Page 1
Others: Each Country name. [Restriction of Hazardous Substances ] Hazardous substances on this product should be satisfied by substance regulation of Level A-I, A-II, SVHC according to LG(52)B—5011 standard. NOTE Especially, Part should be followed and controlled the following specification.
Page 3
Title Warning! Safety instructions Connections Preparing Troubleshooting - Lifting and moving the TV Specifications - Mounting on the Table - Mounting to the Wall - Open Source Software Notice Information - Antenna/Cable - Licenses - Satellite dish Precautions for Protecting the OLED TV Starting TV Screen...
Page 4
Warning! Safety instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Page 5
• Use only an authorized attachments / accessories approved storm. You may be electrocuted. by LG Electronics. Otherwise, this may result in fire, electric • Make sure the power cord is connected securely to the TV and shock, malfunction, or product damage.
Page 6
• Batteries - Store the accessories (battery, etc.) in a safe location out of the reach of children. - Do not short circuit, disassemble, or allow the batteries to overheat. Do not dispose of batteries in a fire. Batteries should not be exposed to excessive heat. - Caution : Risk of fire or explosion if the battery is replaced by an incorrect type.
Preparing Lifting and moving the TV Please note the following advice to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. • It is recommended to move the TV in the box or packing material that the TV originally came in. •...
Page 8
Mounting on the Table 1 Lift and tilt the TV into its upright position on a table. • Leave a 10 cm (minimum) space from the wall for proper ventilation. 2 Connect the power cord to a wall outlet. 10 cm (Depending on model) •...
Page 9
Securing TV to the Wall 1 Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV. • If there are bolts inserted at the eye-bolts position, remove the bolts first. 2 Mount the wall brackets with the bolts to the wall. Match the location of the wall bracket and the eye-bolts on the rear of the TV.
LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices.
Wall Mounting Bracket (Depending on model) Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table. OLED48/55/65A1* OLED77B1* Model OLED55/65B1* OLED83C1* OLED77C1* OLED48/55/65C1* VESA (A x B) (mm) 300 x 200 400 x 200...
Starting TV Turning on the TV You can simply operate the TV functions, using the button. <A type> <B type> Using button <A type> Power On (Press) 1) All running apps will close, and any recording in progress will stop. Power Off (Press and Hold) 2) You can access and adjust the menu by pressing the button when TV is on.
Page 13
Adjusting the menu When the TV is turned on, press the button one time. You can adjust the Menu items using the button. <A Type> Turns the power off. Changes the input source. Adjusts the volume level. Scrolls through the saved programmes. <B Type>...
NFC is technology that uses Near Field Communication, allowing you to conveniently send and receive information without separate settings. By bringing a smart device near the NFC-enabled remote control, you can install the LG ThinQ app and connect the device to the TV.
Using Remote Control Using Magic Remote Control (Depending on model) The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. Number buttons Enters numbers. Power Turns the TV on or off. Accesses the [Quick Help].
Page 16
Connections Connect various external devices to the TV and switch input modes to select an external device. For more information of external device’s connection, refer to the manual provided with each device. • When connecting the HDMI cable, the product and external devices should be turned off and unplugged. HDMI •...
Page 17
Some USB Hubs may not work. If a USB device connected using a USB Hub is not detected, connect it to the USB port on the TV directly. • For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick and 18 Note mm width.
Troubleshooting • Check the remote control sensor on the product and try again. Cannot control the TV with the remote • Check if there is any obstacle between the product and the remote control. control. • Check if the batteries are still working and properly installed ( to , to ).
Specifications (Depending on country) Broadcasting Specifications Digital TV Analogue TV PAL B/B, PAL B/G, PAL D/K, PAL-I, Television system DVB-T/T2, DVB-C, DVB-S/S2 SECAM B/G, SECAM D/K, NTSC-M DVB-S/S2 DVB-C DVB-T/T2 VHF III : 174 ~ 230 MHz UHF IV : 470 ~ 606 MHz Programme coverage 46 ~ 862 MHz 950 ~ 2,150 MHz...
