- Page 1 ® ViewSonic N3290w/N4290p/N4790p LCD TV 手册 ® ViewSonic...
-
Page 2: Table Of Contents
Antenna Installation Instructions ... 3 Cleaning the LCD TV ... 4 Getting Started Package Contents ... 5 Mounting ViewSonic LCD TV to the wall... 5 Place the TV on a solid Install the wall mount plate to the LCD TV... 6 Connecting the power... -
Page 3: Important Safety Instructions
The waste batteries shall be properly disposed of, and never burn it in a fire. Never expose the batteries (packaged batteries or the batteries installed in the equipment) to excessive heat, for example, the sunlight or fire and the like. ViewSonic N3290w/N4290p/N4790p... -
Page 4: Copyright Information
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. Disclaimer:ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 5: Antenna Installation Instructions
When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. Ground clamp Electric service equipment Ground clamps ViewSonic Antenna Antenna discharge unit Grounding conductors Power service grounding electrode system... -
Page 6: Cleaning The Lcd Tv
LCD TV screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the LCD TV. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. -
Page 7: Getting Started
Do not install in a moist or wet environment. This equipment is intended for indoor use. Do not install near heat source, or strong magnetic fields. Use only ViewSonic approved wall-mounting brackets to support the LCD TV weight. Before attaching the wall mount plate to the back cover, ensure the product is working. -
Page 8: Place The Tv On A Solid Surface
TV set to be left in standby to work correctly. The instructions in this manual will inform you if this applies. If you will not be using the TV set for several days, the TV set should be disconnected from the mains for environmental and safety reasons. ViewSonic N3290w/N4290p/N4790p... -
Page 9: Turn The Tv On & Off
The Auto Scan screen will be shown, and after it is done, the screen will return to the ¿rst found channel. Press the number buttons or Channel up /down to select a TV Channel. ViewSonic to perform Auto Search function. N3290w/N4290p/N4790p... -
Page 10: Overview The Lcd Tv & Connection
OSD menu appears, use to change channels in TV mode. Vol+/- ( When the OSD menu appears, press these two buttons to confirm the selected item; when no OSD menu appears, use to adjust the volume. ViewSonic button to N3290w/N4290p/N4790p... -
Page 11: Signal Source Interface From Rear View
DVD content outputted via DVI from being copied. It provides a secure digital link between a video source (DVD,PC etc.) and your TV. Content is encrypted at the source device to prevent unauthorized copies from being made. ViewSonic N3290w/N4290p/N4790p... - Page 12 Use the VGA signal cable to connect signals from a PC to the TV Input. Connect the PC audio cable supplied with the TV to the TV’s PC Audio Input. Note: If no signal is present on the VGA screen, the TV will enter into standby mode automatically after 60seconds. ViewSonic N3290w/N4290p/N4790p...
-
Page 13: Signal Source Interface From Side View
Audio Input: Connect the audio signal source (PC, DVD player, Laser Disc player, videocassette recorder or camcorder) to the audio Input ports. (Note: S-Video2 & AV2 are shared same audio input). Helpful Hints: S-Video shares audio signal with Video 2. ViewSonic N3290w/N4290p/N4790p... -
Page 14: To Use Remote Control
OSD menus. for function select, and is for function adjustment. Enter/ Press the button to confirm selection. ViewSonic POWER/ Press to turn on/off. HDMI To select HDMI/ PC input. YPbPr/ To select component input. Recall/ To display the previously... -
Page 15: Remote Control Battery Installation
7. If the battery fluid leaks inside the remote control, clean the battery compartment carefully and insert new batteries. 8. Improper battery changing may cause explosion. 9. Dispose of the used batteries in accordance with the instructions on the battery. ViewSonic N3290w/N4290p/N4790p... -
Page 16: Osd Functions
Press the MENU button on the remote control to display the OSD main menu. It offers the following options: Picture Setting, Sound Setting, Setup Setting & TV Setting. Refer to the following descriptions for details: (note: In different input source, the functions which can be adjusted are different.) ViewSonic N3290w/N4290p/N4790p... -
Page 17: Picture Setting
10. DNR: When the signal is poor, you can turn on the noise reduction function. Selection: Off, Low & High. 11. Color Temperature: You can select or adjust the color temperature according to your requirements. Selection: Cool Warm & Middle. ViewSonic N3290w/N4290p/N4790p... -
Page 18: Sound Setting
4. Sound Effect: You can choose your preferred sound effect mode. The selection including Off, News, Movie, Music, Surround, Stereo & User. 5. 100Hz, 300Hz, 1KHz, 3KHz, 10KHz: When you choose Sound Effect in User mode, you can choose the prefer frequency to increase or decrease. ViewSonic N3290w/N4290p/N4790p... -
Page 19: Setup Setting
TV signal mode and become black in other signal modes. The default is On. 7. Menu Timeout: OSD stay timer. 8. Menu Blending: Adjust menu transparency within the range from 0 to 6. 9. Reset : Used to resume the TV’s default settings. ViewSonic N3290w/N4290p/N4790p... - Page 20 6. Timed Power On/Off: Selects the Timed Power On as On (Everyday), Off (Disable) or Once (execute once). Press the “>” and then press the “ ” or “ ” key to adjust the required “On” or “Off” or “Once”, and press Exit key to leave the menu. ViewSonic N3290w/N4290p/N4790p...
