- Page 1 48V40UHD Ver 1.0 USER’S MANUAL 48” 4K ULTRA HD TELEVISION Use a VIDĀO HDMI Cable for the Best Possible Video & Sound For technical assistance or troubleshooting please call 1-855-998-4326 or visit www.sibrandssupport.com...
-
Page 2: Important Safety Instructions
Instruction: The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance. 48V40UHD-1... - Page 3 Safety Instructions Please read these instructions carefully. This product complies with all applicable US federal safety requirements, as well as those of the Canadian Standards Association. 1. Cleaning Always unplug the TV before cleaning. Do not use liquid or aerosol cleaners. Use a soft, slightly damp cloth to clean.
- Page 4 If the TV has been dropped or the cabinet has been damaged. f. If the TV exhibits a distinct change in performance. 48V40UHD-3...
- Page 5 “Blu-ray Disc” is a trademark of Blu-ray Disc Association, registered in the U.S. and other countries. MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of the MHL, LLC. All other trademarks are the property of their respective owners and are used for descriptive and/or compatibility purposes only. 48V40UHD-4...
-
Page 6: Table Of Contents
Closed Captions.................................24 CEC Settings................................25 Parental Control ................................26 Channel Settings Favorite ..................................28 Show / Hide ..................................28 Channel Label ................................28 TV Channel Setup & Channel Auto Scan ........................29 Zoom Modes ................................30 USB Modes ..................................31 MHL Setting ................................32 ................................33 Troubleshooting ................................34 48V40UHD-5... -
Page 7: Introduction
• Quick Start Guide • User Manual • Child Safety • Pedestal Base • Screws M4X12 for Pedestal Base (6) 48V40UHD • User manual • Remote Control • Base Legs • Screws M4X12 for Base Legs • Quick Start Guide •... -
Page 8: Installing The Base
Installing the Base Place the TV face down on a soft cloth or cushion. Position base as shown. Insert 6 screws M4X12 (provided) through the holes in the bottom of the base into the post holes and tighten securely. Do not over-tighten. -
Page 9: Remote Control
For non-major TV functions not listed, use the remote control included with this TV. o program your Cable / Satellite remote to operate this VIDAO TV, follow the programming instruc- tions included with your providers’ remote and use the following codes. -
Page 10: Overview
Remote Control Overview 48V40UHD 48V40UHD-9... - Page 11 27. MTS Press to select a program’s second audio channel (if available). 28. CCD Press to select closed caption subtitles (if available) OFF - ON - CC ON MUTE Press number keys to enter channel numbers. 29. NUMBER KEYS 48V40UHD-10...
-
Page 12: Tv Overview
TV Overview Front & Rear Panel IR Receiver A soft green light illuminates when the television power is on. Source Select Component HDMI1 HDMI2 HDMI3 HDMI4 Media 1. STANDBY - Press the STANDBY button to turn the TV ON/ OFF (power). The screen image will appear within a few seconds, and the Green LED will turn on. -
Page 13: Rear Panel
TV Overview Rear Panel Wall Mounting NOTE: You must remove the pedestal before wall mounting. It is recommended that you consult a professional before mounting this TV a wall. Use VESA 400x200 wall mount hardware. ‘ ’ Œ... -
Page 14: Installation
Installation Connection to HDMI Input Digital Cable / Satellite Set Top Box Optional HDMI cable ( not included ) Cable / Satellite set top box Coaxial / RF Cable (not included) How to connect • On the back of your device, connect the HDMI cable from HDMI out on device to HDMI in on the panel. How to Use •... -
Page 15: Connect A Digital Cable Box, Satellite Recei Ver, Or Dvd Player With A Component Connection
Connection to Component Installation YPbPr Input Connecting a device with a Component connection. Optional Component cables (not included) Digital set top box, gaming console or DVD Source Select How to Connect • Match and insert the green (Y), blue (Pb), and red (Pr) cables into the device and TV. -
Page 16: Connect A Digital Cable Box, Satellite Recei Ver, Or Dvd Player With Composite Cables (Yellow, Red, & White)
Installation Connection to Composite Input Connecting a device with a Composite connection. Audio Video Cable (not included) Digital set top box, gaming console or DVD How to Connect • Match and insert the yellow, red, and white A / V cables into the Source Select device and TV. -
Page 17: Connecting The Power And Basic Cable Connection
Connection to Antenna & Installation Cable / Satellite Box We recommend using a high quality roof top antenna, digital cable, or satellite box for the best display and performance. Note: Reception quality is determined by your location, geographical terrain, distance from the local broadcast transmitter, and strength of antenna. -
Page 18: Connection To A Home Theater System
Connection to a Home Installation Theater System Connection to a Home Theater Audio System Optional digital cable (not included) Connecting to a Home Theater System Digital audio can deliver optimal 2 - channel stereo or 5.1 surround sound with Five discrete full range channels plus a separate channel for a subwoofer. Sound Mode Standard Connect an optional digital cable directly to the television’s OPTICAL OUT... -
Page 19: Tv Setup
Select the time zone & Daylight saving time Use the q arrow button to select Go to next step and press the Select the time zone & Daylight saving time MENU Select Move Return Move Select Exit MENU u button to complete the step. 48V40UHD-18... - Page 20 TV Setup Initial Setup Wizard IMPORTANT NOTE: If your TV is connected to a Cable or Satellite set top box DO NOT run the “Channel Auto Scan” in STEP 3. STEP 3: Setting Air/Cable and Channel Auto Scan Note: Your type of television connection will determine if you should complete the Channel Auto Scan part of this step.