Page 20
Wireless module(LGSBWAC95)Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency range Output Power (Max.) 2,400 to 2,483.5 MHz 19 dBm 5,150 to 5,725 MHz 18 dBm 5,725 to 5,850 MHz 13.5 dBm Bluetooth Frequency range Output power(Max.) 2,400 to 2,483.5 MHz 9 dBm As band channels can vary per country, the user cannot change or adjust the operating frequency.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
Page 22
Precautions for Protecting the OLED TV Screen Unlike regular LED/LCDs, OLED TVs produce images that emit light for each pixel, achieving a perfect black colour and delivering clear images without blurring. Due to the nature of the organic materials used to achieve high-resolution image quality, OLED displays generally experience image retention on the screen, which can be a persistent phenomenon.
Page 23
Recommendations for Minimising Image Retention → [Picture] → [Select Mode] and set the mode When watching the TV for a long time, press the button on the remote control, go to to [Eco] / [APS] (Depending on country), go to [Advanced Settings] → [Brightness] and set [OLED Pixel Brightness] to a lower level. In addition, →...
Page 24
Regulatory WARNING! (STABILITY HAZARD) A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: - ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of the television set. - ALWAYS use furniture that can safely support the television set.
Page 27
The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
Page 28
ﺗﺟد طراز اﻟﻣﻧﺗﺞ ورﻗﻣﮫ اﻟﺗﺳﻠﺳﻠﻲ ﻋﻠﻰ اﻟﺟﮭﺔ اﻟﺧﻠﻔﯾﺔ ﻣﻧﮫ وﻋﻠﻰ أﺣد .ﺟواﻧﺑﮫ. دو ّ ﻧﮭﻣﺎ أدﻧﺎه ﻓﻲ ﺣﺎل اﺣﺗﺟت إﻟﻰ أي ﺧدﻣﺔ اﻟطراز .اﻟرﻗم اﻟﺗﺳﻠﺳﻠﻲ...
Page 54
הדגם והמספר הסידורי של המוצר נמצאים בגב המוצר ובצד אחד שלו. רשום אותם למטה למקרה שתזדקק .לשירות דגם מס"ד...
Page 55
רגולטורי (אזהרה! )מקור לאי-יציבות מכשיר טלוויזיה עלול ליפול ולגרום לפציעה חמורה או למוות. ניתן למנוע פציעות רבות, במיוחד לילדים, על-ידי נקיטת :אמצעי זהירות כגון .צריך תמיד להשתמש בכוננית, במעמד או בשיטת תלייה המומלצים על ידי היצרן של מכשיר הטלוויזיה .צריך תמיד להשתמש ברהיט שמסוגל לשאת בבטחה את מכשיר הטלוויזיה .צריך...
Page 56
המלצות להפחתת קיפאון תמונה ← ]תמונה[ ← ]מצב בשלט הרוחק, לעבור אל כשצופים בטלוויזיה במשך זמן ממושך, יש ללחוץ על לחצן [ )תלוי בארץ(, עוברים אל ]הגדרות מתקדמות[ ← ]בהירות[ ומגדיריםAPS] / [ECO] בחירה[ ומגדירים מצב תמונה ← בשלט הרוחק, עוברים אל [ לדרגה...
Page 57
אמצעי זהירות עבור צג טלוויזיה OLED . כך מתקבלLCD מפיקות תמונות שפולטות אור עבור כל פיקסל, בניגוד לטלוויזיות רגילות עם צג לד אוOLED טלוויזיות .צבע שחור מוחלט והתמונות חדות ללא טשטוש ,OLED-טבעם של החומרים האורגאנים בהם משתמשים לקבלת תמונה איכותית במיוחד ברזולוציה גבוהה בצג ה , ואףOLED -עשויים...
Page 58
.בנוסף לקוד המקור, זמינים להורדה תנאי הרשיון, אחריות ,כתבי ויתור וזכויות יוצרים גם תספק לכם קוד מקור פתוח על גבי תקליטור בתמורה לתשלום המכסה את עלות ההפצה )כגון עלותLG Electronics .opensource@lge.com המדיה, המשלוח והטיפול(, בתגובה לבקשה בדואר האלקטורני אל הכתובת...
