  • Page 1 User’s Guide W2040S W2240S W2340S ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 4 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
  • Page 5 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 6 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Power Cord User's Guide/Cards 15-pin D-Sub Signal Cable (To set it up, this signal cable may be attached to this product before shipping out.) NOTE...

  • Page 7: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the Stand Base(Front, Rear) into the Stand Body in the correct direction.

  • Page 8: Disassembling The Stand

    Connecting the Display Disassembling the stand Put a cushion or soft cloth on a flat Place the monitor face down on surface. the cushion or soft cloth. Change your lock on the product as it follows and turn it in the arrow direction. If you can't release the stand base even the locking rib is at a release position, Please push the indicated rib down and retry it.
  • Page 9 Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5 ~15 Do not touch or press the screen when adjusting the angle of the monitor.
  • Page 10 Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.

  • Page 11: Control Panel Functions

    Control Panel Functions Front Panel Controls MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear. You can unlock the OSD controls at any time by pushing the MENU button for several seconds.
  • Page 12 Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is W2040S : 1600 x 900 W2240S : 1920 x 1080 W2340S : 1920 x 1080 Exit the OSD (On Screen Display).

  • Page 13: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.

  • Page 14: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Supported input Description To adjust the brightness, contrast BRIGHTNESS PICTURE DSUB and sharpness of the screen CONTRAST SHARPNESS COLOR TEMP To customize the color of the...
  • Page 15 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 16 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST To adjust the clearness of the screen. SHARPNESS Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu...
  • Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To move image left and right. HORIZONTAL To move image up and down. VERTICAL To minimize any vertical bars or CLOCK stripes visible on the screen background. The horizontal screen size will also change.
  • Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description OTHERS To choose the language in which the LANGUAGE MENU OTH ERS control names are displayed. Use this function to set the power LANGUAGE ENGLISH POWER indicator on the front side of the monitor POWER INDICATOR INDICATOR WHITE BALANCE...
  • Page 19 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MODE Button, then the main menu of the OSD appears.
  • Page 20 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description Select this when you want to use the product NORMAL in the most general using environment. Select this when you are watching a video or MOVIE movie. INTERNET Select this when you are working on the document (Word etc.) This is used for advertising in the store.
  • Page 21 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description Switch to full screen mode according to WIDE input image signal. Change the input image signal ratio to ORIGINAL original. * This function works only if input resolution is lower than monitor ratio (16:9).

  • Page 22: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears • Check and see if the power cord is connected Is the power cord of the properly to the power outlet. display connected? • Press the Power button. Is the power indicator light on? •...
  • Page 23 Troubleshooting Display image is incorrect • Press the AUTO button to automatically adjust Display Position is your display image to the ideal setting. incorrect. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.
  • Page 24 Troubleshooting Display image is incorrect • Check if the signal cable is properly connected The screen color is and use a screwdriver to fasten if necessary. mono or abnormal. • Make sure the video card is properly inserted in the slot. •...

  • Page 25: Specifications

    Specifications W2040S 20.0 inches (50.8 cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating Visible diagonal size : 50.8 cm 0.2766 x 0.2766 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
  • Page 26 Specifications W2240S 21.5 inches (54.6 cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 x 0.248 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
  • Page 27 Specifications W2340S 23 inches (58.4 cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating Visible diagonal size : 58.4 cm 0.266 x 0.266 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
  • Page 28 Specifications Preset Modes (Resolution) W2040S Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.123 1024 x 768 67.500...
  • Page 29 Digitally yours...
