- Page 1 Operators Manual & Parts List MAJOR SWIFT ROLLERMOWERS Three point linkage models: MJ70-190, MJ70-240 MJ70-320, MJ70-410, MJ70-550 Front mounted models: MJ70-190FM, MJ70-240FM MJ70-320FM, MJ70-410FM Trailed models MJ70-410T, MJ70-550T...
- Page 2 Head Office Major Equipment Intl. Ltd. Ballyhaunis, Co. Mayo, Ireland. Tel.: +353 (0) 9496 30572 Fax: +353 (0) 9496 30788 Email: info@major-equipment.com UK Office Major Equipment Ltd. Major Industrial Estate, Middleton Rd., Heysham, Lancs. LA3 3JJ Tel.: +44 (0) 1524 850 501 Fax: +44 (0) 1524 850 502 Email:...
-
Page 3: Table Of Contents
Contents Introduction Thank you Using Your Operator’s Manual Safety Aspects Intended use Product Identification Machine Serial Numbers Register Your Product and Warranty Online Product Specifications Safety Machine Safety Labels Hazards associated with operating Grass Cutting Machinery Operating Safely Workstation Regulations for use of the transmission PTO Shaft Safety Driving Safely on Public Roads Operating the Machine... - Page 4 Tel. +353949630572 +353949630788 declares in sole responsibility that the product: MJ70 ROLLERMOWER (SWIFT) When properly installed, maintained and used only for it’s intended purpose, complies with all the essential Health & Safety requirements of: • THE SUPPLY OF MACHINERY (SAFETY) REGULATIONS 2008.
-
Page 5: Thank You
140616 Introduction Thank you We appreciate having you as a customer and wish you many years of safe and satisfied use of your machine. Using Your Operator’s Manual This manual is an important part of your machine and should remain with the machine when you buy it. Reading your operator’s manual will help you and others avoid personal injury or damage to the machine. -
Page 6: Product Specifications
Product Specifications Model Overall Working Transport Power PTO rpm Cutting Rotors/ Weight Blade Mowing Width Width Width (HP) Height Blades (kg) Rates (mm) speed (Acres/hr (m/s) at 7mph) MJ70-190 2.0m (6' 6") 1.9m (6' 3") 2.00m (6' 6") 25-70 10-150 MJ70-240 2.5m (8' 2") 2.40m (8') -
Page 7: Hazards Associated With Operating Grass Cutting Machinery
Hazards associated with operating Grass Cutting Machinery Shear Hazard Shear hazards are created when the edges of two objects move toward or next to each other closely enough to cut relatively soft material. This can include the parts of the machine under hydraulic control when operating from transport to mowing position. -
Page 8: Operating Safely
Noise Hazard Please note that the machine is normally used outdoors and that the position of the operator is seated in the driving seat of the tractor. It is advisable to consult the prescriptions listed in tractor operator and maintenance manuals. The acoustic pressure at a distance of 2.6m from the centre of the machine and at a height of 2.0m, with the implement operating in a no load condition can reach 90 dBA. -
Page 9: Pto Shaft Safety
