Dear Sceptre Customer,
Congratulations on your new ultra high definition SCEPTRE UMS Series UHD
Display purchase. This display supports 4K resolution. Thank you for your
support. To ensure safety and many years of trouble free operation of your
display, please read the manual carefully before making any adjustments, and
keep them in a safe place for future references. This manual contains
instructions for the U405CV-UMS, U515CV-UMS, U550CV-UMS, and
U650CV-UMS models. We hope you enjoy your new SCEPTRE UHD Display.
For technical assistance, please call 1800-788-2878 and select option 3 or
email our tech support group at SceptreTS@sceptre.com.
For all other inquiries, please call 1800-788-2878 and select option 4 or
email our customer service group at SceptreCS@sceptre.com.
Web Chat is available during business hours M-F 8:30AM-5:30PM.
We recommend you register your SCEPTRE Display at our online website
http://www.sceptre.com/registration.html.
This 4K UHD Display is MHL® ready using HDMI 1 / MHL.
This UHD Display supports 4K resolution at 60 Hz refresh rate under
HDMI 1, 2, and 3.
- 1 -
www.SCEPTRE.com
SCEPTRE UMS Series UHD Display User Manual
Advertisement
Table of Contents
Related Manuals for Sceptre U415CV-UMS
Summary of Contents for Sceptre U415CV-UMS
- Page 1 Dear Sceptre Customer, Congratulations on your new ultra high definition SCEPTRE UMS Series UHD Display purchase. This display supports 4K resolution. Thank you for your support. To ensure safety and many years of trouble free operation of your display, please read the manual carefully before making any adjustments, and keep them in a safe place for future references.
-
Page 2: Important Information
IMPORTANT INFORMATION - 2 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 3: Safety Instructions
- 3 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 4: Safety Instructions
Do not overload power strips and ventilation. To ensure reliable extension cords. Overloading can operation of the display and to protect result in fire or electric shock. - 4 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... - Page 5 Operating environment: Temperature: and the housing is damaged, the 5°C ~ 35°C, Humidity: 10% to 90% internal components may function non-condensing, Altitude: 0~10,000 ft. abnormally. Unplug the power cord - 5 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual...
-
Page 6: Important Information
Power Lines Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. - 6 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 7: Opening The Package
Opening the Package The SCEPTRE display is packaged in a carton. Any standard accessories are packed separately in another carton. Due to the size and weight of the product, it is suggested that it must be handled by a minimum of 2 or more persons. Since the glass can be easily scratched or broken, please handle the product gently. -
Page 8: Installation
Dispose unwanted electronics and batteries through an approved recycler. For TVs please visit the web at http://www.earth911.com/recycling-guide/how-to- recycle-large-electronics/ For Batteries please visit the web at http://www.call2recycle.org/ For more information, visit: www.sceptre.com/recycling.html or call (888) 580-5588. - 8 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 9: Attaching Or Removing The Stand For U405Cv-Ums
Make sure the wall is structurally safe for the weight of the Display Make sure the wall mount kit is compatible with the Display Read and follow all instructions provided by the wall mounting kit. Securely install all screws and connections. - 9 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 10: Attaching Or Removing The Stand For U515Cv-Ums
Make sure the wall is structurally safe for the weight of the Display Make sure the wall mount kit is compatible with the Display Read and follow all instructions provided by the wall mounting kit. Securely install all screws and connections. - 10 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 11: Attaching Or Removing The Stand For U550Cv-Ums
Make sure the wall is structurally safe for the weight of the Display Make sure the wall mount kit is compatible with the Display Read and follow all instructions provided by the wall mounting kit. Securely install all screws and connections. - 11 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 12: Attaching Or Removing The Stand For U650Cv-Ums
Make sure the wall is structurally safe for the weight of the Display Make sure the wall mount kit is compatible with the Display Read and follow all instructions provided by the wall mounting kit. Securely install all screws and connections. - 12 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 13: Table Of Contents
OSD (On Screen Display) Controls ........... 32 Via Remote Control ............... 32 Via Display Side Panel Buttons ............. 32 OSD (On Screen Display) Options ............ 33 PICTURE ..................33 - 13 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... - Page 14 U515CV-UMS Specification ............... 62 U550CV-UMS Specification ............... 64 U650CV-UMS Specification ............... 66 LIMITED PRODUCT WARRANTY ............ 68 Disclaimer, Trademarks, & Copyright Information ......70 FCC Compliance Statement .............. 71 - 14 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual...
-
Page 15: Identifying Front And Rear Panel
Mounting Specification: 200mm x 200mm using 4 screws sized at M5 (not included). Top two mounting holes are 14mm deep and the bottom two mounting holes are 10mm deep. - 15 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 16: Rear View Mounting Pattern For U515Cv-Ums
When you’re buying screws, you should add the original length to the thickness of your mounting plate in order to get the total screw length. Rear View Mounting Pattern For U515CV-UMS - 16 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... -
Page 17: Rear View Mounting Pattern For U650Cv-Ums
When the OSD is active, this button acts as the enter button and confirms the menu selection. – Turn on the display by pressing the button once. Press the button again to turn off the display. - 17 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... - Page 18 - 18 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual...
-
Page 19: Rear View Connections
HDMI 2 (ver.2.0) – HDMI 2 houses a HDMI version 2.0 connection. Under ultra HD 4K x 2K resolution this connection supports 60 Hz refresh rate and - 19 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... - Page 20 10 minutes of idling on a connection with no signal. This feature is present on all connection. TV tuner is an optional item for this display. - 20 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual...
