- Page 1 User’s Guide W2243C ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.
-
Page 2: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
- Page 4 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
- Page 5 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
-
Page 6: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the Stand Base(Front, Rear) into the Stand Body in the correct direction. -
Page 7: Disassembling The Stand
Connecting the Display Disassembling the stand Put a cushion or soft cloth on a flat Place the monitor face down on surface. the cushion or soft cloth. Change your lock on the product as it follows and turn it in the arrow direction. If you can't release the stand base even the locking rib is at a release position, Please push the indicated rib down and retry it. -
Page 8: Positioning Your Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range: -5˚~15˚... -
Page 9: Using The Computer
Connecting the Display Using the Computer Make sure to turn off the computer and product. Connect the cable as below sketch map form Connect D-sub Cable (PC) Connect D-sub Cable (Mac) NOTE This is a simplified representation of the rear view. This rear view represents a general model;... -
Page 10: Using The Cable Holder
Connecting the Display Using the cable holder (This feature is not available in all models.) Cable holder... -
Page 11: Control Panel Functions
Control Panel Functions Front Panel Controls Control Function Use this button to enter 4:3 IN WIDE, PHOTO EFFECT Button items, for more information, refer to page A17. Use this button to enter or exit from the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that these settings are not inadvertently changed. - Page 12 Screen Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is: W2243C: 1920 x 1080 Power Button Use this button to turn the display on or off. Power Indicator This Indicator lights up as red when the display is operating normally(On Mode).
-
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. -
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Reference 4:3 IN WIDE To adjust the image size NORMAL GAUSSIAN BLUR PHOTO To adjust screen color mode EFFECT SEPIA MONOCHROME... - Page 15 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
- Page 16 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE PICTURE To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50/0/50 GAMMA On the monitor, high gamma values display whitish images and low gamma values display high contrast images.
- Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING TRACKING To move image left and right. HORIZONTAL To move image up and down. VERTICAL To minimize any vertical bars or CLOCK stripes visible on the screen background. The horizontal screen size will also change.
- Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description SETUP SETUP To choose the language in which the LANGUAGE control names are displayed. To adjust position of the OSD window POSITION on the screen. If the output of the video card is different WHITE BALANCE the required specifications, the color...
- Page 19 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the button on the right bottom of the monitor. Main menu Sub menu Description 4:3 IN WIDE To select the image size of the screen. WIDE •...
- Page 20 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the button on the right bottom of the monitor. Menu Name Icons Sub-menu Name Main menu Sub menu Description MOVIE This feature lets you easily select the best desired INTERNET image condition optimized to the environment (ambient illumination, image types etc).
-
Page 21: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected properly to the power outlet. display connected? Is the power indicator •... -
Page 22: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. -
Page 23: Have You Installed The Display Driver
Troubleshooting Display image is incorrect ❁ The screen color is • Check if the signal cable is properly connected and use a screwdriver to fasten if necessary. mono or abnormal. •Make sure the video card is properly inserted in the slot. •Set the color setting higher than 24 bits (true color) at Control Panel -Settings . -
Page 24: Specifications
Specifications W2243C 21.5 inches (54.6 cm) Flat Panel Active matrix-TFT LCD, Anti- Display Glare coating Visible diagonal size: 54.6 cm 0.248*0.248 mm pixel pitch Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) -
Page 25: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) W2243C Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.123 1024 x 768 67.500... -
Page 26: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Change your lock on the product as it follows and turn it in the arrow direction. Install the Wall mount plate. - Page 27 Digitally yours...