PTO Shaft Safety Maximum PTO input is specified in the Product Specifications section of this booklet. Contact your nearest dealer or a specialised retail outlet if the PTO must be replaced with a longer one, since this must belong to the same power category and possess the same characteristics. -
Page 10: Operating The Machine
Operating the Machine 270117 This machine is designed to be connected to a tractor by using a standard 3 point linkage connection. It can be installed either to the front or to the rear of the tractor, depending on the model of your machine. Key to Main Parts Rear mounted machine shown Body... -
Page 11: Inspections Before Use
Inspections before Use Always disengage PTO, Switch off tractor engine and engage the parking brake before making adjustments to the machine. 1. With the whole machine as level as possible, check the oil level in the Primary and Rotor Gearboxes and top up as required with recommended gear oil through the oil filler plug indicated. -
Page 12: Starting Regulations
Starting Regulations Always check that any imminently dangerous conditions have been eliminated before using the machine. Ensure all guarding is present & the operator is fully aware of the operations of the machine. Always ensure the pins lock the PTO shaft yoke ends onto the spline shafts on both the tractor and the implement. -
Page 13: Operating The Machine/Mowing
Transport Position (Winged models only) ALWAYS HAVE THE TRACTOR SWITCHED ON WHEN RAISING THE WINGS INTO TRANSPORT POSITION. IMPORTANT: The transport locking bars, transport pin and axle ram stopper should always be slotted into place while transporting the machine. Doing this removes pressure from the hydraulic system. Failure to use the safety equipment can cause mechanical as well as physical damage. -
Page 14: Roller And Castor Wheels Adjustment
Roller and Castor wheels adjustment In order to achieve desired cutting height, castor wheels and roller should be adjusted. Castor wheels (optional) Roller To adjust the height of front wheels lift up the To adjust the height of the roller follow this procedure at machine and: both sides of the roller: 1. -
Page 15: Maintenance
Maintenance The machine must always be disconnected form the tractor before any cleaning, lubricating and servicing operations can be carried out. Maintenance must be carried out by qualified personnel. If emergency operations are required whilst the machine is connected to the tractor, switch off the engine, engage the parking brake and disengage the PTO. -
Page 16: Blade Rotation
Blade Rotation Ensure blade rotation and timing (90 degrees) is correct after servicing transmission. CENTER BOX ROTATION VIEWED FROM TOP, LOOKING AT MACHINE. MJ70-190 CENTER BOX ROTATION MJ70-240 MJ70-320 VIEWED FROM TOP, LOOKING AT MACHINE. CENTER BOX ROTATION VIEWED FROM TOP, LOOKING AT MACHINE. MJ70-410 MJ70-550 Blade rotation viewed from underside... -
Page 17: Troubleshooting
