- Page 1 WF-2117/WF-2118 Wireless N PCI Adapter Quick Installation Guide...
- Page 2 Wireless-N PCI Adapter Quick Installation Guide FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Package Contents
Wireless-N PCI Adapter Quick Installation Guide modifications to this equipment. Such modifications could void the user authority to operate the equipment 1 Package Contents The following items should be found in your package: Ø Wireless-N PCI Adapter Ø CD-ROM Ø Quick Installation Guides Make sure that the package contains above items. - Page 4 Wireless-N PCI Adapter Quick Installation Guide 4 Driver and Hardware Installation 4.1 Driver installation of the Wireless-N PCI Adapter Turn on the computer and Insert the Wireless-N PCI Adapter Driver CD in the CD-ROM drive. The Install Screen will appear. If not, click the Start button and choose Run and enter D:\autorun.exe (if ‘D’...
- Page 5 Wireless-N PCI Adapter Quick Installation Guide Figure 4-2 Ø Select “Ralink Configuration Tool” and Click Install...
- Page 6 Wireless-N PCI Adapter Quick Installation Guide Figure 4-3 Ø Click Install...
- Page 7 Wireless-N PCI Adapter Quick Installation Guide Figure 4-4 Ø Click Finish to finish the driver installation...
- Page 8 Wireless-N PCI Adapter Quick Installation Guide Figure 4-5 4.2 Hardware installation of the Wireless PCI Adapter 4.2.1 Install the Wireless-N PCI adapter into your computer Ø Make sure to turn off your computer and unplug the power cord. Remove the back cover of the computer.
- Page 9 Wireless-N PCI Adapter Quick Installation Guide Ø Attach the Wireless-N PCI Adapter’s antenna to the socket on the back panel shield. 4.2.2 Restart your computer Turn on the computer, the Found New Hardware Wizard (windows XP) screen will appear: Ø Select Install the software automatically (Recommended) and then click Next Figure 4-6 Ø...
-
Page 10: Connecting To A Wireless Network
Wireless-N PCI Adapter Quick Installation Guide 5 Connecting to a wireless network Use the Ralink WLAN Utility to check the link information, search for available wireless networks, or create profiles that hold different configuration settings. You can double-click the icon on your desktop to run it. Another way to start the Configuration Utility is to click Start>... - Page 11 Wireless-N PCI Adapter Quick Installation Guide Figure 5-2 Now you have finished the configuration. Figure 5-4 6 FAQ This chapter provides solutions to problems that may occur during the installation and operation of the Wireless USB Adapter. Read the descriptions below to solve your problems. 1.
- Page 12 Wireless-N PCI Adapter Quick Installation Guide that the AC power and Ethernet cables are firmly connected. Check that the IP address, subnet mask, gateway, and DNS settings are correctly entered for the network. In Infrastructure mode, make sure the same Service Set Identifier (SSID) is specified on the settings for the wireless clients and access points.
