- Page 1 All manuals and user guides at all-guides.com User Manual TL-RKPS-01 Integrated Switching Power Supply All Rights Reserved Version: TL-RKPS-01_170525...
- Page 2 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Preface Read this user manual carefully before using this product. Pictures shown in this manual are for reference only, slight differences may be evident on the real product. This manual is only for operation instruction only, not for any maintenance usage. Trademarks Product model and logo are trademarks.
- Page 3 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. l Unpack the equipment carefully and save the original box and packing material for possible future shipment l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
- Page 4 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual IMPORTANT SAFETY INSTRUCTIONS Read these instructions – All the safety and operating instructions should be read before this product is operated. Keep these instructions – The safety and operating instructions should be retained for future reference.
- Page 5 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual 13. Unplug the apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 6 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual the terminals requires installation by an instructed person or the used of ready- made leads or cords. 22. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
- Page 7 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual - The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. Protective earthing terminal. The apparatus should be connected to a mains socket outlet with a protective earthing connection.
-
Page 8: Table Of Contents
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Contents 1. Introduction ............................. 1 1.1 Brief Introduction ........................ 1 1.2 Features ..........................1 1.3 Package List .......................... 1 2. Panel Description ........................... 2 2.1 Front Panel ........................... 2 2.2 Rear Panel ..........................2 3. -
Page 9: Introduction
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual 1. Introduction 1.1 Brief Introduction The product is an integrated switching power supply designed for converting AC into DC power. It provides 2 input channels and 12 output channels, input voltage 100~240VAC, output 5/12/24VDC, the max power consumption of single channel is 15W. -
Page 10: Panel Description
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual 2. Panel Description 2.1 Front Panel Name Description FIRMWARE USB port for updating system firmware. ① Input AC source indicators. Green when the device is powered on and normal output. AC1 &... - Page 11 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Name Description 12 output channals. DC: 2-Pin phoenix connector, connect with the device needed to be powered. SELECT: Press the TACT Switch to select the output voltage among 5V, 12V, and 24VDC. In addition, simultaneously long-press this buttons on channel 01 and channel 02 for 3 seconds or more, the device will be restored to factory setting.
-
Page 12: System Connection
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual 3. System Connection 3.1 Usage Precautions System should be installed in a clean environment and has a prop temperature and humidity. All of the power switches, plugs, sockets and power cords should be insulated and safe. -
Page 13: System Operations
All manuals and user guides at all-guides.com TL-PKPS-01 User Manual 4. System Operations 4.1 Front Panel Buttons Switch on/off output channel: Press the button 01~12 on front panel to switch on/off the corresponding output channel. Lock/unlock output channel: Long-press the button 01~12 for 3 seconds or more on front panel to lock/unlock the corresponding channel, and then the corresponding LED will flash 3 times. -
Page 14: Rs232 Communication Commands
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual The interface of the control software is showed as below: Parameter Configuration area Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. - Page 15 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Command Function Feedback Example Switch on the output channel [x], [x]@! [x] Open. =1~12. Switch off the output channel [x], [x]$! [x] Closed. =1~12. When y = NULL, Set the output voltage as x for all output channels.
- Page 16 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Command Function Feedback Example Over N N N N N N N N N N N N Lock N N N N N N N N N N N N When x =NULL, clear the data of all Clear All.
- Page 17 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Command Function Feedback Example 01 02 03 04 05 06 07 08 09 10 11 State S S S S S S S S S S S S 12 12 12 12 %9975.
- Page 18 All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Command Function Feedback Example Modify product model. The command has 18 bytes in total, and FB XX XX XX XX 16 bytes are effective. The digit 0 is XX XX XX XX XX used for padding.
-
Page 19: Web-Based Gui Control
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual 4.3 Web-based GUI Control In addition to control the product via front panel button and RS232 communication software. This product can be controlled via web-based GUI. It allows users to interact with the product through graphical icons and visual indicators. -
Page 20: Control Menu
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual 4.3.1 Control Menu Type user name: user and password: user (default setting) on the log-in interface, and then click Login to enter Control menu shown as below: Select the ON/OFF to switch on/off the output channel. Click the All On to switch on all output channels. -
Page 21: Voltage Setting Menu
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual Click the All Off to switch off all output channels. 4.3.2 Voltage Setting Menu Click Voltage Setting on the top of page to enter voltage setting menu shown as below: In this interface, you can select 5V, 12V, or 24V for each output channel. -
Page 22: Password Menu
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual In this interface, dynamic or static IP mode can be selected. Under static IP mode, IP address and subnet mask, gateway can be set and make sure the IP addresses are different to avoid IP conflict. -
Page 23: Web-Based Gui Update
All manuals and user guides at all-guides.com TL-RKPS-01 User Manual In this interface, the password can be modified as you need. 4.3.5 Web-based GUI Update Web-based GUI for the Scaler Switcher supports online update in http://192.168.0.178:100. Type the username and password (the same as the GUI log- in settings, modified password will be available only after rebooting) to log in the configuration interface. -
Page 24: Specification
All manuals and user guides at all-guides.com TL-PKPS-01 User Manual 5. Specification Input & Output Input Port AC1 & AC2 Input Voltage 100~240VAC 50~60Hz Output Port Total 12 DC port (2-Pin phoenix connectors) Output Voltage 5V, 12V or 24V can be selectable. 12V is default 5V: 4.75~5.25V... -
Page 25: Panel Drawing
All manuals and user guides at all-guides.com TL-PKPS-01 User Manual 6. Panel Drawing 437 mm FIRMWARE AC 1 AC 2 AC100V 240V AC100V 240V SELECT SELECT SELECT SELECT SELECT SELECT SELECT SELECT SELECT SELECT SELECT SELECT RS232 TCP IP www.tlnetworx.com... -
Page 26: Troubleshooting & Maintenance
All manuals and user guides at all-guides.com 7. Troubleshooting & Maintenance Problems Causes Solutions Power supply protect function Please reduce loads. will start when over loaded. After selecting output voltage, Switch output No output voltage the output channel will switch channel via front panel off automatically. - Page 27 All manuals and user guides at all-guides.com Cannot control the device by RS232 / The device has already been Send authorized front panel broken. dealer for repairing. buttons/web-based GUI. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support.
-
Page 28: After-Sales Service
All manuals and user guides at all-guides.com 8. After-sales Service If there appear some problems when running the device, please check and deal with the problems referenced in this user manual. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for three years.
