Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
If you have any questions, visit :
http://shop.panasonic.com/support
Register online at http://shop.panasonic.com/support (U.S. customers only)
P
Blu-ray Disc
Model No.
Firmware updates
Panasonic is constantly improving the unit's firmware to ensure
that our customers are enjoying the latest technology.
Panasonic recommends updating your firmware as soon as you
are notified.
For details, refer to "Firmware updates" (
http://panasonic.jp/support/global/cs/ (This site is in English only.)
Owner's Manual
TM
DP-UB820
18) or
Player
TQBS0258-1
