C&H Pulse Amplifier M206 Specifications

Specifications:

Outputs:
Two true (A & B) and two
complement (A & B) outputs
Frequency: 20MHz max.
Input:
Output Amplitude:
R = 50 +0.21V to +15V
LOAD
R = +0.42V to +30V
LOAD
Output Current:
Source
Sink
Output Impedance:
Programming Resolution:
10V range
30V range
Accuracy: 0.75% 75mV
Rise/Fall Time:
30V, R =
LOAD
C&H Technologies, Inc.
(512) 733-2621
Inputs/Outputs:
Pulse Input
True Output A
True Output B
Complement Output A
Complement Output B
TTL
External Power (+36V)
External Power Interlock
Pulse Interlock
External Power:
36V 2A supply required
300mA
Front Panel Connectors:
100mA
Pulse Input/Outputs
Ext. Pwr. & Interlocks 9-pin DSUB
50
Temperature:
Operating:
2.50mV
Storage:
7.50mV
Power (typical):
+5V
+12V
-12V
30ns
Ext. +36V
445 Round Rock West Drive
FAX (512) 733-2629
SMA
0 C to 50 C
-40 C to 70 C
150 mA
300 mA
100 mA
1.0 A
Round Rock, TX 78681-5012
www.chtech.com
M206
Pulse Amplifier
The M206 is a programmable pulse
amplifier that accepts a fixed level
input pulse and provides dual
complementary switched outputs.
The module produces a total of four
outputs. Two outputs have the
same active-level as the input pulse
and two outputs
complement level of the input pulse.
The output level is programmable
up to 30V into no load (up to 15V
into a 50 load). An external +36V
supply is required. An external
power interlock and a pulse interlock
are provided.
M Module Compliance
Complies with ANSI/VITA Std. 12-
1996 for triple-wide MA Modules
Data Transfers:
Interrupts: not supported
Triggers: not supported
Compatible with VXI, VME, PCI,
cPCI and other M Module carriers.
Applications
Pulse amplification
Pulse level shifting

Ordering Information

Part Number 11028470-0001

Additional Information

User Manuals for C&H carriers and
this module can be found on our
website at www.chtech.com.
