- Page 1 OWNER'S MANUAL BOTTOM FREEZER REFRIGERATOR Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times. LBNC15231* LBNC15241* www.lg.com MFL70720827 Rev.02_032420 Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved...
-
Page 2: Table Of Contents
14 Reversing Doors 14 Leveling 14 Turning on the Power 15 OPERATION 15 Before Use 16 Control Panel 17 Icemaker 18 Folding Shelf 19 Storing Food 22 SMART FUNCTIONS 22 LG ThinQ Application 22 Smart Diagnosis™ Feature 23 MAINTENANCE 23 Cleaning... -
Page 3: Product Features
PRODUCT FEATURES PRODUCT FEATURES Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer drawer remains open. If a refrigerator door or freezer drawer is left open for more than 60 seconds, a warning alarm sounds at 30-second intervals. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. This is the safety alert symbol. - Page 5 SAFETY INSTRUCTIONS • Keep packing materials out of the reach of children. Packaging material can be dangerous for children. There is a risk of suffocation. • Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may deteriorate.
- Page 6 SAFETY INSTRUCTIONS • Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. • Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. • Do not damage the refrigerant circuit. •...
- Page 7 SAFETY INSTRUCTIONS CAUTION To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: INSTALLATION • Do not install the refrigerator where there may be a danger of the unit falling. •...
-
Page 8: Product Specifications
PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS The appearance and specifications listed in this manual may vary due to constant product improvements. Electrical requirements: 115 V, 60 Hz Model LBNC15231* LBNC15241* Description Bottom Freezer Refrigerator Net weight 167 lb (76 kg) -
Page 9: Product Overview
Control Panel Sets the refrigerator and freezer temperatures. Smart Diagnosis Speaker Use this function to help the LG Electronics Customer Information Center to diagnose problems if you call for service. LED Interior Lighting The LED lighting inside the appliance lights up when you open the door. - Page 10 PRODUCT OVERVIEW Folding Shelf* Fold shelf under to make room for tall items. Humidity Controlled Crisper* Helps vegetables and fruit to stay crisp and controls humidify. Crisper* Stores fruits and vegetables to keep them fresh for as long as possible. •...
-
Page 11: Installation
INSTALLATION INSTALLATION Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. Unpacking the Choosing the Proper Leveling and Door Refrigerator Location Alignment... -
Page 12: Unpacking The Refrigerator
INSTALLATION Unpacking the Refrigerator Choosing the Proper Location WARNING Electricity • Use two or more people to move and install the refrigerator. Failure to do so can result Use an individual, grounded outlet:115 Volts, 60 in back injury or other injury. Hz, AC, 15 Amps minimum. -
Page 13: Dimensions And Clearances
INSTALLATION Dimensions and Clearances • Check the dimensions of the appliance and the installation path to ensure there is sufficient room to move the refrigerator through doors or narrow openings. • The installation location chosen for the refrigerator should allow space behind the unit for connections and airflow and space in front to open the doors. -
Page 14: Reversing Doors
INSTALLATION Reversing Doors Turning on the Power • After installing, plug the refrigerator’s power This feature is only available on some models. cord into a 3-prong grounded outlet and push the refrigerator into the final position. Your appliance is designed with reversible doors, so that they may open from either the left of right hand side to suit your kitchen design. -
Page 15: Operation
OPERATION OPERATION Before Use Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION • Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator. -
Page 16: Control Panel
OPERATION Control Panel Depending on the model, some of the following functions may not be available. The control panel may differ from model to model. Control Panel Features Freezer Temperature Express Cool Indicates the set temperature of the freezer This function can quickly cool a large compartment in Fahrenheit (°F). -
Page 17: Icemaker
OPERATION Icemaker Removing Ice This is where ice is manually produced and Rotate the ice separation handle on the stored. icemaker clockwise. NOTE To create more space in the freezer, remove the ice tray or ice storage bin. Making Ice Use the handle on the ice tray to pull the tray out. -
Page 18: Folding Shelf
OPERATION Folding Shelf This feature is only available on some models. Fold the shelf to make room for taller items in front, such as gallon containers or wine bottles. To fold the shelf, lift the front of the sliding shelf slightly and slide it inward under the rear half of the shelf. -
Page 19: Storing Food
OPERATION Storing Food Where to Store Food Each compartment inside the refrigerator is designed to store different types of food. Store food in the optimal space to enjoy the freshest taste. Adjustable Refrigerator Shelf Adjustable shelves to meet individual storage needs. Crisper Preserves vegetables and fruit. - Page 20 OPERATION Food Storage Tips CAUTION Wrap or store food in the refrigerator in airtight and moisture-proof material unless otherwise • Do not overfill or pack items too tightly into noted. This prevents food odor and taste door bins. Doing so may cause damage transfer throughout the refrigerator.