-
Page 21: Picture Setting
Menu Adjustments Picture Setting The Picture menu offers options to enhance and refine the picture displayed on your TV based on ambient room light and personal preferences. Adjustment options include contrast, brightness, color, sharpness and color temperature. How to Navigate: Press the MENU button on the remote control. -
Page 22: Audio Settings
Menu Adjustments Audio Settings The Audio menu offers options to make sound enhancements while listening through the built-in speakers or to select digital audio options when connected to a Dolby Digital receiver though an optical digital output. How to Navigate: Press the MENU button on the remote control. -
Page 23: Date & Time Settings
Menu Adjustments Date & Time Settings The Time menu includes adjustment of settings for your local time zone and daylight savings time. The clock will adjust automatically after the initial Channel Auto Scan of available broadcast channels in your area. How to Navigate: Press the MENU button on the remote control. -
Page 24: Setup Settings
Menu Adjustments Setup Settings In the Setup menu you may change the initial set up of preferences that include settings for language, menu display, computer monitoring, closed captions, enhancement of black detail in the picture and resetting your TV back to its factory default status. -
Page 25: Closed Captions
Menu Adjustments Closed Captions The Setup menu includes adjustments for activating the Closed Caption text feature for display on-screen and customiz- ing CC display types and font styles. How to Navigate: Press the MENU button on the remote control. Navigate using arrow t u buttons to select Setup. Menu Language Menu Language English... -
Page 26: Cec Settings
Menu Adjustments CEC Settings The CEC menu includes options for controlling functions of compatible external devices connected via the HDMI input. Please refer to the instruction manual of your connected device to confirm if CEC control is possible. How to Navigate: Press the MENU button on the remote control. -
Page 27: Parental Control
Menu Adjustments USA Parental Control In the Lock menu, you may block television and movie programming based on TV ratings and Motion Picture Association guidelines. To gain access and select your preferences within the Parental menu make certain your input is set to TV. How to Navigate: Press the MENU button on the remote control. - Page 28 Appropriate for Children 13 years old and up 16 ans+ Appropriate for Children 16 years old and up 18 ans+ Mature Audience Only Move Select Return Note: When adjustments are completed, you may select another menu by pressing the Menu button. 48V40UHD-27...
- Page 29 Next Next Return Return Return Next Return Next Next Return 48V40UHD-28...
-
Page 30: Favorite
TV Provider Changes & TV Settings Channel Auto Scan After Initial Setup To make changes your TV provider or re-scan for available broadcast channels in your area, select the Channel Menu. Note: For Cable or Satellite users with a set-top box, there is no need to run Channel Auto Scan. Connect your cable satellite set top box to one of the available inputs on the TV for viewing. -
Page 31: Zoom Modes
Aspect Modes The ASPECT function offers several viewing display options on the 16:9 screen. Press the ASPECT button to cycle through the following widescreen settings. NOTE: The ASPECT function is not available for digital broadcasts. Press ASPECT to cycle through the following widescreen settings. -
Page 32: Usb Modes
MEDIA. Source Select MEDIA in the Component HDMI1 HDMI2 HDMI3 HDMI4 Media... -
Page 33: Mhl Setting
MHL Setting Connecting an MHL-enabled device You can connect a MHL-enabled device, such as certain models of smartphones & tablets, and view the device’s screen on the TV. Connecting a MHL-enabled device to the HDMI4 (MHL) input requires a special MHL cable. (Not included) To connect an MHL-enabled device: 1. - Page 34 480p / 720p / 1080i / 1080p / 2160p 3840x2160 3000:1 178° 178° 16.7M 130 W 2 x 8W 43.3” (W) x 25.6” (H) x 3.3” (D) 29.7 lbs Weight (may vary 10%) Composite Video Y Pb Pr HDMI HDMI with MHL CABLE-ANTENNA Optical AUDIO out 48V40UHD-33...
-
Page 35: Troubleshooting
• Re-connect the antenna or cable wiring. • Restore default settings. See page 23. Remote control does not function • Replace batteries with new ones. • Check that battery polarity is correct. • Point remote directly at the TV’s IR receiver. See page 8. 48V40UHD-34... - Page 36 We warrant this product to be free from defects in material and workmanship under normal use for a one-year period from the original date of purchase from an authorized VIDAO dealer. We will repair or replace the unit free of charge should it become defective under this warranty, providing you, the original purchaser, submit proof of purchase (sales slip) along with the TV and all accessories.
