplies LLC is not responsible for any kinds of damages (direct or indirect) sustained through the use of any of its products.