Troubleshooting Fault Cause Remedy Blades dull or bent Replace blades Carrier RPM too low Use correct PTO speed Field conditions are so wet that the wheels Too wet to mow. Stop operation and wait until it is drier are pushing grass into mud Leaves a streak of uncut or Ground speed too fast... - Page 18 Damaged oil seal Replace seal Bent shaft Replace oil seal and shaft Shaft rough in oil seal area Replace or repair shaft Oil seal installed incorrectly Replace seal Gearbox leaking Oil seal not sealing in the housing Replace seal or use a sealant on outside diameter of seal Oil level too high Drain oil to proper level Hole in gearbox...
- Page 19 080416 MJ70 Spare Parts Single Deck models MJ70-190, MJ70-240 MJ70-190FM, MJ70-240FM www.major-equipment.com...
-
Page 20: Mj70-190 - General Assembly
MJ70-190 - General Assembly www.major-equipment.com... -
Page 21: Mj70-190 - Underbody Assembly
MJ70-190 - Underbody Assembly www.major-equipment.com... -
Page 22: Mj70-190 - Drivetrain And Roller Height Asjuster Assembly
MJ70-190 - Drivetrain and Roller Height Asjuster Assembly www.major-equipment.com... -
Page 23: Mj70-190 - Parts List
MJ70-190 - Parts List Item Part No. Description D281215 DISC SPRING 28x12x1.5 DSR-1-2 1/2" RATED 'D' SHACKLE 6300RM-SCRPR-01 6300 SCRAPER BAR DSR-5-8 5/8" RATED 'D' SHACKLE 725-BLD-FL 725 FIXED BLADE (Anti_Clk) DSW34 DISC SPRING 34x16.3 x2 725-BLD-FR 725 FIXED BLADE (Clk) FWM12 M12 FLAT WASHER 8400RM-CV14... -
Page 24: Mj70-240 - General Assembly
MJ70-240 - General Assembly www.major-equipment.com... -
Page 25: Mj70-240 - Underbody Assembly
MJ70-240 - Underbody Assembly www.major-equipment.com... -
Page 26: Mj70-240 - Drivetrain And Roller Height Asjuster Assembly
MJ70-240 - Drivetrain and Roller Height Asjuster Assembly www.major-equipment.com... -
Page 27: Mj70-240 - Parts List
MJ70-240 - Parts List Item Part No. Description 8400STR 8400RM MKII STRAP (2000mm) GREASE NIPPLE M8x1.25 STR 725-BLD-FL 725 FIXED BLADE (Anti_Clk) AN099/10 LINCH PIN DIA 9.5 725-BLD-FR 725 FIXED BLADE (Clk) CP176-181MG1 45mm INSERT 8400RM-CV14 GUARD BASE MOUNT D281215 DISC SPRING 28x12x1.5 8400RM-HG55 M20 ADJUSTER BLOCK... -
Page 28: Mj70 Front Mounted Standard Kit
STRAP MOUNT (FRONT) M20x120BZP M20x120 BOLT S15707 CAT 1/2 LINK PIN S4444 DIA 1 3/8"x2 1/8"x7/8" COLLAR SW-FM-C12 SWIFT A FRAME CAT 1-2 T27A267006 6 SPLINE 'T' BOX RATIO 1.1 V600810ENC12RB2 V60 SHEARBOLT / OR 111044 DIA 26-30mm INSERT 3234 CAT 1/2 TOP LINK PIN www.major-equipment.com... -
Page 29: Mj70 Front Mounted Multihog Kit
MJ70 Front mounted Multihog kit Item Part No. Description 1 MJ70-240-FMGF-GA FLAP GUARD (8400) 2 MJ70-CW-SW01 SWIFT CASTOR (FRONT) 3 MJ70-CW-SW30 SWIFT CASTOR (REAR) 4 SW-240-BD01 MJ70-240 BODY 5 SW-240-LM20 LINKAGE MOUNT (FRONT) 6 909-AF-01 909 A-FRAME 2011 7 9162 CAT 2 PIN DIA 28.5x113mm... -
Page 30: Mj70-190-Fmgf-Ga (Mj70-190Fm)
MJ70-190-FMGF-GA (MJ70-190FM) Item Part No. Description MJ70-190-FMGF02 FLAP PIVOT SHAFT MJ70-240-FMGF20 FLAP SUPPORT (FRONT) DIA 5/8"x1 1/8"x1/2" COLLAR MJ70-240-FMGF03 80mm FLAP GUARD MJ70-240-FMGF04 60mm FLAP GUARD ASSEMBLED MJ70-240-FMGF-GA (MJ70-240FM) REV 1: JUNE 2014 1 OF F PER MACHINE CTRS 805 WERE 875mm. ALTD FLAP NUMBERS TO SUIT. -
