Owner's Manual
for Assembly, Operating & Maintenance of
Model Gas Steam Table
YOU MUST READ THIS OWNER'S MANUAL
BEFORE OPERATING YOUR GAS STEAM TABLE.
DANGER
IF YOU SMELL GAS:
1. SHUT OFF GAS TO APPLIANCE
2. EXTINGUISH OPEN FLAMES
3. OPEN LID (IF APPLICABLE)
4. IF ODOR CONTINUES, KEEP AWAY FROM THE
APPLIANCE AND IMMEDIATELY CALL YOUR
GAS SUPPLIER OR FIRE DEPARTMENT.
LEAKING GAS MAY CAUSE FIRE, EXPLOSION,
PERSONAL INJURY, DAMAGE TO PROPERTY, AND
DEATH.
THIS GAS GRILL IS DESIGNED FOR OUTDOOR USE ONLY.
P: 814-359-2755
Copyright 2107 Big John Grills & Rotisseries
526 EAST ROLLING RIDGE DRIVE, BELLEFONTE, PA 16823
F: 814-359-2621
WARNING: Follow all leak-check
procedures listed in this manual carefully
prior to operation of this unit. Do this
even if the steam table was assembled by
a professional.
WARNING: Do not ignite this steam table
without reading the LIGHTING
INSTRUCTIONS first.
WARNING: DO NOT store or use
gasoline or other flammable liquids/
vapors in the vicinity of this steam table.
An LP Cylinder not connected for use
should not be stored in the vicinity of this
unit.
sales@bigjohngrills.com
www.bigjohngrills.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BIG JOHN ST-4

  • Page 1 PERSONAL INJURY, DAMAGE TO PROPERTY, AND unit. DEATH. THIS GAS GRILL IS DESIGNED FOR OUTDOOR USE ONLY. 526 EAST ROLLING RIDGE DRIVE, BELLEFONTE, PA 16823 P: 814-359-2755 F: 814-359-2621 sales@bigjohngrills.com Copyright 2107 Big John Grills & Rotisseries...
  • Page 2: Table Of Contents

    Page 10 8. CLEANING & CARE INSTRUCTIONS Page 11 9. PARTS LIST Page 12 10. ACCESSORY LIST Page 13 11. TROUBLESHOOTING GUIDE Page 14 & 15 12. WARRANTY Page 16 13. WARNINGS Page 17 Copyright 2107 Big John Grills & Rotisseries...
  • Page 3: Propane Safety - General

    All tanks used on Big John Grills equipment must be a minimum of 30 lb. size.  Tanks larger than 100 lbs. in size may require a POL for connection. Please call a Big John  Customer Service Representative if you are using a 100 lb. propane tank.
  • Page 4: Propane Safety - Cylinder

    Always store propane cylinders in a secure, cool/dry place in the upright position.  Never store propane cylinders in a vehicle of any kind and or anywhere the temperatures can reach  125° F. Copyright 2107 Big John Grills & Rotisseries...
  • Page 5 If you suspect any problems, have your grill and tank serviced by a qualified professional Spray Soapy Water on All Propane Connections between Cylinder Valve and Unit to Test for Leaks Hose to Unit Connection Cylinder Valve to QCC Connection Copyright 2107 Big John Grills & Rotisseries...
  • Page 6: Propane Safety - Qcc

    8. Inspect each connection and length of hose for any bubbles being produced 9. If bubbles are detected (bubbles indicate gas is escaping), turn off propane tank and call Big John Grills to order replacement parts. Do not go to your local hardware store.
  • Page 7: General Information

    GENERAL INFORMATION Thank you for purchasing a Big John Steam Table! We take pride in producing and selling equipment made right here in America and are pleased that you recognized the quality and durability of our products. Your new steam table is a commercial grade, outdoor piece of cooking equipment. With this unit, you will be able to maintain the temperature of a variety of foods quickly and easily without the worry of blow-outs or hot spots.
  • Page 8: Assembly Instructions

    5. Flip base right-side up 6. Remove all packing materials, tape, and protective laser paper (can be white, gray or clear in color) from Stainless Steel Water Pan 7. Insert stainless steel water pan into body. Copyright 2107 Big John Grills & Rotisseries...
  • Page 9: Set-Up Instructions

    6. Ensure the control valve is in the CLOSED position (parallel to the ground with knob end turned to the left). Knobs are “Push to Turn” Position Position Copyright 2107 Big John Grills & Rotisseries...
  • Page 10: Operating Instructions

    6. Carefully drain water from stainless steel pan using spigot on side of unit. WARNING: WATER WILL BE EXTREMELY HOT! Copyright 2107 Big John Grills & Rotisseries...
  • Page 11: Cleaning & Care Instructions

    3. How to clean the control valve orifice: a. Turn off gas and completely disconnect unit from gas source. b. Use small wire, needle or pipe cleaner to gently wipe away any debris from orifice. Copyright 2107 Big John Grills & Rotisseries...
  • Page 12: Parts List

    Control Valve 302762 Chrome Knob 302345 Steam Table Burner 302450 Leg for Steam Table 102338 5” Swivel Caster 102336 Caster Brake for 5” Caster 102344 Caster Wrench 302761 302762 BACK FRONT 302763 http://www.bigjohngrills.com/categories/3and4bayparts Copyright 2107 Big John Grills & Rotisseries...
  • Page 13: Accessory List

    301016 30# Propane Cylinder 301017 40# Propane Cylinder 102336 Caster Brake for 5” Caster 301169 VC-62; 62” Green Vinyl Cover for ST-4 301168 VC-46; 46” Green Vinyl Cover for ST-3 ST-4 Accessories: http://www.bigjohngrills.com/products/st-4#accessories ST-3 Accessories: http://www.bigjohngrills.com/products/st-3#accessories Copyright 2107 Big John Grills & Rotisseries...
  • Page 14: Troubleshooting Guide

    8. Inspect each connection and length of hose for any bubbles being produced 9. If bubbles are detected (bubbles indicate gas is escaping), turn off propane tank and call Big John Grills to order replacement parts. Do not go to your local hardware store.
  • Page 15 If you are not, please call Big John Grills to purchase a replacement regulator. 1. Check that you are using at least a 30 lb. propane tank as most Big John equipment requires a minimum of a 30# propane tank due to the BTU draw. Use of 20 lb. cylinders is only acceptable for an appliance with a BTU draw of 60,000 BTU’s or less.
  • Page 16: Warranty

    WARRANTY INFORMATION Big John Corporation provides a warranty, to the original purchaser, for all Big John finished units for a period of 1 year from the date of sale. Any unit, or part thereof returned, freight prepaid, to our Sales &...
  • Page 17: Warnings

    If you wish to change your unit from LP to NG or vice versa,  Do not store extra liquid propane cylinders within the vicinity please call a Big John Customer Service Agent to obtain of this product. required parts.
