- Page 1 PSV40U Bench Power Supply AC-to-DC Power Converter with USB Charge Port, LCD Digital Display, Adjustable Voltage (4 Amp)
-
Page 2: Power Supply Features
FEATURES Your PYRAMID Heavy-Duty 4-Amp Switching DC Power Supply is designed to use AC power-to-power equipment that requires 12V DC automotive power. The power supply converts standar 120V AC household power to 1.5V-15V DC power and can supply up to 4-Amp of continuous power. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS DANGER: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS. WARNING: This unit should not be directly connected to a battery for charging or for battery back-up. Battery charging and battery back-up may be undertaken only when the battery is connected through suitable external isolating diodes and charge limiting resistor. - Page 4 CAUTION: TO REDUCE THE RISK OF DAMAGE • Do not expose the power supply to rain or excessive moisture. • Do not operate the power supply if it has been dropped or damaged in any way. Take it to a qualified service technician for repair. •...
- Page 5 CONNECTIONS Caution: Make all other connections before you connect the power supply standard AC power. 1. Power ON/OFF: Set the power supply's POWER switch to ON or OFF. 2. Amperes: Do not use with equipment requiring more than 50amp. 3. USB Charge (5V/2A): USB Charge Support Works with All of Today's Latest Devices 4.
-
Page 6: Operation
• Insert the device's positive wire (usually red) into the red binding post's wire hole, then tighten the binding post's sleeve to secure the wire in place. • If you are using the banana plugs connection, insert the plugs into the terminal's jack. - Page 7 • Rugged & Durable Housing Construction, Cabinet Heatsink • Used for Component & Device Equipment Testing, Operation & Performance • Pyramid Compact Hobby Power Supplies Safe for Tabletop Placement Technical Specs: • Continuous Power: 4 Amp, Max. • Adjustable Voltage Power: 1.5 - 15V (4 Amp DC) •...