Page 31: Mj70-Cw-Sw01
30x34x26 FLANGE BUSH MJ70-CW-020 MJ70 CASTOR YOKE GREASE NIPPLE M8x1.25 STR MJ70-CW-025 CASTOR SPACER DSW34 DISC SPRING 34x16.3 x2 MJ70-CW-SW02 SWIFT CASTOR STAND FWM12 M12 FLAT WASHER RMCW-030 CASTOR AXLE FWM30 M30 FLAT WASHER RMCW-033 BEARING SPACER TUBE M12 NYLOC NUT... -
Page 32: Mj70-Cw-Sw30
GREASE NIPPLE M8x1.25 STR MJ70-CW-020 MJ70 CASTOR YOKE DSW34 DISC SPRING 34x16.3 x2 MJ70-CW-025 CASTOR SPACER FWM12 M12 FLAT WASHER MJ70-CW-SW31 SWIFT CASTOR STAND FWM30 M30 FLAT WASHER RMCW-030 CASTOR AXLE M12 NYLOC NUT 6005 47x25x12 DEEP GROOVE M12x100BZP M12x100 BOLT... -
Page 33: Mj70-410 - Overview
140616 MJ70 Winged models MJ70-320, MJ70-410, MJ70-550 MJ70-320FM, MJ70-410FM MJ70-410T, MJ70-550T MJ70-410 - Overview Item Part No. Description SW-270-BDGA MJ70-270 BODY SW-410-WGGA MJ70-410 WING SW-410-WGGAH MJ70-410 WING (LH) 19RM-WRAM WING LIFT RAM E500202S132132 CLAMP COLLAR PTO 15502-B CAT 1 TOP LINK MJ70-550 - Overview Item Part No. -
Page 34: Mj70-410/550 Body - General Assembly
MJ70-410/550 Body - General Assembly www.major-equipment.com... -
Page 35: Mj70-410/550 Body - General Assembly
MJ70-410/550 Body - General Assembly www.major-equipment.com... -
Page 36: Mj70-410/550 Body - Underbody Assembly
MJ70-410/550 Body - Underbody Assembly www.major-equipment.com... -
Page 37: Mj70-270 410/550 - Transmission And Height Adjuster
MJ70-270 BODY SCRAPER BAR BSCRPR-01 11RM-C16 MODIFIED OVAL GUARD MJ70-270-GBR01 UNDERSIDE TROUGH 3000T-AFBGA A' FRAME BUFFER MJ70-270-ROLB MJ70-270 BODY ROLLER 725-BLD-FL 725 FIXED BLADE (Anti_Clk) MJ70-320-HYD05 HYDRAULIC BLOCK 725-BLD-FR 725 FIXED BLADE (Clk) MJ70-320-STRP01 SWIFT CHAIN SLING 8400RM-CV14 GUARD BASE MOUNT www.major-equipment.com... -
Page 38: Mj70-410/550 - Parts List (Continued)
MJ70-410/550 - Parts List (continued) SW-240-LM08 SPACER TUBE D281215 DISC SPRING 28x12x1.5 SW-270-BD01 MJ70-270 BODY DSW34 DISC SPRING 34x16.3 x2 SW-270-HT01 HINGE TIE DIA 1" FLAT WASHER SW-270-LM01 LINKAGE MOUNT FWM12 M12 FLAT WASHER SW-270-LM01H LINKAGE MOUNT FWM12L M12 FLAT WASHER (LARGE) SW-270-SM01 270 STRAP MOUNT FWM16... -
Page 39: Mj70-410/550/410Fm- Hydraulics
MJ70-410/550/410FM- Hydraulics RIGHT WING "UP" LEFT WING "UP" IMPORTED ASSEMBLED Item Part No. Description REV X: XXXX 200X 19RM-WRAM WING LIFT RAM .......... 270-HOSE A 1/4"x 860mm Str to Block 90 270-HOSE-B 1/4"x 2440mm Str to Str CRP1400 1/4" CRIMP (STRAIGHT) CRP1490 1/4"... -
Page 40: Mj70-410 Wing - General Assembly
MJ70-410 Wing - General Assembly www.major-equipment.com... -
Page 41: Mj70-410 Wing - Underbody Assembly
MJ70-410 Wing - Underbody Assembly www.major-equipment.com... -
Page 42: Mj70-410 Wing - Height Adjuster And Transmission
MJ70-410 Wing - Height Adjuster and Transmission www.major-equipment.com... -
Page 43: Mj70-410 Wing - Parts List
