- Page 1 Marvell Semiconductor, Inc. IEEE 802.11 2X2 MU-MIMO ac/a/b/g/n Wireless LAN + Bluetooth NGFF Module W8997-M1216 (AW-CM276NF) EVB User Manual Version 0.3 - 1 - Arrow.com. Downloaded from...
- Page 2 Marvell Semiconductor, Inc. 1. Test environment requirement Linux OS(later than Ubuntu 14.04) PCIE Interface 2. EVB connections 3. EVB set up with Linux PC Please follow document “AW-CM276NF WLAN & Bluetooth MFG Tool Command User Guide” and start the RF test.
- Page 3 Marvell Semiconductor, Inc. Environment set up and Bridge Mode Tool The “Manufacturing Bridge” refers to the application that allows a user to send commands between Target platform and Windows XP platform. The environment enables the user to test performance of the AW-CM276NF.
- Page 4 Marvell Semiconductor, Inc. On the given Host Linux system, the following files have to be transferred & reside on the system. (Transfer the files over via flash memory or tftp over the host.) Place the firmware in /lib/firmware/mrvl/ Ex. pcieuart8997_combo_v2.bin (for PCIE/USB interface) The user may need to compile the driver per your specific Linux OS and Kernel.
-
Page 5: Windows Pc Set Up
Marvell Semiconductor, Inc. 4.2 Windows PC set up Within the internal folder is the labtool and other folders. For this document’s purpose, only the details of the labtool folder will be discussed. The contents of the labtool folder are shown below. - Page 6 Marvell Semiconductor, Inc. Start driver installation and DUT testing Now you can run the following commands to install the driver and firmware and start the Manufacturing bridge application with the following commands. On the working direction, use the following commands to put the 88W8997 in MFG mode after power on DUT.
- Page 7 Marvell Semiconductor, Inc. Edit the “SetUp.ini” file as shown in the lines highlighted in below. The setup DutIpAddress will be the IP address of your target. Then you can double click “DutApiMimoBt.exe” to enter labtool as below picture. 5.1 Initial Command As the information showed on your screen, please enter these commands below to start your test.
- Page 8 Marvell Semiconductor, Inc. 5.2 Generate 802.11a/b/g/n/ac Packet commands a. Tx on CH 6 at 10 dBm with a CCK-11Mbps data rate in 20 MHz BW mode on path A // Stop Tx 10 1 1 // Set Path A Only 30 0 // Set to 2.4 GHz Band...
- Page 9 Marvell Semiconductor, Inc. 10 1 1 // Set Path A 30 1 // Set to 5 GHz Band 112 0 // Set to 20 MHz BW 22 0 36 8 2 // Set to CH 36 at 8 dBm Output Power with OFDM(n or ac mode)
- Page 10 Marvell Semiconductor, Inc. N mode: MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 MCS6 MCS7 AC mode: VHT Data Rates: 101 for VHT_SS1_MCS0 102 for VHT_SS1_MCS1 103 for VHT_SS1_MCS2 104 for VHT_SS1_MCS3 105 for VHT_SS1_MCS4 106 for VHT_SS1_MCS5 107 for VHT_SS1_MCS6 108 for VHT_SS1_MCS7...
- Page 11 Marvell Semiconductor, Inc. 10 1 1 // Set Path A 30 1 // Set to 5 GHz Band 112 0 // Set to 20 MHz BW 22 0 36 8 2 // Set to CH 36 at 8 dBm Output Power with OFDM Data Rate on Path A...
- Page 12 Marvell Semiconductor, Inc. Installation and setting on customer’s platform AW-CM276NF is a M.2 type 1216 solder down module, which needs SMT process to assembly on customer’s platform. The software setup steps is same as MFG one(step 4.1). Customer only needs to replace MFG FW by normal FW.
- Page 13 Marvell Semiconductor, Inc. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 14 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: UAY-W8997-M1216”. The grantee's FCC ID can be used only when all FCC compliance requirements are met.
- Page 15 Marvell Semiconductor, Inc. Industry Canada statement: This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 16 Marvell Semiconductor, Inc. IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be used on the final product.
- Page 17 Marvell Semiconductor, Inc. Caution : (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p.
- Page 18 Marvell Semiconductor, Inc. (v) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
