Summary of Contents for Westinghouse LCM - 19v5
-
Page 2: Table Of Contents
IMPORTANT PRODUCT SAFETY INSTRUCTIONS ... 1 ... 2 AFETY UIDELINES FCC C OMPLIANCE TATEMENT LCD M ... 3 LEANING THE ONITOR FEATURES... 4 ... 4 OWER AVER & P ... 4 INSTALLATION ... 5 ... 5 ACKAGE ONTENTS LCD M RONT IEW OF THE ONITOR... -
Page 3: Important Product Safety Instructions
• Do not place heavy objects on the LCD Monitor, audio/video cables, or power cord. • If the LCD Monitor emits smoke, abnormal noise, or a strange odor, immediately turn it off and contact the Westinghouse Service Center. • WARNING – To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose... -
Page 4: Safety Guidelines
If a BNC cable used, use only a shielded BNC (5) cable. Also, any unauthorized changes or modifications not expressly approved by Westinghouse Digital will void the user's authority to operate this device. -
Page 5: Cleaning The Lcd Monitor
Westinghouse Digital does not recommend the use of any ammonia or alcohol-based cleaners on the LCD Monitor screen or case. Some chemical cleaners have been reported to damage the screen and/or LCD Monitor case. Westinghouse Digital will not be liable for damage resulting from the use of any ammonia or alcohol-based cleaners. -
Page 6: Features
FEATURES • Bright Display Image • Lightweight • Fast Response Time • Stereo Speakers • Power Saver • Kensington Security Lock Compatible • Safety Certifications Power Saver A power control system, Power Saver, is installed inside the LCD monitor. If the LCD monitor has not been used for a certain period of time, the system will turn the LCD monitor to low voltage mode to save electrical power. -
Page 7: Installation
INSTALLATION Congratulations on your purchase of a Westinghouse 19” LCD Monitor. Sleek and practical, this lightweight and wall-mountable LCD monitor delivers a crisp and clear display optimized for 1280 x 1024 display resolution. Package Contents Your product package includes: • 19” Westinghouse LCD Monitor •... -
Page 8: Front View Of The Lcd Monitor
Front View of the LCD Monitor Use the buttons on the front of the LCD Monitor to display the On Screen Display (OSD). The OSD controls are defined in “OSD Functions” on page 11. • Switch between picture, text and economy modes. /▲... -
Page 9: Rear View Of The Lcd Monitor
Rear View of the LCD Monitor 1. AC IN (Power) 2. Audio-IN 3. DVI-D 4. D-SUB (VGA) 5. Lock Hole • Connect the power cord from AC IN to a power source. • Using the cable provided, connect to the Audio out (Green) from a computer. -
Page 10: Attaching The Base Stand To The Lcd Monitor
Installation 1. Attaching the Base Stand to the LCD Monitor Attach the base stand to the LCD monitor stand neck. Align the holes and tabs; press in and snap into place. To remove the base stand, press the tabs on the bottom of the stand neck and remove the base. -
Page 11: Connect Power Cables
3. Connect Power Cables Connect the AC power adapter cord to the LCD Monitor (to the connector labeled “AC-IN”) and then connect the female AC power cord to the adapter. Plug the AC power cord into a properly grounded AC outlet. Turn the Power On Press the power button on the front of the LCD monitor. -
Page 12: Mounting The Monitor Ona Wall
2. Remove the plastic covers and screws to remove the LCD monitor stand neck. 3. Use the 100mm VESA hole pattern on the back of the monitor to secure a Westinghouse Décor Wall Mount to the monitor and mount it on a wall. Step 3... -
Page 13: Osd Menu Functions
OSD Menu Functions All the function settings for the LCD monitor are controlled via the control keys located on the bottom part of the front panel. To display the OSD main menu, press the “Menu” keypad button on the control keys. (Note: The OSD menu display will disappear automatically after approximately 10 seconds, if no action is taken.) The LCD monitor has been adjusted to optimal settings before shipment. -
Page 14: Image Menu
The following is a list of the OSD sub-menus for the LCD monitor: Image Menu Function Adjust the brightness of the screen. Brightness Adjust the contrast of the image. Contrast Adjust the picture sharpness of low resolution pictures. Sharpness Adjust the LCD monitor clock. (Optional) Clock Adjust the LCD monitor phase. -
Page 15: Audio Menu
Audio Menu Function Adjust the volume of the audio. Volume Disable the audio. Mute Description... -
Page 16: Color Menu
Color Menu Function User/9300K/7500K/6500K/sRGB Color temp Adjust red color. Adjust green color. Green Adjust blue color. Blue Description... -
Page 17: Misc Menu
Misc Menu Function English, Français, Italiano, Deutsch, Español, 日本語, 简体中 Language 文, 繁體中文, Русский, 한국어 OSD time-out Adjust OSD display time setting. OSD position Move OSD display position to any one of the following 5 positions within the overall screen. Restore LCD monitor to factory settings. -
Page 18: Info Menu
Info Menu Function Displays resolution. Resolution Horizontal Displays horizontal frequency. frequency Vertical Displays vertical frequency. frequency Description... -
Page 19: Quick Adjustments
Quick Adjustments You can skip the Menu pages and display an adjustment scale directly by using the following button operations: • Brightness: Press the Brightness button when the Menu is not displayed. • Contrast: Press the Contrast button when the Menu is not displayed. •... -
Page 20: Display Modes
Display Modes The monitor backlighting can be controlled by using the Turbo button on the control keypad. There are 3 modes: Economy, Text, and Picture. To toggle between these modes, press the Turbo key until the mode you desire is selected. These modes automatically change the backlighting levels between bright, brighter, and brightest. -
Page 21: Appendix
Appendix Specifications Item Type Panel Size Optimum Resolution Response Time Contrast Ratio Maximum Brightness Viewing Angles Physical Wall/Arm Mount Video Input Signal Audio Speaker Output Voltage Power Operating Conditions Temperature Humidity Altitude Temperature Storage Conditions Humidity Altitude Unit Dimensions Carton Unit Weight Regulations... -
Page 22: Troubleshooting
Troubleshooting No Power • Make sure the DC cord is plugged into the back of the LCD monitor. • Make sure the AC power cord is securely connected to the AC socket. • Plug another electrical device (like a radio) to the power outlet to verify that the outlet is supplying the proper voltage. -
Page 23: Image Is Not Centered (Size Is Not Scaled Correctly)
• Use the 100mm VESA hole pattern to secure a mounting plate to the LCD monitor. • Use professional installation to reduce the risk of injury and damage. Additional Questions • See our website at www.westinghousedigital.com. • Contact Westinghouse Digital Customer Service at (866) 287-5555 or write us at service@westinghousedigital.com.