I-257 3/4x1/2 REDUCER BUSH MJ70-270-PE01 PIVOT EYE M12 NYLOC NUT MJ70-460-GBR20 WING UNDERSIDE TROUGH M12x20SZP M12x20 SET BOLT SW-270-LITR SWIFT LIGHT ASSY RH M12x25SKBH M12x25 SOCKET BUTTON SW-410-WG01 MJ70-410 WING HEAD 10.9 15000RM2-CV52 RUBBER FLAP M12x30SKBH M12x30 SOCKET BUTTON 60CSD 60mm STAR DRIVE HEAD 10.9... -
Page 44: Mj70-550 Wing - General Assembly
MJ70-550 Wing - General Assembly www.major-equipment.com... -
Page 45: Mj70-550 Wing - Underbody Assembly
MJ70-550 Wing - Underbody Assembly www.major-equipment.com... -
Page 46: Mj70-550 Wing - Height Adjuster And Transmission
MJ70-550 Wing - Height Adjuster and Transmission www.major-equipment.com... -
Page 47: Mj70-550 Wing - Parts List
M12 NYLOC NUT MJ70-270-PE01 PIVOT EYE M12x20SZP M12x20 SET BOLT MJ70-600-GBR20 WING UNDERSIDE TROUGH M12x25SKBH M12x25 SOCKET BUTTON SW-270-LITR SWIFT LIGHT ASSY RH HEAD 10.9 SW-550-WG01 550 WING M12x30SKBH M12x30 SOCKET BUTTON 19000RM-CV52 RUBBER FLAP HEAD 10.9 60CSD 60mm STAR DRIVE... -
Page 48: Mj70-320 - Overview
MJ70-320 - Overview Item Part No. Description SW-320-BDGA SWIFT MJ70-320 BODY SW-320-WGGA SWIFT 320 WING RH SW-320-WGGAH SWIFT 320 WING LH 19RM-WRAM WING LIFT RAM E500202S132132 CLAMP COLLAR PTO E500232S132132 CLAMP COLLAR PTO 15502-B CAT 1 TOP LINK MJ70-320/320FM - Hydraulics Item Part No. -
Page 49: Mj70-320 Body - General Assembly
MJ70-320 Body - General Assembly www.major-equipment.com... -
Page 50: Mj70-320 Body - General Assembly
MJ70-320 Body - General Assembly www.major-equipment.com... -
Page 51: Mj70-320 Body - Underbody Assembly
MJ70-320 Body - Underbody Assembly www.major-equipment.com... -
Page 52: Mj70-320 Body - Transmission And Height Adjuster
MJ70-320 BODY ROLLER MJ70-320-GBR18 BODY UNDERSIDE TROUGH 11RM-C10 COVER PIVOT MJ70-320-HYD05 HYDRAULIC BLOCK 11RM-C11 COVER PIVOT MJ70-320-STRP01 SWIFT CHAIN SLING 11RM-C16 MODIFIED OVAL GUARD SW-240-LM08 SPACER TUBE 725-BLD-FL 725 FIXED BLADE (Anti_Clk) SW-320-BD01 MJ70-320 BODY 725-BLD-FR 725 FIXED BLADE (Clk) -
Page 53: Mj70-320 Body - Parts List (Continued)
MJ70-320 Body - Parts List (continued) SW-320-HT01 HINGE TIE DSW34 DISC SPRING 34x16.3 x2 SW-320-LM01 SWIFT-320 LINKAGE MOUNT DIA 1" FLAT WASHER SW-320-LM01H MJ70-320 LINKAGE MOUNT FWM12 M12 FLAT WASHER SW-320-SM01 STRAP MOUNT (REAR) FWM12L M12 FLAT WASHER (LARGE) SW-320-SM01H... -
Page 54: Mj70-320 Wing - General Assembly And Height Adjuster
MJ70-320 Wing - General Assembly and Height Adjuster www.major-equipment.com... -
Page 55: Mj70-320 Wing - Underbody Assembly
MJ70-320 Wing - Underbody Assembly www.major-equipment.com... -
Page 56: Mj70-320 Wing - Parts List
MJ70-320 Wing - Parts List Item Part No. Description FWM16 M16 FLAT WASHER FWM20 M20 FLAT WASHER 11000RM-WSCRPR-01 11000 WING SCRAPER BAR FWM8 M8 FLAT WASHER 11GMROLW-V2 MJ70-270 WING ROLLER G1106 BRASS TAP CONNECTOR 725-BLD-FR 725 FIXED BLADE (Clk) I-257 3/4x1/2 REDUCER BUSH 8400RM-HG55 M20 ADJUSTER BLOCK... -
Page 57: Mj70-410Fm Body Flap Guards
