Model No.: BG04-01
1：Reset
2：Network Interface
3：Power Interface
1.1 Network Interface
The
AB BLE Gateway V4
Supply(voltage range is 44~ 57V).
The ethernet port has a green LED and a YellowLED.
1.2 Power Interface
The
AB BLE Gateway V4
greater than 2000Ma. The voltage interface adopts the Micro usb .the input voltage of the 5V power adaptor is AC 100-
240V and 50/60Hz, output voltage is 5V 2A.
1.3 Reset
Long press the reset button for 5 seconds, the
Usage
•
Prepare a power adapter 5V/2A. Please note the the current 2A is required
1
network interface supports CAT-5/CAT-5E to transmit data and POE Power
power interface supports DC_5V input, input voltage range is 5-5.5 V, and the current is
AB BLE Gateway V4
3
2
internal wifi will restore factory Settings
