- Page 1 TRK-SR2 Install Guide 8/29/01 10:22 AM Page 1 TRK-SR2 Roof-Mount Satellite Radio Antenna Installation Guide...
-
Page 2: Table Of Contents
About XM Satellite Radio ........ -
Page 3: Introduction
• Safe for low-clearance conditions, including car washes The TRK-SR2 is easy to install on most vehicles. The package includes all the necessary mounting hardware, as well as color-coded cable connectors to ensure complete compatibility with all XM receivers. Remember to save your sales receipt and this guide so both are available for future reference. -
Page 4: Applications
For details, see Installation starting on page 6. EDANS Figure 2. The Terk TRK-SR2 is shown installed on the roof of a four-door sedan. Figure 3. The Terk TRK-SR2 is shown installed on the roof of an SUV. -
Page 5: Convertibles
Figure 5. The Terk TRK-SR2 is shown installed on the trunk of a convertible. Note the difference in antenna orientation from other vehicles. NOTE: The TRK-SR2 can be used on a convertible with a removable metal roof as long as the top is off. Using the roof may cause interference and degraded reception. -
Page 6: Installation
Although a center position on a roof is the most aesthetically pleasing, if there is an obstruction (e.g., skid ribs, protruding brake light on roof line, etc.) consider offsetting the TRK-SR2 from the center. If this doesn’t work, use the Terk TRK-SR1 Glass-Mount Satellite Radio Antenna instead. -
Page 7: Installing The Trk-Sr2
If the vehicle is equipped with a metal sunroof (e.g., Mazda 626), which opens to the outside, allow a minimum distance of 6 inches from the edge of the open sunroof to the TRK-SR2. If this is not possible, use the Terk TRK-SR1 Glass-Mount Satellite Radio Antenna instead. - Page 8 TRK-SR2 ( NSTALLING TRK-SR2 Figure 9. Positioning the TRK-SR2 on a vehicle’s roof so the cable cover flap extends over the rear window molding. 3. Continue placing the molding down on the roof, working forward towards the antenna module. Examine the placement and make any desired adjustments.
- Page 9 TRK-SR2 Install Guide 8/29/01 6. If the XM system is not already installed, temporarily connect power and ground to the system. Connect the TRK-SR2 to your XM receiver, as directed by the receiver’s manufacturer (see Figure 11 below). XM Receiver (Tuner) Figure 11.
-
Page 10: Use And Care
TRK-SR2 Install Guide 8/29/01 USE AND CARE In normal daily use, the Terk TRK-SR2 Roof-Mount Satellite Radio Antenna is a rugged, high-performance antenna that does not require any special attention. TROUBLESHOOTING YMPTOM XM radio is on, but no channels are being received. -
Page 11: Specifications
Specifications and appearance may differ from those listed or shown in this manual. The XM name and related logos are trademarks of XM Satellite Radio, Inc. Terk and Terk Technologies are trademarks of Terk Technologies Corp., Commack, NY. -
Page 12: Limited Warranty
ABOUT XM SATELLITE RADIO For more information about XM Satellite Radio service, visit their web site at: www.xmradio.com Terk Technologies Corporation...