MJ70 Winged Front Mounted Models MJ70-410FM Body flap guards Item Part No. Description MJ70-240-FMGF20 FLAP SUPPORT (FRONT) MJ70-270-FMGF02 FLAP PIVOT SHAFT DIA 5/8"x1 1/8"x1/2" COLLAR MJ70-240-FMGF03 80mm FLAP GUARD MJ70-240-FMGF04 60mm FLAP GUARD MJ70-320FM Body flap guards Item Part No. Description MJ70-240-FMGF20 FLAP SUPPORT (FRONT) -
Page 58: Mj70-410Fm Body
MJ70-410FM Body Item Part No. Description 3000T-AFBGA A' FRAME BUFFER MJ70-270-FMGF-BD FLAP GUARD BODY (270) MJ70-270-FMGF03 GUARD TUBE MJ70-320-STRP01 SWIFT CHAIN SLING MJ70-CW-SW20 SWIFT CASTOR (FRONT) SW-270-BDGA MJ70-270 BODY SW-270-LM20 LINKAGE MOUNT (FRONT) 3000T-AF-01 3000T A-FRAME SW-270-CV01 MJ70-270 BODY COVER... -
Page 59: Mj70-410Fm Wing Assembly
MJ70-410FM Wing Assembly Item Part No. Description MJ70-460-FMGF-WG FLAP GUARD WING (410) MJ70-460-FMGF16 GUARD TUBE (WING) MJ70-CW-SW01 SWIFT CASTOR (FRONT) SW-410-WGGA MJ70-410 WING MJ70-320-FMGF04 GUARD TUBE SUPPORT 111044 DIA 26-30mm INSERT FWM12 M12 FLAT WASHER M12 NYLOC NUT M12x30SZP M12x30 SET BOLT S4444 DIA 1 3/8"x2 1/8"x7/8"... -
Page 60: Mj70-320Fm Body
MJ70-320-FMGF-BD FLAP GUARD BODY (MJ70-320) AN099/10 LINCH PIN DIA 9.5 MJ70-320-HYD05 HYDRAULIC BLOCK FWM12 M12 FLAT WASHER MJ70-320-STRP01 SWIFT CHAIN SLING FWM20 M20 FLAT WASHER MJ70-CW-SW20 SWIFT CASTOR (FRONT) M12 NYLOC NUT SW-270-LM20 LINKAGE MOUNT (FRONT) M12x25SKBH M12x25 SOCKET BUTTON HEAD 10.9... -
Page 61: Mj70-320Fm Wing
MJ70-320FM Wing Item Part No. Description MJ70-320-FMGF-WG FLAP GUARD WING (MJ70-270) MJ70-320-FMGF16 GUARD TUBE (WING) MJ70-CW-SW20 SWIFT CASTOR (FRONT) SW-320FM-WGGA MJ70-320 WING MJ70-320-FMGF04 GUARD TUBE SUPPORT 111044 DIA 26-30mm INSERT FWM12 M12 FLAT WASHER M12 NYLOC NUT M12x25SKBH M12x25 SOCKET BUTTON HEAD 10.9... -
Page 62: Mj70-Cw-Sw01
MJ70-CW-SW01 Item Part No. Description MJ70-CW-020 MJ70 CASTOR YOKE MJ70-CW-025 CASTOR SPACER MJ70-CW-SW02 SWIFT CASTOR STAND RMCW-030 CASTOR AXLE RMCW-033 BEARING SPACER TUBE 6005 47x25x12 DEEP GROOVE 6005RS 47x25x12 DEEP GROOVE 8400RM3-LM15 LINKAGE SUPPORT (FRONT) RM2-L019 HEIGHT ADJUSTOR NYLON RM2-L020... -
Page 63: Mj70-Cw-Sw20
MJ70-CW-SW20 Item Part No. Description MJ70-CW-020 MJ70 CASTOR YOKE MJ70-CW-025 CASTOR SPACER MJ70-CW-SW21 SWIFT CASTOR STAND RMCW-030 CASTOR AXLE 6005 47x25x12 DEEP GROOVE 6005RS 47x25x12 DEEP GROOVE RMCW-033 BEARING SPACER TUBE 8400RM3-LM15 LINKAGE SUPPORT (FRONT) RM2-L019 HEIGHT ADJUSTOR NYLON RM2-L020... -
Page 64: Mj70-410T/550T
MJ70 Winged Trailed Models MJ70-410T/550T www.major-equipment.com... -
Page 65: Mj70-410T/550T - Parts List
DIA 1" FLAT WASHER 12DB-030 PTO STAND FWM12 M12 FLAT WASHER MJ70-TAX300 AXLE RAM STOP FWM20 M20 FLAT WASHER MJ70-TAX400 SWIFT TRAILED AXLE M10 NYLOC NUT MJ70-TAXM30 AXLE MOUNT (SWIFT) M10HEX M10 PLAIN NUT MJ70-TAXM30H AXLE MOUNT (SWIFT) M10x20SZP M10x20 SET BOLT... -
Page 66: Mj70-410T/550T - Hydraulics - Braked Axle
MJ70-410T/550T - Hydraulics - Braked Axle Item Part No. Description 14CROSS 1/4" M/M/M/M CONNECTOR 19RM-WRAM WING LIFT RAM 68-1132-00 1/4" VALVE BREATHER BQRF12 1/2" BRAKE Q-RELEASE FEMALE BRAKE RAM CRP1400 1/4" CRIMP (STRAIGHT) RIGHT WING "UP" CRP1490 1/4" CRIMP SWEPT (90 Deg) EDOW12 1/2"... -
