User's Guide
W2363V
M
ake sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for future reference.
S
ee the label attached on the product and give the information to your
dealer when you ask for service.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W2363VV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG W2363VV

Summary of Contents for LG W2363VV

  • Page 1 User’s Guide W2363V ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
  • Page 4 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 5: On Disposal (Only, Hg Lamp Used Lcd Monitor)

    Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 6 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. User's Guide/Cards Power Cord (Depending on the country) DVI-D Signal Cable 15-pin D-Sub Signal Cable (This feature is not available (To set it up, this signal cable may in all countries.)

  • Page 7: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting and Disassembling the stand Place the monitor face down on the soft cloth. Assemble the Stand Base into the Stand Body in the correct direction. Make sure you push the Stand Base until the end.
  • Page 8 Connecting the Display Turn the screw to the right to fix the Stand Body to the Stand Base. Screw Turn the screw by using the screw handle. Then fold the screw handle flat. Once assembled take the monitor up carefully and face the front side. To disconnect the Stand Base from the Stand Body, unfold the screw handle and turn it to the left.

  • Page 9: Positioning Your Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range: -5˚~15˚...

  • Page 10: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.
  • Page 11 Connecting the Display Press the Power Button ( ) on the front panel to turn the power on. When monitor power is turned on, the 'Self Image Setting Function' is executed automatically. (Only Analog Mode) NOTE ‘ Self Image Setting Function’? This function provides the user with optimal display settings.When the user connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual input signals.

  • Page 12: Control Panel Functions

    Control Panel Functions Front Panel Controls Use this button to enter THRU MODE,SRS Button TRUSURROUND HD,ARC or AUTO BRIGHT menus. For more information, refer to page 14. When two or more input signals are connected, SOURCE Button first monitor automatically detects one signal as main input, then you can select the input signal (DSUB/DVI/HDMI1/HDMI2/COMPONENT) you want.

  • Page 13: Auto Image Adjustment

    Control Panel Functions Buttons Use these buttons to select or adjust functions in the On Screen Display. Use this button you can directly use PIP function. You can use PIP menu to select PIP input. For more information, refer to page 21. When two input signals are connected, one is main input, SWAP the other is PIP input.

  • Page 14: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.

  • Page 15: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Reference THRU MODE Use Frame-Buffer to prevent picture delay SRS TRUSURROUND HD Use 3D surround for live sound effect Use aspect ratio control AUTO BRIGHT To control screen brightness automatically...

  • Page 16: Srs Trusurround Hd

    On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the button on the front of the monitor. Menu Name G-MODE Icons MENU : Save & Exit : Move Sub-menu Name THRU MODE Main menu Sub menu Description THRU MODE G-MODE...

  • Page 17: Auto Bright

    On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description G-MODE The picture will be displayed depends on Input resolution.No Scaling.If 640x480 resolution input, the picture will just display 640x480 size even FULL though the 1920x1080 size panel. Original The picture will be displayed with input resolution ratio scaling.
  • Page 18 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.

  • Page 19: Black Level

    On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE PICTURE To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50/0/50 GAMMA On the monitor, high gamma values display whitish images and low gamma values display high contrast images.
  • Page 20 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description COLOR COLOR • sRGB: Set the screen color to fit the PRESET SRGB standard color specification. • 6500K: Slightly reddish white. • 9300K: Slightly bluish white. USER Set your own red color levels. Set your own green color levels.
  • Page 21 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING TRACKING To move image left and right. HORIZONTAL DSUB input To move image up and down. VERTICAL To minimize any vertical bars or CLOCK stripes visible on the screen background.
  • Page 22 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To choose the language in which the SETUP LANGUAGE SETUP control names are displayed. To adjust position of the OSD window POSITION on the screen. If you set ON, you enable the Response Time Control function.

  • Page 23: Pip Input

    On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PIP ON/OFF To select PIP on or off. * It supports only for HDMI input in RGB PIP ON/OFF (D-sub analog signal) mode. PIP INPUT * The combinations of main screen and sub-screen (PIP) available are as shown PIP POSITION below:...

  • Page 24: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •...

  • Page 25: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is • Press the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.

  • Page 26: Have You Installed The Display Driver

    Troubleshooting Display image is incorrect The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot. •...

  • Page 27: Specifications

    Specifications Display 23.0 inches (58.4 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size: 58.4 cm 0.265*0.265 mm pixel pitch Horizontal Freq. Analog,Digital : 30 - 83 KHz (Automatic) Sync Input HDMI : 30 - 83 KHz (Automatic) Vertical Freq.

  • Page 28: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) DSUB/DVI Timing Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 X 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.123 1024 x 768...
  • Page 29 Specifications Preset Modes (Resolution) Component Video Timing Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 15.75 480i 15.62 576i 31.50 480P 31.25 576P 37.50 720P 45.00 720P 28.12 1080i 33.75 1080i Indicator LED Color MODE Blue On Mode Blue Blinking Sleep Mode Off Mode...

  • Page 30: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor face down on the soft cloth. To disconnect the Stand Base from the Stand Body, unfold the screw handle and turn it to the left.
  • Page 31 Installing the Wall mount plate Install the Wall mount plate. Wall mount plate(Separate purchase) This is stand-type or wall mount type and is connectable with Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased.
  • Page 32 Digitally yours...