Page 60
מפרט ()תלוי בארץ מפרט שידור טלוויזיה אנלוגית טלוויזיה דיגיטלית PAL B/B, PAL B/G, PAL D/K, PAL-I, DVB-T/T2, DVB-C, DVB-S/S2 מערכת טלוויזיה SECAM B/G, SECAM D/K, NTSC-M DVB-T/T2 DVB-C DVB-S/S2 :VHF III MHz 230 471 עד :UHF IV MHz 606 074 עד MHz 862 64 עד...
Page 61
פתרון בעיות .בדוק את חיישן השלט רחוק במוצר ונסה שוב • לא ניתן לשלוט על .ודא שאין מכשול בין המוצר לשלט רחוק • הטלוויזיה באמצעות .השלט רחוק -ל , -ל ) ודא שהסוללות תקינות ומותקנות כהלכה • .ודא שהמוצר מופעל •...
Page 62
אינוUSB שמשתמש ברכזתUSB מסוימות עלולות שלא לפעול. אם התקןUSB רכזות . של הטלוויזיהUSBמזוהה, חבר אותו ישירות לכניסת ה צריכה להיות מסגרת שעובייהUSB ולהתקניHDMI לצורך חיבור אופטימלי, לכבלי • הערה לאUSB- או התקן זיכרון הUSB-קטן מ-01 מ"מ ורוחבה קטן מ-81 מ"מ. אם כבל ה -...
Page 63
חיבורים חיבור מקוון התקנים חיצוניים לטלוויזיה והחלפת מצבי כניסה לבחירת התקן חיצוני. למידע נוסף על חיבור התקנים .חיצוניים, עיין במדריך המסופק עם כל התקן יש לכבות ולנתק מהחשמל את המוצר ואת ההתקנים החיצוניים בעת חיבור כבל • HDMI .HDMI-ה :( נתמך )תלוי בדגםHDMI פורמט שמע •...
Page 64
שימוש בשלט רחוק Magic השימוש בשלט הרחוק של ()תלוי בדגם .התיאורים במדריך זה מבוססים על הלחצנים בשלט רחוק. קרא מדריך זה בעיון והשתמש בטלוויזיה כהלכה .כפתורי מספרים מספר כניסה .הפעלה מפעיל ומכבה את הטלוויזיה .[מאפשר גישה ל ]עזרה מהירה בין מספרים כגון )מקף( מכניס...
Page 65
היא טכנולוגיה הקרויה 'תקשורת טווח אפס'. היא מאפשרת העברת מידע - שידור וקלט - ללא שימוש בהגדרותNFC .נפרדות . ולחבר את ההתקן לטלוויזיהLG ThinQ , ניתן להתקין את היישוםNFC-כשמקרבים התקן חכם לשלט רחק המצויד ב NFC , יש להגדיר אתAndroid במכשירים מופעליNFC- בהגדרות של ההתקן החכם. לשימוש בNFC נא להפעיל...
Page 66
בחירה מהתפריט .כשהטלוויזיה מופעלת, לחץ פעם אחת על הלחצן . ניתן לבחור פריטים מהתפריט באמצעות הלחצנים <A >סוג .מחליף את מקור הכניסה .מכבה את המכשיר .גלילה בין התוכניות השמורות .כוונון את עוצמת הקול <B >סוג .'מאפשר גישה לתפריט 'הגדרות .מכבה את המכשיר .מחליף...
Page 67
הפעלת הטלוויזיה הדלקת הטלוויזיה .ניתן להפעיל את פונקציות הטלוויזיה באמצעות הלחצן <B >סוג <A >סוג באמצעות לחצן <A >סוג (הפעלה )לחיצה .כל היישומים הפועלים ייסגרו וכל תהליך הקלטה פועל יופסק ()לחיצה והחזקה כיבוי ניתן לגשת לתפריט ולבחור ממנו על-ידי לחיצה על הלחצן בקרת...