Page 67: Mj70-410T/550T - Hydraulics - Axle With No Brakes
MJ70-410T/550T - Hydraulics - Axle with no brakes Item Part No. Description 14CROSS 1/4" M/M/M/M CONNECTOR 19RM-WRAM WING LIFT RAM 68-1132-00 1/4" VALVE BREATHER CRP1400 1/4" CRIMP (STRAIGHT) RIGHT WING "UP" CRP1490 1/4" CRIMP SWEPT (90 Deg) EDOW12 1/2" DOWTY WASHER EDOW14 1/4"... -
Page 68: Mj70 Blades
MJ70 Blades 725-BLD-L and 725-BLD-FL 725-BLD-R and 725-BLD-FR NOTE: Items 12 and 13 are supplied loose with the machine and can be used to lock the blades. It’s up to the user whether the machine will operate with swinging or rigid blades. Item Part No. -
Page 69: Mj70 Gearboxes
T27A - 267.245 - 1.92 Item Part No Description 1 T27/12 0.267.0300.00 CASING 2 T4A/6 8.0.1.00870 BEARING 6207 3 T27/2 8.5.2.00131 SNAP RING 72 UNI7437 4 T27/1 8.7.3.00055 OIL SEAL 35X72X10 5 T4A/4 0.259.7500.00 SHIM 35.3x48.0 6 LF135/7 8.5.1.00005 SNAP RING 35 UNI7435 7 T27/9 0.121.6000.00 CROWN WHEEL Z23 M5.3... - Page 70 LF205H-205 872-1.92 Item Part No Description 17 8.5.2.01358 8.5.2.01358 Snap Ring (52x55x2.5) 0.135.5000.00 0.135.5000.00 Crown Gear Z23 M5 18 LF135/13 8.6.6.00201 3/8" Gas Solid Plug 19 LF135/5 8.7.1.00748 Dust Lip 40x80x12 0.205.0302.00 0.205.0302.00 Casing LF135/18 0.135.2001.00 Input Shaft 20 8.7.3.00055 8.7.3.00055 Oil Seal 25x72x10 21 0.205.1300.00...
- Page 71 LF205TH-205.874-1.92 Item Part No Description 16 8.5.2.00955 8.5.2.00955 Snap Ring (LF135/3) 0.135.5000.00 0.135.5000.00 Crown Gear Z23 M5 17 85200648 8.5.2.00648 LF205/17 Circlip 18 8.6.6.00201 8.6.6.00201 Plug (LF135/13) 0.205.0303.00 0.205.0303.00 Casing (LF135/12) 8.7.1.00748 0.135.2002.00 0.135.2002.00 Shaft (LF135/25) 19 8.7.1.00748 Double Lip Seal (40X80X12V) (LF135/5) 0.135.6008.00 0.135.6008.00...
- Page 72 S3035230012-2.30 Item Part No Description CIRCLIP EXTERNAL 40x2.50 DIN471/2 11 339001040R THICK 1 290330503R HOUSING 3035 -R- D.123.5 12 354101035R BALL BEARING 35x72x17 6207 2 290330601R COVER 13 354101040DR BALL BEARING 40x80x18 6208 -SKF- 3 295030357R SHAFT 14 354107035R BEARING CUSC.6007 35x62x14 SF.D.Q. 4 298404008R SEALING LID 15 355038040R OIL SEAL 40x80x10 FPM/FKM SCREW HEX HEAD M8x25x1.25 UNI5739...
- Page 73 Warranty: This machine is guaranteed for 12 months. No warranty is given where the machine is being used as a hire machine. Warranty is against faulty workmanship or parts, with the exception of components not of MAJOR’S manufacture or design, i.e. hydraulic components, universally jointed shafts, chains and tyres, etc., which are subject to the original manufacturers conditions.
- Page 74 HEAD OFFICE Major Equipment Intl Ltd Ballyhaunis, Co Mayo Ireland Tel: +353 (0) 9496 30572 UK OFFICE Major Equipment Ltd Major Ind. Estate, Heysham, Lancs, LA3 3JJ, UK Tel: +44 (0) 1524 850501 Netherlands & Germany OFFICE Major Equipment Intl Ltd Postbus 29, NL-7700 AA Dedemsvaart, Nederland Tel: + 31 (0) 6389 19585...
