MODEL EQ-1
EQ-1-D
© and
(1983-MSRP $149.00)
OWNER'S MANUAL AND
INSTALLATION GUIDE
EQUALIZER
INTRODUCTION
The EQ-1 and EQ-1-D© is 6 band equalizer with input level gain matching for the
source unit. Each band of equalization is controlled by a precision slider control,
with the controlled frequencies chosen to give the best over response from your
car stereo equipment.
TECHNICAL DESCRIPTION
Power SUPPLY:
The EQ-1 and EQ-1-D© include internal suppression for freedom from external
noise. A unique ultrasonic inverter provides a negative 14 volts to facilitate the
unusual high output voltage. The EQ-1 and EQ-1-D are fully protected against
accidental power reversal.
CONSTRUCTION FEATURES:
All components are securely mounted to a rugged two piece glass-epoxy printed
circuit board assembly, minimizing internal wiring which could vibrate loose. A
heavy aluminum extrusion and precision machined faceplates combine to form a
rugged unitized chassis. All construction and assembly is performed in-house,
insuring highest quality, and each unit is fully tested, inspected, and re-tested
before shipping.
© 2008 Linear Power, Inc. - ALL RIGHTS RESERVED
1
LINEAR POWER™ is a trademark of Linear Power, Inc.
Advertisement
Table of Contents
Related Manuals for Linear Power EQ-1
Summary of Contents for Linear Power EQ-1
- Page 1 EQUALIZER INTRODUCTION The EQ-1 and EQ-1-D© is 6 band equalizer with input level gain matching for the source unit. Each band of equalization is controlled by a precision slider control, with the controlled frequencies chosen to give the best over response from your car stereo equipment.
- Page 2 INSTRUCTIONS Read the following instructions completely through. If it appears too complicated, we recommend that you have an authorized LINEAR POWER™ dealer do the work. IMPORTANT !!! THE FREQUENCY CHIP MUST BE PROPERLY INSTALLED AND LOCKED FIRMLY IN POSISTION PRIOR TO OPERATION IN ORDER TO PREVENT THE POSSIBILITY OF SEVERE SYSTEM DAMAGE.
- Page 3 "hot" wires from the low frequency amplifier by attaching the green wire to the woofer positive terminal and the grey wire to the negative terminal. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 4 WE REPEAT THE WARNING: DAMAGE TO YOUR SPEAKERS CAN BE CAUSED BY REMOVING THE RESISTOR NETWORK WHEN THE SYSTEM IS TURNED ON! © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 5 In the case above, since the overlap area is one octave, the crossover point would be at one half octave, or 1800 Hertz. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 6 (601) 932-8477 E-mail: ray@tipsinc.net SPECIFICATIONS XO-1© Output Level: 0 to 5 volts Total Harmonic 0.05% maximum Distortion: 0.01% typical Inter-modulation Distortion: 0.01% maximum © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
- Page 7 +1dB 4 Hz to 250 KHz Current Draw: 25 mA maximum Crossover Points: 50 Hz to 6 KHz in 1/3 octave steps Crossover Slope: 12dB per octave © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
