C&H Technologies M360 Specification Sheet

Specifications:

Serial Port Characteristics:
Data Rates: Up to 1 Mbps
Clock Frequency: Programmable
Identifier Fields: Standard (11 bit)
and Extended (29 bit) supported
CAN access priority: Determined
by message identifier
I/O Buffer Memory:
TX: 64 bytes (2 CAN messages)
RX
Connectors:
Temperature:
Operating:
Storage: -20°C to 70°C
Power:
+5V @ 0.175 A
C&H Technologies, Inc. • 445 Round Rock West Drive • Round Rock, TX 78681-5012
(512) 733-2621 • FAX (512) 733-2629 • www.chtech.com
Transceiver Characteristics:
Type:
TTL signals:
(on I/O connector)
Controller:
CANbus support:
Front Panel Indicators:
10 bytes
Two LEDs:
9 pin DSUB
(Female)
Full Interrupt Capabilities
0°C to 60°C
Isolation:
PCA82C250T
TX0
TX1
RX0
RX1
SJA1000
Rev. 2.0a
Rev. 2.0b
User Programmable
Status
Opto-isolation
devices ship with M360
M360

CAN bus

Controller
M Module
The M360 CAN bus Controller is an
integrated standalone controller for
the Controller Area Network (CAN)
with an M Module interface. CAN is
used within the automotive and
general industrial environments. The
M360 contains all
hardware for high performance
serial network communications. It
performs all the functions of the
physical and data link layers.
M Module Compliance
Complies with ANSI/VITA Std 12-
1996 for single-wide M Modules.
Data Transfers
Interrupts
IDENT Implemented
Compatible with VXI, VME, PCI,
PXI, CPCI & Ethernet Carriers
Applications
• Automotive CAN interfacing
• Industrial Control

Ordering Information

Part Number
11029690-0001

Additional Information

User Manuals for C&H carriers and
this module can be found on our
website at www.chtech.com.
necessary
16 bit
INTA
