COMMERCIAL GAS WATER HEATER
• INSTALLATION • OPERATION • SERVICE • MAINTENANCE
Thank you for buying this energy efficient water heater. We
appreciate your confidence in our products.
PRINTED IN U.S.A. 1004
Glass-Lined Tank-Type Water Heater
PLACE THESE INSTRUCTIONS ADJACENT TO HEATER
AND NOTIFY OWNER TO KEEP FOR FUTURE REFERENCE.
TEXT IN BLACK BOLD TYPE OR UNDERLINED
CONTAINS INFORMATION RELATIVE TO YOUR
SAFETY. PLEASE READ THOROUGHLY BEFORE
INSTALLING AND USING THIS APPLIANCE.
1
CAUTION
PART NO. 196284-001
Advertisement
Table of Contents
Summary of Contents for Water Heater Innovations 196284-001
- Page 1 TEXT IN BLACK BOLD TYPE OR UNDERLINED CONTAINS INFORMATION RELATIVE TO YOUR SAFETY. PLEASE READ THOROUGHLY BEFORE INSTALLING AND USING THIS APPLIANCE. PLACE THESE INSTRUCTIONS ADJACENT TO HEATER AND NOTIFY OWNER TO KEEP FOR FUTURE REFERENCE. CAUTION PART NO. 196284-001...
-
Page 2: Rough-In Dimensions
ROUGH-IN DIMENSIONS Model Units Inches 61 1/8 58 1/2 Natural & LP 155.25 148.6 Inches 69 3/4 66 1/2 Natural 177.2 168.9 Inches 68 5/8 66 1/2 174.3 168.9 Input Approx. Approx. Rating Rating Gal. Model Btu/Hr Cap. FOREWORD The design of models ***-75 and 100 comply with the latest version of ANSI Z21.10.3-CSA 4.3 as automatic storage or automatic circulating tank type water heaters. -
Page 3: Table Of Contents
TABLE OF CONTENTS ROUGH-IN DIMENSIONS ... FOREWORD ... GENERAL SAFETY INFORMATION ... Precautions ... Chemical Vapor Corrosion ... Improper Combustion ... Liquid Petroleum Models ... Extended Non-use Periods ... Insulation Blankets ... Circulating Pump ... INSTALLATION INSTRUCTIONS ... Required Ability ... Locating The Heater ... -
Page 4: Extended Non-Use Periods
IF YOU EXPERIENCE AN OUT-OF-GAS SITUATION, DO NOT TRY TO RELIGHT APPLIANCES YOURSELF, ask your LP delivery person to relight pilots for you. Only trained LP professionals should conduct the required safety checks in accordance with industry standards. EXTENDED NON-USE PERIODS WARNING HYDROGEN GAS CAN BE PRODUCED IN A HOT WATER SYSTEM SERVED BY THIS HEATER THAT HAS NOT BEEN USED FOR A LONG... -
Page 5: High Altitude Installations
Drain pans suitable for these heaters are available from your distributor or Apcom Inc., 125 Southwest Parkway, Franklin, TN 37065 or contact them by phone, 615-794-5574 or fax 615-791-0660. Water heater life depends upon water quality, water pressure and the environment in which the water heater is installed. Water heat- ers are sometimes installed in locations where leakage may re- sult in property damage, even with the use of a drain pan piped to a drain. -
Page 6: Air Requirements
If the unconfined space is within a building of tight construction (buildings using the following construction: weather stripping, heavy insulation, caulking, vapor barrier, etc.), air for combustion, ventilation and draft hood dilution must be obtained from outdoors. The installation instructions for confined spaces in tightly constructed buildings must be followed to ensure adequate air supply. -
Page 7: Venting
VENT CONNECTION Vent connections must be made to an adequate stack or chimney. Size and install proper size vent pipe. Do not reduce pipe size to less than that of the draft hood outlet. Horizontal runs of vent pipe must have a minimum upward slope toward the chimney of 1/4 inch per foot. - Page 8 Size the main gas line in accordance with Table 1. The figures shown are for straight lengths of pipe at 0.5 in. W.C. pressure drop, which is considered normal for low pressure systems. Note: Fittings such as elbows, tees and line regulators will add to the pipe pressure drop.
-
Page 9: Gas Pressure Regulator
THERMOSTAT FOR NATURAL AND PROPANE GASES FIGURE 6. GAS PRESSURE REGULATOR The gas pressure regulator is built into the gas valve and is equipped to operate on the gas specified on model and rating plate. The regulator is factory adjusted to deliver gas to burner at correct water column pressure allowing for a nominal pressure drop through the controls. -
Page 10: Lighting Instructions
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING: ENTIRE SYSTEM MUST BE FILLED WITH WATER AND AIR PURGED AT FAUCETS A.. -
Page 11: Lighting Instructions
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING: ENTIRE SYSTEM MUST BE FILLED WITH WATER AND AIR PURGED AT FAUCETS This appliance has a pilot which must be lighted by hand. -
Page 12: Temperature Regulation
TEMPERATURE REGULATION DANGER THIS WATER HEATER IS EQUIPPED WITH AN ADJUSTABLE THERMOSTAT TO CONTROL WATER TEMPERATURE. HOT WATER TEMPERATURES REQUIRED FOR AUTOMATIC DISHWASHER AND LAUNDRY USE CAN CAUSE PAINFUL SCALDING WITH POSSIBLE SERIOUS AND PERMANENT INJURY. THE TEMPERATURE AT WHICH INJURY OCCURS VARIES WITH THE PERSON’S AGE AND THE TIME OF THE EXPOSURE. -
Page 13: Operation
• If the back draft cannot be corrected by the normal method or if a suitable draft cannot be obtained, a blower type flue gas exhauster must be employed to assure proper venting and correct combustion. HIGH TEMPERATURE LIMIT SWITCH (Auto Reset Type Energy Cut Off) TO RESET AUTOMATIC GAS SHUTOFF This water heater is equipped with a automatic reset type high... -
Page 14: Vent System
TABLE 3. INPUT CHECK TIME REQUIRED TO CONSUME 1 CU. FT. OF GAS Type of BTU Per Model Cu. Ft. ***-75 Natural 1050 Propane 2500 ***-100 Natural 1050 Propane 2500 Use this formula to “clock” the meter. Be sure that other gas consuming appliances are not operating during this interval. -
Page 15: Preventive Maintenance
PREVENTIVE MAINTENANCE RECOMMENDED PROCEDURE FOR PERIODIC REMOVAL OF LIME DEPOSITS FROM TANK TYPE COMMERCIAL WATER HEATERS The amount of calcium carbonate (lime) released from water is in direct proportion to water temperature and usage, see chart. The higher the water temperature or water usage, the more lime deposits are dropped out of the water. -
Page 16: Checklist
Prepare the Water Heater To delime the water heater using the Flo-Jug method, first prepare the heater for deliming. Then install the long plastic male adapter fitting into the drain valve opening of the water heater. Use teflon tape and hand tighten only. Do not overtighten. Prepare the Up-N-Down Transfer Kit The next step is the preparation on the Up-N-Down Transfer Kit, if you have not already done so:... - Page 17 PLUG THE TEMPERATURE AND PRESSURE RELIEF VALVE. Also, the leakage could be due to unusually high water pressures or temperatures in the system, or to a faulty relief valve. Your dealer or a qualified service technician should be called to determine the cause of the problem and to correct it. 4.
-
Page 18: Notes
NOTES... - Page 19 NOTES...
