AIR CAULKING GUN
Stock Number M682
SPECIFICATIONS:
Caulking tubing size (IN.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 x 8.5
Capacity (OZ.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Air pressure (P.S.I.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30-60
Average air consumption (C.F.M.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Air inlet (N.P.T.). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4
Hose size (I.D.). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8 in.
Length (IN.). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Weight (LBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.5
Specifications are subject to change without notice.
WARNING
It is the owner and/or operators' responsibility to study all WARNINGS, operating, and maintenance
instructions contained on the product label and instruction manual prior to operation of this product.
The owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning
labels and while in use, maintaining the unit in good working order. If the owner and/or operator are
not fluent in English, the product warnings and instructions shall be read and discussed with the
operators' native language by the purchaser/owner or his designee. Make sure that the operator
comprehends its contents. Safety information shall be emphasized and understood prior to usage.
The product shall be inspected per the operating instructions.
Users of this product must fully understand these instructions. Each person operating this product
must also be of sound mind and body and must not be under the influence of any substance that
might impair their vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
If you encounter any problems or difficulties, please contact our customer service department at:
1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.
Please read these instructions carefully and retain them for future use.
OWNER'S MANUAL
© Copyright 2016 WILMAR CORPORATION,
P.O. Box 88259 Tukwila, WA 98138
Advertisement
Table of Contents
Summary of Contents for Performance Tool M682
- Page 1 AIR CAULKING GUN Stock Number M682 OWNER’S MANUAL SPECIFICATIONS: Caulking tubing size (IN.) ....... .2 x 8.5 Capacity (OZ.) .
- Page 2 IMPORTANT SAFETY INFORMATION WARNING! READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY. Warning! Oil tool before each use. 4 to 5 drops of a good grade Air Tool Oil placed in the air inlet is sufficient.
- Page 3 Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Performance Tool®. Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may become hazardous when used on another tool.
- Page 4 OPERATION CAULK LOADING INSTRUCTIONS Caulk is loaded into the Caulking Gun with a standard size cartridge. WARNING: Disconnect the Caulking Gun from the air supply before filling. Loading A Caulk Cartridge 1. Unscrew the End Cap (12) from the Container Tube (11). 2.
- Page 5 PARTS LIST Description Qty. Description Qty. Inlet bushing Trigger Valve spring O-Ring Valve ball Housing adaptor Valve stem 10 Seal Handle Container tube Roll Pin 12 End cap TROUBLESHOOTING INSUFFICIENT POWER: Probable Cause Solution Dirty or clogged air passages ..Flush and lubricate tool, drain air tank and supply line Insufficient air supply ......
- Page 6 After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty.
