Summary of Contents for HANNspree HT161CGB2EX
- Page 1 HT161CGB (HSG1400) LCD Monitor OSD[V6.0]...
- Page 2 【Optional, depend on selected model】 Socket-outlet shall be near the equipment and shall be accessible. Trademark Notice: HANNspree products incorporate High-Definition Multimedia Interface (HDMI ) technology. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 3 User’s Manual RECYCLING INFORMATION We, the HANNspree care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels.
-
Page 4: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ....................5 PRECAUTIONS....................5 SPECIAL NOTES ON LCD MONITORS ............6 BEFORE YOU OPERATE THE MONITOR ............7 FEATURES......................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 ... -
Page 5: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 6: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. -
Page 7: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 39,5cm /15.6” Wide Screen TFT Color LCD Monitor Crisp, Clear Display for Windows Ergonomic Design Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: LCD Monitor Cables and User manual HDMI-MINI HDMI... -
Page 8: Support Holster Stents
User’s Manual SUPPORT HOLSTER STENTS (For reference only) POWER POWER SOURCE: charge a connected notebook.If the included power adapter is connected to the monitor, then the monitor can. Note: Power Delivery Output : DC 5V 2A... -
Page 9: Making Connections
User’s Manual MAKING CONNECTIONS CONNECTING TO A PC Turn off your computer before performing the procedure below. 1. Connect one end of the Type-C cable to the back of the monitor and connect the other end to the computer’s Type-C port. 2. -
Page 10: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 11: Front Panel Control
User’s Manual FRONT PANEL CONTROL Quick Menu: Press the ▲/▼/ ◀ / ▶ key to select activate the Quick Menu. Note ：Follow the key guide that appears on the screen to select the option or make adjustments. Menu Description Activation symbol to turn the various modes on when operating the menu system Exit... - Page 12 User’s Manual NOTES: Do not install the monitor in a location near heat sources such as radiators or air dusts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock. Save the original shipping box and packing materials, as they will come in handy if you ever have ...
-
Page 13: How To Adjust A Settings
User’s Manual HOW TO ADJUST A SETTINGS General Operations: 1. Press the Middle 【 】 Key and to Select the【 】key to display the On-Screen Disply (OSD) Menu. 2. Press the ◀ or ▶key to select the main menu, Then press the 【 】key to enter the selected menu. - Page 14 User’s Manual 3. Press the ▲ or▼ key to select the desired menu option. Press the 【 】 key to enter the sub-menu. 4. Press the ▲ or▼ key to select the setting, Then press 【 】key to confirm. Or press the◀ or ▶ key to make adjustments.
-
Page 15: Plug And Play
User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 16: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position. Power LED is not on *Power Cord should be connected. * Check if the PC system is Plug & Play compatible. *Check if the Video Card is Plug &... - Page 17 62,5cm / 24.6 (16:9) 68,6cm / 27 ” (16:9) 70cm / 27.5” (16:10) 1920×1200@60Hz 1920×1200@50Hz And if you still have display problem after doing the above procedure, please visit Hannspree support and Service Website: http://www.hannspree.eu/en/monitors Windows is a registered trademark of Microsoft Corporation.
-
Page 18: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED: 1. Check that the signal-cable is properly connected, if the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. - Page 19 User’s Manual 1680×1050 @60Hz 65.290 59.954 1920×1080 @60Hz 67.500 60.000 (Video mode) MODE RESOLUTION 640×480p @60Hz 720×480i @60Hz 720×480p @60Hz 720×576i @50Hz 720×576p @50Hz 1280×720p @60Hz 1920×1080i @50Hz 1920×1080i @60Hz 1920×1080p @50Hz 1920×1080p @60Hz ** We ensure that the monitor can be lighted under interlace signal mode, but we can not guarantee the image quality.
-
Page 20: Appendix
2.3 kg (5.1 lb) *** The above specification is subject to actual product specification and is subject to change without prior notice. NOTES: The Maximum Resolution will depends on the display card supporting. Related issue can refer to http://www.hannspree.eu/en/monitors. FAQ section.
