Summary of Contents for MeritRC MT-602
- Page 1 MT-602&MR-600 2.4GHz Radio Control System Instruction Manual CH2 D/R CH1 D/R...
- Page 2 Antenna Hook 3-position Carrying bar 2-position switch(CH6) switch(CH5) CH2 D/R CH1 D/R switch switch Up position D/R-OFF Down position D/R-ON Elevator(Mode 1) Throttle(Mode 1) CH2 D/R CH1 D/R Throttle(Mode 2) Elevator(Mode 2) Trim Lever Trim lever Elevator(Mode 1) Throttle(Mode 1) Throttle(Mode 2) Elevator(Mode 2) /Rudder stick...
- Page 3 ADJUSTMENT AND INSTALLATION Connections The diagram shown is for aircraft models only.Additional servos may have to be purchased separately. To Battery NOTE:NEVER use dry battery as it cause malfunction. (The Y connector is sold separately) Switch Harness Flap Servo (CH6) Gear Servo Receiver (CH5)
- Page 4 MT-602 (Rear and Side Panel) TRANSMITTER MR-600 RECEIVER...
- Page 5 Special note for 2.4GHz FHSS radio system setup Receiver ’s Antenna installation coaxial part...
- Page 6 Transmitter antenna FCC Compliance Statement WARNING The distance close to the finger usually should be 78mm.
- Page 7 Binding Setup(Pair Procedure) Programming a receiver to recognize the code of only one specific transmitter. If you change transmitters or add a receiver, you must re-bind before operating your model. 1. Place the transmitter and the receiver close to each other (within one meter). Turn the power switch on the transmitter to the ON position.
- Page 8 2.Walk away from the model while simultaneously operating the controls.Have an assistant stand by the model and signal what the controls are doing to confirm that they operate correctly.You should be able to walk approximately 30 - 50 paces from the model without losing control. 3.If everything operates correctly,return to the model.Set the transmitter in a safe,yet accessible location so it will be within reach after starting the engine.
- Page 9 ELEVON & V-TAIL MIXING FUNCTIONS The Elevon and V-tail mixing functions which can be turned on or off 。Ele- -von control consists of a mixture between the elevator and aileron channels。 V-tail control consists of mixture between the elevator and rudder channels。 The default setting for all mixing will be off the GREEN LED should be on steady。...
- Page 10 V-tail Mixing Intended for V-tail aircaft,V-tail mixing allows the ruddervators to operate both as rudders and elevators.The same as the other mixes,V-tail mixing requires that each ruddervator be operated by a separate servo. *If necessary,use the Servo Reversing function to achieve the correct direction of servo throws.
-
Page 11: Transmitter Operation And Movement Of Each Servo
Transmitter Operation and Movement of Each Servo AILERON OPERATION Aileron(CH1) Left Right Left Right ELEVATOR OPERATION Elevator(CH2) Down Down Down (Mode 1) (Mode 2) Throttle(CH3) THROTTLE OPERATION High High High (Mode 1) (Mode 2) RUDDER OPERATION Rudder(CH4) Left Light Left Right... - Page 12 WARNING Connector Connection Servo Thr ow Receiver Vi brationpr oofing / Waterpr oofing Servo Installation Receiver Antenna <Antenna installation> Power Switch Installation...
