Summary of Contents for qpcom QP-W1510NUSB
- Page 1 User’s Manual QP-W1510NUSB 802.11n 2.4GHz, Wireless USB dongle With antena 2dBi www.qpcom.com...
-
Page 2: Information To User
Information To User Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Regulatory Information
REGULATORY INFORMATION WLAN Adapter must be installed and used in strict accordance with the instructions. This device complies with the following radio frequency and safety standards. USA - Federal Communications Commission (FCC) This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. - Page 4 Introduction Thank you for your purchase of the WLAN Adapter. Featuring wireless technology, this wireless networking solution has been designed for both large and small businesses, and it is scalable so that you can easily add more users and new network features depending on your business scale. FEATURES ...
-
Page 5: Wireless Lan Basics
Wireless LAN Basics Wireless LAN network defined by IEEE 802.11b/g standard committee could be configured as : Ad Hoc wireless LAN. Infrastructure wireless LAN. Ad Hoc network is a group of PCs installed with wireless LAN cards, this group of PCs is called a BSS (Basic Service Set). - Page 6 IP ADDRESS To use the WLAN Adapter with a computing device, the WLAN Adapter must be equipped with a proper Interface. All drivers and supporting software for the WLAN Adapter must be installed and configured first. Ask your system administrator for the following information, which you may need to provide during driver installation : ...
-
Page 7: Install Driver/Utility
Install Driver/Utility Warning! Do not cover or block the airflow to the adapter. The adapter will reach a high temperature during use. Windows XP/2K Step 1 : Insert the installation CD into your CD-ROM. Installation program will prompt language setup.Choose the Setup Language you would like to use and click Next button. - Page 8 Step3 : Click Install.
- Page 9 Step4 : Click Finish to complete installation.
-
Page 10: Windows Vista
Windows Vista Step 1 : Insert the installation CD into your CD-ROM. Installation program will prompt language setup.Choose the Setup Language you would like to use and click Next button. - Page 11 Step 2 : Welcome Installation dialog prompt shown. Click Next to continue. Click Cancel to close installation. Installing and configuring wlan utility. Step3 : Click Install.
- Page 12 Step4 : Click Finish to complete installation.
-
Page 13: Wireless Network Configuration
Wireless Network Configuration WLAN adapter uses its own management software. All functions controlled by users are provided by this application. When you insert the WLAN Adapter into your laptop or desktop, a icon should appear in the Windows System Tray automatically. Utility Icon ... -
Page 14: Profile Setting
PROFILE SETTING In profile tab, you can Add, Remove, Edit, Duplicate Set Default to manipulate profile content manually. Strongly recommend to use profile after you do Available Network. - Page 15 AVAILABLE NETWOEK SETTING Click Available Network tab and it will show all available networks that radio can reaches. Select proper SSID & BSSID you want to connect. Click Refresh button to force and rescan available networks currently. Select one of SSIDs, and click Add to Profile to create profile that can be configured more wireless parameters.
- Page 16 In this page, you can edit your profile name, configure wireless security like WEP, WPA, WPA2, 802.1x …etc. After finishing setup, click button to save configuration.
- Page 17 Status Status page tab, shows all wireless, networking and device driver version in details.
- Page 18 Statistics Statistics page tab will show real-time TX/RX relative counters to check or evaluate the wireless performance. Click Reset button to set counter to zero.
-
Page 19: Wi-Fi Protected Setup
Wi-Fi Protected Setup An easy and secure setup solution for Wi-Fi network. you can choose PIN Code or Push Button method to connect to an AP. -
Page 21: Technical Specifications
Technical Specifications Product Name Wireless LAN 11n USB Adapter Chipset Realtek RTL8188SU Standard IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Frequency Band 2.4GHz ~ 2.484GHz unlicensed ISM band IEEE 802.11b : DSSS Spread Spectrum IEEE 802.11g : OFDM IEEE 802.11n : OFDM Modulation BPSK, QPSK, 16QAM, 64QAM IEEE 802.11b : 1, 2, 5.5, 11Mbps... -
Page 22: Troubleshooting
Troubleshooting Symptom : The LED is off. Make sure the PC Card is inserted properly. Otherwise contact your Remedy : vendor. Symptom : The LED is always on not blinking. Make sure that you have installed the driver from attached CD. Remedy : Otherwise contact your vendor. - Page 23 Glossary 1. IEEE 802.11 Standard The IEEE 802.11 Wireless LAN standards subcommittee, which is formulating a standard for the industry. 2. Access Point An internetworking device that seamlessly connects wired and wireless networks together. 3. Ad Hoc An Ad Hoc wireless LAN is a group of computers, each with a WLAN adapter, connected as an independent wireless LAN.
- Page 24 flaws of WEP. 18. Transmission Control Protocol / Internet Protocol (TCP/IP) TCP/IP is the protocol suite developed by the Advanced Research Projects Agency (ARPA). It is widely used in corporate Internet works, because of its superior design for WANs. TCP governs how packet is sequenced for transmission the network.
- Page 25 29. WPA2 It is the second generation of WPA. WPA2 is based on the final IEEE 802.11i amendment to the 802.11 standard. 30. Temporal Key Integrity Protocol (TKIP) The Temporal Key Integrity Protocol, pronounced tee-kip, is part of the IEEE 802.11i encryption standard for wireless LANs.