Page 68
סוגר להרכבה על הקיר ()תלוי בדגם . המידות הסטנדרטיות לערכות מתלי קיר מתוארותVESA יש להשתמש בברגים ובמתלה התקנה העומדים בתקן .בטבלה הבאה OLED48/55/65A1* OLED77B1* OLED83C1* OLED55/65B1* דגם OLED77C1* OLED48/55/65C1* 400 x 400 200 x 400 200 x 300 (( )מ"מB x A) VESA בורג...
Page 69
הקיר תבוצע על-ידי מתקין מקצועי מוסמך. אנו ממליצים על . הזווית להתקנהLG השימוש בזווית להתקנה על הקיר של קלה להזזה כשהכבלים מחוברים. אם לאLG על הקיר של , יש להשתמשLG נעשה שימוש בזווית להתקנה על הקיר של בזווית להתקנה על הקיר שבה ההתקן מאובטח כהלכה לקיר...
Page 70
לאבטח את הטלויזיה אל הקיר הכנס את בורגי העין, או את זוויות הטלוויזיה והברגים שבגב הטלוויזיה, וחזק .אותם .אם יש ברגים במקומות של בורגי העין, ראשית יש להוציא את הברגים • התקן את זוויות הקיר עם הברגים על הקיר. התאם את מיקום זווית הקיר .ובורגי...
Page 71
התקנה על שולחן .הרם את הטלוויזיה והטה אותה למצב ישר על שולחן השאר מרווח מינימלי של 01 ס"מ מהקיר לצורך אוורור • .מתאים ס"מ 01 ס"מ .חבר את כבל המתח לשקע חשמל ()תלוי בדגם אין להחיל חומרים זרים )שמנים, חומרי סיכה וכו'( על הברגים בעת הרכבת המוצר. )פעולה כזו עלולה לגרום •...
Page 72
הכנה הרמת הטלוויזיה והעברתה הקפד על העצות הבאות כדי למנוע גרימת שריטות או נזק לטלוויזיה וכדי להוביל אותה בבטחה ללא קשר לסוג או לגודל .שלה .מומלץ להעביר את הטלוויזיה בקופסה או בחומרי האריזה שבהם הגיעה הטלוויזיה • .לפני העברת הטלוויזיה או הרמתה יש לנתק את כבל המתח ואת כל הכבלים האחרים •...
Page 73
• סוללות יש לאחסן את האביזרים )סוללה וכו'( במיקום .בטוח הרחק מהישג ידם של ילדים אין לקצר או לפרק את הסוללות או לאפשר להן להתחמם יתר על המידה. אין להשליך סוללות .לאש. אין לחשוף סוללות לחום יתר זהירות: החלפת הסוללה בסוג לא נכון עלולה .לגרום...
Page 74
אין לנסות לבצע שינויים במוצר זה בכל דרך שהיא • פינים לשקע חשמל בעל 3 פינים. ודא חיבור של .LG Electronics ללא אישור בכתב מחברת .חוט ההארקה כדי למנוע סכנת התחשמלות סכנת שרפה או התחשמלות. יש ליצור קשר על לעולם אין לגעת במכשיר או באנטנה בעת סערת...
Page 75
אזהרה! הוראות בטיחות זהירות סכנת התחשמלות אין לפתוח .זהירות : כדי לצמצם את הסכנה להתחשמלות, אין להסיר את המכסה )או הגב(. אין בפנים חלקים שניתן לטפל בהם .יש לפנות לאנשי שירות מוסמכים מטרת סמל זה להזהיר את המשתמש בדבר קיומם של 'מתחים מסוכנים' לא מבודדים בתוך המוצר שעלולים .להוות...
Page 76
כותרת חיבורים אזהרה! הוראות בטיחות פתרון בעיות הכנה הרמת הטלוויזיה והעברתה מפרט התקנה על שולחן התקנה על הקיר פרטי הודעה על תוכנת קוד פתוח אנטנה/כבלים רישיונות צלחת לוויין אמצעי זהירות עבור צג טלוויזיה הפעלת הטלוויזיה OLED הדלקת הטלוויזיה Magic רישום השלט הרחוק של רגולטורי...
