M
ake sure to read the Important Precautions before using the
product. Keep the User's Guide(CD) in an accessible place for future
reference.
S
ee the label attached on the product and give the information to
your dealer when you ask for service.
User's Guide
E2050S
E2250S
E2350S

Advertisement

Table of Contents
loading

Related Manuals for LG E2350SV

Summary of Contents for LG E2350SV

  • Page 1 User’s Guide E2050S E2250S E2350S ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
  • Page 4 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 5 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 6 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. 15-pin D-Sub Signal Cable User's Guide/Cards (To set it up, this signal cable may be attached to this product before shipping out.) Power Cord...

  • Page 7: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. 1 way stand Place the monitor with its front facing downward on a cushion or soft cloth. Use a coin on the back of the stand base and turn the screw clockwise to tighten.
  • Page 8 Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. 2 way stand Place the monitor with its front facing downward on a soft cloth. Press the button as shown, and pull the stand body up.
  • Page 9 Connecting the Display . If you want to use the stand base,pull the stand body down. (Once you pull the stand body down, please keep pressing the button.If you don’t press the button, it will damage the product.) Use a coin on the back of the stand base and turn the screw clockwise to tighten. Once assembled take the monitor up carefully and face the front side.

  • Page 10: Positioning Your Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display After installation, adjust the angle as shown below. * With sandbase Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚~15˚...
  • Page 11 Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display * Without sandbase Ergonomic It is recommended that in order to maintain an ergonomic and comfortable viewing position, the backward tilt angle of the monitor should exceed 10 degrees.

  • Page 12: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.

  • Page 13: Control Panel Functions

    Control Panel Functions Front Panel Controls MENU Button Use this button to enter or exit the On Screen Display. OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED"...

  • Page 14: Auto Image Adjustment

    Control Panel Functions AUTO Button Use this button to enter a selection in the On Screen Display. AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the AUTO button before entering the On Screen Display(OSD). (Only Analog Mode) This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode).

  • Page 15: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.

  • Page 16: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Description BRIGHTNESS To adjust the brightness, contrast PICTURE and sharpness of the screen CONTRAST SHARPNESS COLOR TEMP To customize the color of the COLOR (PRESET / USER)
  • Page 17 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. MO NI TO R SE TUP AUTO MENU...
  • Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS ME N U PICT URE CONTRAST To adjust the contrast of the screen. BRIGHTNESS SHARPNESS To adjust the clearness of the screen. CONTRAST SHARPNESS EXIT...
  • Page 19 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description DISPLAY HORIZONTAL To move image left and right. M E N U D I S P L A Y HORIZONTAL To move image up and down. VERTICAL VERTICAL CLOCK PHASE To minimize any vertical bars or CLOCK...
  • Page 20 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description OTHERS To choose the language in which the LANGUAGE MENU OTHERS control names are displayed. Use this function to set the power POWER LANGUAGE ENGLISH indicator on the front side of the monitor INDICATOR POWER INDICATOR to ON or OFF.
  • Page 21 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. M O N I T O R S E T U P AUTO MENU...

  • Page 22: Auto Broght

    On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description SMART+ SMART+ AUTO BRIGHT AUTO BROGHT DUAL ORGINAL RATIO If select on,it automatically controls the brightness of display to best suit the surrounding working environment,providing the optimal viewing condition and maximized user convenience.

  • Page 23: Cinema Mode

    On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description * Before using below functions, please install Easy Set Packge programme. SMART+ DUAL WEB SMART+ DUAL WEB DUAL ORGINAL RATIO Help user to browse web efficiently by dividing in half. Help to arrange and move windows on screen.
  • Page 24 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. M O N I T O R S E T U P AUTO MENU...
  • Page 25 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description NORMAL Select this when you want to use the product in the most general using environment. MOVIE Select this when you are watching a video or movie. INTERNET Select this when you are working on the document (Word etc.) DEMO This is used for advertising in the store.

  • Page 26: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears ● Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. ● Is the power indicator •...

  • Page 27: Display Image Is Incorrect

    Troubleshooting Display image is incorrect ● Display Position is • Press the AUTO button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.
  • Page 28 Troubleshooting Display image is incorrect ● The screen color is • Check if the signal cable is properly connected and use a screwdriver to fasten if necessary. mono or abnormal. • Make sure the video card is properly inserted in the slot.

  • Page 29: Specifications

    Specifications E2050S Display 50.8 cm (20.0 inches) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 50.8 0.2766 x 0.2766 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
  • Page 30 Specifications E2250S Display 54.6 cm (21.5 inches) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 0.248 x 0.248 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
  • Page 31 Specifications E2350S Display 58.4 cm (23.0 inches) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.4 0.265 x 0.265 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.

  • Page 32: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) E2050S Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.123 1024 x 768 67.500 1152 x 864 60.000...
  • Page 33 Digitally yours...
