Crown Food Service Equipment ELTM Series Installation & Operation Manual

Electric self generating single and twin mixer kettles
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: ____________________
INSTALLATION & OPERATION
MANUAL
Single and Twin Mixer Kettles
LTM-40-(2)
LTM-60-(2)
LTM-80-(2)
LTM-100-(2)
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read
the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
y
A Middleby Compan
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
www.crownsteamgroup.com
Printed in Canada
MANUAL 10041R4
