READ AND SAVE THESE INSTRUCTIONS The Installer must leave these instructions with the homeowner. The homeowner must keep these instructions for future reference and for local electrical inspec- tors’ use. READ THESE INSTRUCTIONS BEFORE YOU START INSTALLING THIS RANGEHOOD WARNING: - TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: Never leave surface units unattended at high settings. - Page 4 W A R N I N G • Venting system MUST terminate outside the home. • DO NOT terminate the ductwork in an attic or other enclosed space. • DO NOT use 4" laundry-type wall caps. • Flexible-type ductwork is NOT recommended. •...
- Page 5 WARNING - TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PER- SONS, OBSERVE THE FOLLOWING: Installation Work And Electrical Wiring Must Be Done By Qualified Person(s) In Accordance With All Applicable Codes And Standards, Including Fire-Rated Construction. Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of fuel burning equipment to prevent backdrafting.
-
Page 6: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS The Instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION • The manufacturer will not be held liable for any damages resulting from incor- rect or improper installation. -
Page 7: Dimensions And Main Parts
DIMENSIONS and MAIN PARTS Dimensions The exhaust is 4" on center off of the wall 4-15/16" 3-5/16" 35-7/16" - 43-5/16" 8-4/16" 24" minumum Ø 5-14/16" Components Ref. Qty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Telescopic Chimney comprising: Upper Section Lower Section Damper... -
Page 8: Installation
INSTALLATION Wall drilling and bracket fixing Wall marking: • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the center of the area in which the hood will be installed. • Draw a horizontal line at 24” above the cooktop for installation without the back panel, or at height H (height of the visible part of the panel) for installation with the back panel. - Page 10 1 10...
- Page 11 Mounting the hood body • Hook the hood body onto the screws 12a. • Fully tighten the support screws 12a. Note: The Hood body should be secured to wall studs. If necessary, install a wood support behind the dry wall, flush mounted between 2 studs. This will provide the necessary structure and support for mounting.
- Page 12 For the 36" ELECTRICAL CONNECTION Knockout is located in the junction box on the left side of the hood facing the front approx. 9-3/8" from • Remove the cover from the Field Wiring Com- the left to the right and 3-3/8" up from the bottom of partment with a Phillips screwdriver.
-
Page 13: Use
Control Board Light Switches the lighting system on and off Motor Switches the extractor motor on and off Speed Sets the operating speed of the extractor: 1. Low speed, used for a continuous and silent air change in the presence of light cooking vapor. -
Page 14: Care
CARE Metal grease filters CLEANING METAL SELF- SUPPORTING GREASE FILTERS • The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. • Remove the filters one at a time by supporting them with one hand and turning the safety knobs (pull and turn). - Page 15 991.0272.134_04 - 05042013...