- Page 21 10. Channel Skip: If set to “On”, this channel will be shielded. When you press the Channel Up/Down button, you cannot enter this channel. But when you press the digit buttons, you can enter it. To regain full access this channel, set this item to Off. ViewSonic N3290w/N4290p/N4790p...
-
Page 22: Osd Menu In Pc Mode
Selection: cool, warm & User. When you select in User mode, you can adjust Red, Green & Blue item. 4. Self Setup: When the user selects the Color Temperature as Self Setup, the color temperatures for red, green and blue can be adjusted separately. ViewSonic N3290w/N4290p/N4790p... - Page 23 Sound Effect: You can choose your preferred sound effect mode. The selection including Off, News, Movie, Music, Surround, Stereo & User. 5. 100Hz 300Hz 1kHz 3kHz 10kHz: When the sound effect is selected as Self Setup, the user may enhance or attenuate the frequency according to he or her preference. ViewSonic N3290w/N4290p/N4790p...
- Page 24 2. Wide Mode: To select picture size. Includes 2 modes: Full and 4:3. Start/Off : To setup turn on and turn off time. Menu Timeout: OSD stay timer. Menu Blending: Adjust menu transparency within the range from 0 to 6. Reset : Used to resume the TV’s default settings. ViewSonic N3290w/N4290p/N4790p...
-
Page 25: Vga Setting
2. Phase: To improve focus clarity and image stability. 3. H. Position: Adjust horizontal position on screen. 4. V. Position : Adjust vertical position on screen. 5. Auto Setting: Auto fine tune to a best status on screen. ViewSonic N3290w/N4290p/N4790p... -
Page 26: Other Information
Power Consumption (Standby) Dimensions (W)x(H)x(D) (mm) (with stand) Wall Mount Kits Wall Mount dimension Environmental Considerations Operating Temperature Operating Humanity Storage Temperature Storage Humanity ViewSonic N3290w 31.5”, 800mm 1366x768 5Wx2 D/K, I, B/G AC100-240V 50/60Hz 180W ”3W 783x559x209 Not Include 200x200mm M6x10mm, 4 pcs (Screw) 0ºC~35ºC 32ºF~95ºF... -
Page 27: Troubleshooting
Snowy picture and noise Horizontal dotted line Television not responding to remote control ViewSonic Items to Check and Actions to follow *This may be caused by obstruction to the antenna due to high rise buildings or hills. Using a highly directional antenna may improve the picture. - Page 28 • Is the image positioned correctly? Picture is cut • Are screen mode adjustments such as picture size set correctly? off/with sidebar • Press WIDE button repeatedly on the remote control to see if you can screen get the picture you prefer. ViewSonic N3290w/N4290p/N4790p...
-
Page 29: Customer Support
Note: You will need the product serial number. Web Site Country/Region China www.viewsonic.com.cn Hong Kong www.hk.viewsonic.com/support/ 852 3102 2900 service@hk.viewsonic.com Declaration of RoHS Compliance The toxic and hazardous substances or elements of this product are shown as below: Name of Components Lead Mercury... -
Page 30: Limited Warranty
How long the warranty is effective: ViewSonic LCD TV are warranted for one (1) year for all parts excluding the light source and one (1) year for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. - Page 31 ViewSonic ® Q41T4701709 1A...
