Summary of Contents for SportsPlay 381-403H
- Page 1 381-403H WHEELCHAIR SWING Installation Guide INSTALLATION INSTRUCTIONS 381-403H ACCESSIBLE WHEELCHAIR SWING Please read the entire manual before beginning installation. 1 CTN 5 PIPE 2 WF 8 TOTAL PCS 148# WEIGHT CLASS 70...
- Page 2 381-403H WHEELCHAIR SWING Installation Guide...
- Page 3 381-403H WHEELCHAIR SWING Installation Guide...
- Page 4 This equipment has been designed for use under STRICT CONTROL BY AN environment away from heat, moisture and sunlight. SportsPlay ADULT. This Equipment does not meet the standards set by ASTM and is recommends carefully unpacking the unit and taking an inventory before designed to allow people who are bound to a wheelchair so swing.
- Page 5 381-403H WHEELCHAIR SWING Installation Guide Before you begin Review your swing footing and top view drawings to ensure your site is large enough. Read through the entire instruction booklet before beginning the actual installation. Before you begin preparing the site or digging any holes you must first contact you local utility companies so they can visit the site and mark all of the buried utilities.
- Page 6 100 Bar harbor drive West Conshohocken PA, 19428-2959 Because accidental falls are likely to occur around play equipment, SportsPlay Equipment Inc. recommends that a resilient safety surfacing that will meet standard ASTM F1292 be placed under and around the structure and extend Call –...
- Page 7 381-403H WHEELCHAIR SWING Installation Guide Tools and Materials Files and sand paper List is for tools and materials needed that are not included with the Safety surfacing playground Spray paint to mark holes Follow manufacturer’s guidelines for proper use of tools and materials.
- Page 8 All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:...
- Page 9 381-403H WHEELCHAIR SWING Installation Guide FOOTING SIDE VIEW Step 1: Layout Lay structure in the desired location using the top view layout drawing. Measure from each post to ensure there is adequate space for any component and the components fall zone. This drawing is a standard drawing and does not represent the actual playground you are installing.
- Page 10 381-403H WHEELCHAIR SWING Installation Guide SportsPlay recommends having a CPSI (certified playground safety Step 3: Post & Component Installation inspector) present during installation. If that’s not possible you should have the completed playground (after surfacing is in place) inspected by We recommend installing the posts once the post are square and level a CPSI.
- Page 11 381-403H WHEELCHAIR SWING Installation Guide Other Installation Tips If you are mocking up components with the intention of removing the hardware at some point, you may want to apply lubricating oil to the hardware. Stainless steel hardware has a tendency to seize so if you are planning on removing the hardware you may want to apply lubricant to prevent this.
- Page 12 381-403H WHEELCHAIR SWING Installation Guide Make sure there are no unsafe modifications (especially ropes tied to SUPERVISION GUIDE equipment). Remove all unsafe modifications and close the equipment for play until they are removed. This equipment has been designed for use under STRICT CONTROL BY AN ...
- Page 13 381-403H WHEELCHAIR SWING Installation Guide Once the is unsnapped of removed, then the front entry platform must be unsnapped from the chain assembly and pulled down. Once the front platform/chain assembly is pulled down, the wheelchair should be placed or rolled onto the platform (Handles facing short platform).
- Page 14 381-403H WHEELCHAIR SWING Installation Guide ½ X ½ SET 3/16 ALLEN WRENCH (YELLOW BAG) SCREW D-SHACKLE 2 3/8” SWING HANGER ¼ ALLEN WRENCH (BLUE BAG) 5/16 LOCK 5/16 X 1 BUTTON WASHER HEAD NUT 5/16 X 2 ½ BUTTON 5/16 ALLEN WRENCH (RED BAG)
- Page 15 381-403H WHEELCHAIR SWING Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...
-
Page 16: Installation Details
381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION DETAILS Recommended crew (Adult): 2 Installation time: 4 hr User age: 5-12 Use zone: 20’ x 32’ Weight: 148 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required. -
Page 17: Parts List
381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 383-511 Swing End 1 7/8” x 11’ Pipe 583-601A 2 3/8” x 4’ Pipe 383-220 2 3/8” Swing Hanger 585-520 342-506 D Shackle ½” x ½” Socket Set Screw 196-802 5/16”... - Page 18 381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION FOOTING INFORMATION Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
- Page 19 3381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT VIEW April 8, 2020...
-
Page 20: Specifications
381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING Apply locktite to all bolts during assembly prior to Tube – FloCoat® Galvanized 1 7/8” O.D. and 2 3/8” O.D. completely tightening them. Hardware – Stainless steel & tamper resistant ... -
Page 21: Before You Begin
381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:... - Page 22 381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Swing Hangers: You will need two swing hangers (4), two D Shackles (5). Assemble the D-shackles and chain to the swing hangers. Attach the swing hangers to the top rail following spacing on page 4.
- Page 23 381-403H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __10) Once the concrete has set, back fill dirt over the footing holes; inspect the area and components for tools, hazardous debris and sharp edges. Verify all components are installed and all hardware is tight and then install the safety surfacing.
