Operator Instructions
Includes – Please Read and Comply, Warning,
Product Configuration and Specifications Table, Parts
Page, Parts List, Work Stations, Putting the Tool Into
Service, Compressor Layout and Safety Information.
Recommended Airline
Size - Minimum
10 mm
DOC EATOS50S1P
Model No. EATOS50S1P
Required Personal Safety Equipment
Safety Glasses
Safety Gloves
Recommended Maximum
Hose Length
3/8 in
8 meters
OPERATOR'S MANUAL FOR
RANDOM ORBITAL SANDER
12,000 RPM
Important
Read these instructions carefully be-
fore installing, operating, servicing or
repairing this tool. Keep these instruc-
tions in a safe accessible location.
Breathing Masks
Maximum Working Pressure
Recommended Minimum
25 feet
1
Ear Protection
Air Pressure
6.2 bar
90 psig
NA
NA
Original Instructions
Revision 08/19/20
