Original Instruction Manual
FM25 Floor Standing
1" Morticer with
Sliding Tables
Version 3.0
August 2014
It is important to register your product as soon as possible in order to receive efficient after sales
support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
Kg
Always wear safety glasses when
using woodworking equipment.
To register this product please visit
www.recordpower.info
Please see back cover for contact details.
Important
i
For your safety read instructions carefully before
assembling or using this product.
Always read the instructions
provided before using
Save this manual for future reference.
woodworking equipment.
Advertisement
Table of Contents
Summary of Contents for Record Power FM25 Series
- Page 1 Original Instruction Manual FM25 Floor Standing 1” Morticer with Sliding Tables Version 3.0 August 2014 To register this product please visit www.recordpower.info It is important to register your product as soon as possible in order to receive efficient after sales support and be entitled to the full 5 year guarantee.
-
Page 2: Table Of Contents
Contents 1.1 Explanation of Symbols 1.2 General Health & Safety Guidance Additional Health & Safety for Morticing Machines Record Power Guarantee Specifications Knowing your Machine Contents of the Package Assembly Operation Setting the Chisel and Bit Maintenance of Chisel and Bits... -
Page 3: Explanation Of Symbols
1.1 Explanation of Symbols THE SYMBOLS AND THEIR MEANINGS SHOWN BELOW MAY BE USED THROUGHOUT THIS MANUAL. PLEASE ENSURE THAT YOU TAKE THE APPROPRIATE ACTION WHEREVER THE WARNINGS ARE USED. Mandatory Instructions Read and fully understand the instruction manual before attempting to use the machine. Indicates an instruction that requires particular attention Wear protective eyewear Use respiratory protective equipment... -
Page 4: General Health & Safety Guidance
1.2 General Health & Safety Guidance Ensure that you carefully read and fully understand the 6. The machine should be level and stable at all times instructions in this manual before assembly, installation and use • When using a leg stand or cabinet base that is designed to be fitted to of this product. - Page 5 1.2 General Health & Safety Guidance cont. • If the work area is to be left unattended, all machinery should be switched table, or to help feed, support, or pull the work piece. ‘OFF’ and isolated from the mains power supply. •...
-
Page 6: Additional Health & Safety For Morticing Machines
1.2 General Health & Safety Guidance cont. • A guard or other part that is damaged should be properly repaired 32. Have your machine repaired by a qualified person or replaced by a qualified person unless otherwise indicated in this •... -
Page 7: Record Power Guarantee
Guarantee should be made directly to Record Power or its Authorised Distributor Record Power guarantees that for a period of 5 years from the date (for details of the Authorised Distributor in your country please see of purchase the components of qualifying Products (see clauses 1.2.1 your Product manual or check www.recordpower.info for details). -
Page 8: Specifications
4. Specifications Table Size: 400 x 150mm Chisel Shank: 1 ”& ” Table Height: 240mm Maximum Chisel Stroke: 210mm Maximum Drill Depth: 70mm Distance from Fence to Centre of Chisel: 140mm Maximum Workpiece Height: 200mm Chuck Capacity: 16mm Maximum Workpiece Depth: 140mm Motor: 230 V / 50 Hz / 750 W / 1 hp Table Movement Side to Side: 170mm Full load current: 4 A... -
Page 9: Contents Of The Package
6. Contents of the Package 1 - Chuck Key 2 - Socket Head Cap Screws x2 3 - Work Stop 4 - Arm 5 - Washer x2 6 - M16 Hex Nut 7 - Base 8 - Morticer Please note the FM25 does not come with the chisel and bit shown. -
Page 10: Operation
8. Operation Fig 8.1 Using the Morticer 1. Set depth stop to the required depth of cut, see Fig 8.1. Depth Stops 2. Place workpiece on table and clamp it to the table with the work clamp at the front of the machine, Fig 8.2. Ensure that the workpiece is seated fully on the table surface before securing with the clamp. -
Page 11: Setting The Chisel And Bit
This will eventually cause the chisel to break. For best results only Record Power chisels and bits should be used with this machine. -
Page 12: Maintenance Of Chisel And Bits
10. Maintenance of Chisels and Bits Chisel Abrasion Look downward into the hollow of the chisel, check to see whether any of Fig 10.1 the bevelled areas inside the chisel (where hollow becomes circular) have Square Corners dulled or any of the square corners have become round, Fig 10.1. The angles of the corners should be filed to regain the original shape. -
Page 13: Dust Extraction
Record Power Extractors be switched off for 20 minutes every hour. 0.5 micron filtration Record Power offer a range of high quality dust extractors, we offer both drum and bag type extractors which filter down 0.5 micron providing CX2000 Compact Chip Extractor protection from harmful fine dusts. -
Page 14: Trouble Shooting
12. Trouble Shooting Should you have any difficulty arise during operation, check the power cord and connection. If the problem does not appear to be related to the power supply, the following table may help to identify it. IMPORTANT Disconnect the machine from the power supply before servicing the machine. -
Page 15: Electrical Connection & Wiring Diagram
13. Electrical Connection & Wiring Diagram Machines supplied for use in the UK are fitted with a 3 pin plug conforming machine. If replacing the original fuse, always fit a fuse of equivalent rating to BS1363, fitted with a fuse conforming to BS1362 and appropriate to the to the original. -
Page 16: Parts List
14. Parts Lists & Diagrams... - Page 17 14. Parts Lists & Diagrams Description Quantity Description Quantity Chuck, 16mm Base Middle Base Screw, M6x10 Cover Drift Gear Setting Handle Hex Nut, M6 Shaft Connecting Bend Washer, 10 Wave Washer, 10 Spring Screw Cap Screw, M10x40 Headstock Column Screw Screw Ruler mark Gas Spring...
- Page 18 14. Parts Lists & Diagrams Stand Assembly Description Quantity Stand Door Door Latch Hex Nut, M10 Stand Base Hex Nut, M10 Washer , 10 Wave Washer 10 Cap Screw, M12x40 Clamping Bar Assembly Description Quantity Shaft Setting Piece Spring Clamping body C-Clip Locking handle Locking Screw...
-
Page 19: Eu Declaration Of Conformity
EU Declaration of Conformity Cert No: EU / FM25 / 1 RECORD POWER LIMITED, Centenary House, 11 Midland Way, Barlborough Links, Chesterfield, Derbyshire S43 4XA declares that the machinery described:- 1. Type: Heavy Duty Morticer 2. Model No: FM25 3. Serial No ................. - Page 20 Woodworking Machinery & Accessories United Kingdom Eire Australia New Zealand Record Power Ltd Record Power Ltd Tools 4 Industry Tools 4 Industry Centenary House, Centenary House, Po Box 3844 Po Box 276079 11 Midland Way 11 Midland Way Parramatta 2124...