- Page 21 OPERATION Storing Frozen Food Do not use • Bread wrappers Check a freezer guide or a reliable cookbook for further information about preparing food for • Non-polyethylene plastic containers freezing or food storage times. • Containers without tight lids • Wax paper or wax-coated freezer wrap Freezing •...
-
Page 22: Smart Functions
Freezer button. Installing the LG ThinQ Application Keep the phone in place until the tone Search for the LG ThinQ application from the transmission has finished. The display will Google Play Store or Apple App Store on a count down the time. Once the countdown smart phone. -
Page 23: Maintenance
MAINTENANCE MAINTENANCE Inside Walls • Allow freezer to warm up so the cloth will not stick. Cleaning To help remove odors, wash the inside of the refrigerator with a mixture of baking soda and warm water. Mix 2 tablespoons of baking soda to 1 quart of water (26 g soda to 1 liter water.) WARNING Be sure the baking soda is completely dissolved... -
Page 24: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING FAQs: Frequently Asked Questions What are the best temperature settings for my freezer and refrigerator? The default setting for the freezer is 0° Fahrenheit (-18° Celsius). The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). Adjust these settings as necessary to keep food at desired temperatures. -
Page 25: Before Calling For Service
TROUBLESHOOTING Before Calling for Service Review this section before calling for service; doing so will save you both time and money. Cooling Problem Possible Cause & Solutions The refrigerator control is set to OFF (some models). • Turn the control ON. Refer to the Setting the Controls section for proper temperature settings. - Page 26 TROUBLESHOOTING Cooling Problem Possible Cause & Solutions Doors are opened often or for long periods of time. • When the doors are opened often or for long periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 27 TROUBLESHOOTING Cooling Problem Possible Cause & Solutions Doors are opened often or for long periods of time. • When the doors are opened often or for long periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 28 TROUBLESHOOTING Making Ice Problem Possible Cause & Solutions Doors are opened often or for long periods of time. • If the doors of the unit are opened often, ambient air will warm the refrigerator which will prevent the unit from maintaining the set temperature.
- Page 29 TROUBLESHOOTING Parts & Features Problem Possible Cause & Solutions Food packages are blocking the door open. • Rearrange food containers to clear the door and door shelves. Ice bin, crisper cover, shelves, door bins, or drawers are out of position. •...
- Page 30 TROUBLESHOOTING Noises Problem Possible Cause & Solutions The defrost control will click when the automatic defrost cycle begins and ends. The thermostat control (or refrigerator control Clicking on some models) will also click when cycling on and off. • Normal Operation Rattling noises may come from the flow of refrigerant or items stored on top of or around the refrigerator.
-
Page 31: Limited Warranty
Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics (“LG”) will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product and applies only when purchased and used within the United States including U.S. - Page 32 Or by mail: LG Electronics Customer Service P.O. Box 240007 Huntsville, AL 35813 ATTN: CIC PROCEDURE FOR RESOLVING DISPUTES: ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION.
- Page 33 Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 1000 Sylvan Ave, Englewood Cliffs 07632.
- Page 34 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the...
-
Page 35: For Canada
CLASS ACTIONS AND JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. - Page 36 150 km radius from the nearest authorized service center (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
- Page 37 If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein.
- Page 38 Limited Warranty. Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the...
