USER' S

TFT LCD MONITOR

MANUAL

MODEL: TME32A

www.tatungusa.com

For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com

Table of Contents

Need help?

Do you have a question about the Tatung TME32A and is the answer not in the manual?

Questions and answers

Summary of Contents for Aegis Tatung TME32A

Page 1 (888)687-6877 USER’ S TFT LCD MONITOR MANUAL MODEL: TME32A www.tatungusa.com For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 2: Table Of Contents
Safety Precautions ------------------------------------------------------------------- 1 Scope -------------------------------------------------------------------------------------- 3 Functional specification ------------------------------------------------------------- 3 Controls and indicators -------------------------------------------------------------- 6 OSD Menu -------------------------------------------------------------------------------- 8 Regulatory Agency ------------------------------------------------------------------ 21 Mechanical ----------------------------------------------------------------------------- 22 Troubleshoot----------------------------------------------------------------------------24 For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 3: Fcc Information
6. Before adding attachments always ask a service technician to perform routine safety tests to determine that equipment is in safe operating condition. Ground potential tests should be part of the routine safety check made by the service technician. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 4 WARNING: SERIOUS SHOCK HAZARDS EXIST WITHIN THE COVERS OF THIS MONITOR. DO NOT OPEN THE COVERS UNDER ANY CIRCUMSTANCES, THERE ARE NO USER SERVICEABLE COMPONENTS INSIDE For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 5: Scope
VGA Input Analog RGB: 0.707 Vp-p. Support VESA Standard Timing HDMI Input HDMI Compatible Interface Digital Signal: TMDS. HDCP: HDCP 1.1 2.4 Audio Input Signal Level: 1.0 Vrms For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 6 F to 140 Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.6 EDID This series of displays support EDID, but does not support DDC2B function. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 7 2. Plug the Video signal and VGA cable to monitor. 3. Turns the PC and/or Video source power on. 4. Plug the AC power cord onto AC Socket. (Use reverse sequence to teardown the monitor). For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 8: Controls And Indicators
Press the button to turn ON or turn OFF the monitor F. POWER LED Indication Green - Power on LED light off - Power off / Sleep mode (PC mode only) For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 9 Auto: VGA mode picture Adjust VIDEO: Select CVBS source S-VIDEO: Select S-Video source Info: Display Monitor source information HDMI: Select HDMI source. VGA: Select VGA source. SDI: Reserve For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 10: Osd Menu
KEY UN-LOCK：Push MENU key for 6 sec to disable this function. RUNNING HOURS： Remove AC power-> Push " " & " " key and Plug in AC power ->Display Running Hours information. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 11 Press the Menu button to bring up the MAIN MENU Page. The following page will appear Press UP Down buttons to select an icon, then Press MENU button to change the values in the sub menu. VGA MAIN MENU For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 12 1. Press Down / UP buttons to select an icon. 2. Press MENU button to select item, 3. Press Down / UP buttons to adjust the value 4. Press MENU button to return For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 13 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item, 3. Press Down / UP buttons to adjust the value 4. Press MENU button to return For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 14 AUTO ADJUST：Press MENU buttons to auto adjust the H. Position, V. Position, Phase, Clock H. POSITION：Adjust the horizontal position value V. POSITION：Adjust the vertical position value PHASE：Adjust the phase value CLOCK：Adjust the clock value For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 15 Press MENU button to get the VGA timing information LANGUAGE：：：： Press MENU button to enter the sub-menu 1. Press Down / UP buttons to select language 2. Press MENU button to enter For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 16 ON – Every one hour there will one scan line from top to bottom ( Every 1 second down one scan line) to prevent panel sticking. AUTO SHIFT scan line For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 17 Press the Menu button to bring up the MAIN MENU Page. The following page will appear Press Down / UP buttons to select an icon, then Press MENU button to change the values in the sub menu. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 18 USER, 0: TEXT, 1: PHOTO, 2: MOVIE, 3: GAME BRIGHTNESS：Adjust the brightness value. CONTRAST：Adjust the contrast value. SHARPNESS：Adjust Image sharp. SATURATION：Adjust Image saturation. TINT：adjust Image tint. (NTSC only). BACKLIGHT：Adjust the backlight value VOLUME：Adjust the volume . For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 19 RED：Adjust the RED value for user mode. GREEN：Adjust the GREEN value for user mode. BLUE：Adjust the BLUE value for user mode. EXIT：Press MENU button to return to the main menu. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 20 2. Press Down / UP buttons to select Scan Setting state. 3. Press MENU button to return. INFORMATION：：：： Press MENU button to get the timing information. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 21 3. Press Down / UP buttons to adjust the value. 4. Press MENU button to return. OSD TIMEOUT：Adjust the OSD Show time (5 ~120 sec). GREEN MODE：Off or On (5 min~10 min). For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 22 EXIT：Press MENU button to return to the main menu. RECALL：：：： Brightness, Contrast, Sharpness, Saturation, Tint, Volume, Vivid Mode, User Color, OSD Timeout, Green Mode, Auto Shift return to default Value. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 23: Regulatory Agency
5.2 EMI/EMS Emission Approvals. This series design shall meet following EMI/EMS specifications: FCC Compliance: FCC Rules and Regulations, Part 15, subpart B, Class B. CE COMPLIANCE: EN55032 class B, EN55024, EN50130-4. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 24: Mechanical
6.2 Dimensions (Physical) Unit: mm - Weight: Model TME32A 17.6 6.3 Dimension (Packing): - Size Model Unit TME32A Inch 32.59 6.22 24.4 - Weight: Model TME32A 10.5 23.1 For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 25 Base Base Base Base Assembly Installation Assembly Installation Assembly Installation Assembly Installation Assembling Base and Neck Screw TYPE 4 * 12 mm x 4 PCS For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 26: Troubleshoot
If you are experiencing trouble with your product, try the following solutions. You may contact Tatung's service department if the problem persist at 1-800-829-2850 ext 216 or email service@tatungusa.com For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 27 WARRANTY SERVICE OF THE PRODUCT. IT IS YOUR RESPONSIBILITY TO SECURE AND/OR BACK-UP ALL PROGRAMS AND DATA CONTAINED IN OR AFFECTED BY THE PRODUCT. This warranty does not cover: For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 28 LOSS OF USE, INTERRUPTION OF BUSINESS, LOST PROFITS, LOST DATA, OR OTHER CONSEQUENTIAL, PUNITIVE, OR SPECIAL DAMAGES, HOWSOEVER CAUSED, WHETHER FOR BREACH OF WARRANTY, CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY, OR OTHERWISE For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 29 This warranty extends only to you, the original commercial purchaser, and is not transferable to anyone who subsequently purchases, leases, or otherwise obtains the product from you. For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 30 Please call us at 1-800-829-2850 ext 242 or email service@tatungusa.com or go to www.tatungusa.com click on "Support" then select either "Online repair Request Form" or Mail or Fax Repair Reques For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