-
Page 21: Sceptre Remote Control
SCEPTRE Remote Control This remote control follows SONY’s universal remote code. To find the actual code you need to consult your cable or satellite tech support. - 21 - www.SCEPTRE.com SCEPTRE UMS Series UHD Display User Manual... - Page 22 VOL(+) – This button increases the volume of the sound bar. POWER – This button turns on the sound bar. Please Note: Buttons encircled by the word SOUND BAR are to be used with a Sceptre’s sound bar only.
-
Page 23: Installing Batteries To The Remote Control
Keep the batteries away from children and pets. If the remote control is not used for a long time, remove the batteries. Keep the remote control away from moisture, sunlight, and high temperatures. - 23 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 24: Connection Suggestions
The UHD TV’s tuner is designed for UHD display therefore requires a stronger signal than normal displays. If you cannot achieve that signal level with your antenna or cable, your UHD display might lose picture or sound. - 24 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 25: Connecting Dvd Player With Component Ypbpr
YPbPr. Please reference the DVD player’s manual, to make sure the DVD player is configured to output correctly to the display. This source shares audio jacks with composite video. - 25 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 26: Connecting Wii™ With Composite
Use the remote control’s source button or the source button on the display to switch to AV. Please Note: Make sure to read your Wii™ installation guide for further information. - 26 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 27: Connecting Cable Or Satellite Boxes With Hdmi
Please reference the set-top box’ manual, to make sure the set-top box is configured to output correctly to the display. Sceptre’s UHD display supports SONY’s universal remote code. Please look up SONY’s codes in your universal remote’s hand book. -
Page 28: Connecting To A Pc With Hdmi
2160 at 60 Hz. Please refer to the PC or graphic card’s manual for further instructions on how to set your resolution and refresh rate. Please refer to your PC manual for video output requirements of the video card. - 28 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 29: Connecting A Digital Audio Receiver With Optical Spdif
The display’s SPDIF out for 5.1CH is ONLY used for antenna/cable connection. Any other incoming audio signal will be passed out of SPDIF in PCM format. - 29 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 30: Switching Sources
Satellite or Cable Company for support. ***TV Source is optional. It may not be equipped in your product. Please check with the seller, distributor or Sceptre Customer Services. - 30 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 31: Ready To Watch Some Tv
Once the scanning finishes, you can begin to watch display. ***TV Source is optional. It may not be equipped in your product. Please check with the seller, distributor or Sceptre Customer Services. - 31 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 32: Osd (On Screen Display) Controls
CH(▲/▼) – These buttons functions as up/down direction in the OSD. – This button opens the OSD and also exits out of menus. – This button acts as the enter button to enter each function or option. - 32 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 33: Osd (On Screen Display) Options
SETUP – This main option has functions for all ports, OSD language, caption styles, time setup, and channel setup, sleep, reset display functions. PICTURE This option allows users to adjust the display’s picture sharpness, color, tint, and other various functions. - 33 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 34 (Normal, Wide, Cinema, Zoom, FULL 100%). III. COLOR TEMPERATURE – This feature adjusts the color temperature of the display, giving warm, normal, and cool, (warm being redder, cool being bluer and normal being neutral color). - 34 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
- Page 35 Please Note: If you use POWER SAVING as your picture mode, the screen’s color, and brightness will be reduced. - 35 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
-
Page 36: Sound
(presets include standard, soft, user SRS, and dynamic). BASS – This feature adjusts the audio bass level of the display. iii. TREBLE – This feature adjusts the audio treble level of the display. - 36 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 37 Second audio programming is dependent on the support of the TV station you are watching. If they do not have a second audio programming (SAP), this function will not work. - 37 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
-
Page 38: Channel
(such as using antenna) and cable. AUTO CHANNEL SEARCH – This feature searches channels automatically for you. Please Note: The TV tuner in this display does not support QAM. - 38 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 39: Setup
CC1. TEXT1-4 displays advertisements of the channel. iii. DIGITAL CAPTION TYPE – This chooses the subchannel for digital channel closed captioning. DIGITAL CC PRESET – This unlocks users ability to change caption styles. - 39 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 40 OSD TIMER – This function adjusts the idle duration the MENU stays on the screen. SLEEP TIMER – This function adjusts the time duration for the display to turn off automatically. - 40 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
- Page 41 CONNECT – This turns on CEC devices through this menu. vii. ROOT MENU – This shows CEC compatible device’s own menu. VIII. SOURCE LABEL – This feature edits the name of each source. - 41 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
- Page 42 NO SIGNAL POWER OFF – This feature turns the display off if there is no signal given to the display after a certain (10 minutes) time. - 42 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
- Page 43 TEXT1-TEXT4 offers you local information; however it might not be support by your local broadcasting station. When no information is offered, you will see a large black box in the middle of the screen. - 43 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
-
Page 44: Detailed Explanations
Once you press the USB button the USB menu will come up. Select either the music or picture you want to browse using the arrow buttons. Press the ENTER button to select the file you want. Browsing Music and Photo In the USB function, select Music or Photo. - 44 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 45 The music function only supports MP3 that is from 32-48k Hz using a data rate of 32-320 kbps. All USB functions are operated by the remote control. None of the buttons physically located on the display will respond to USB functions. - 45 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
-
Page 46: Closed Captioning (Digital And Analog) Explained
(e.g., weather or news). These services are also superimposed over the program currently being viewed. Closed Captioning for this display only works under sources TV, and AV. - 46 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 47: Mhl Explained
MHL cable and connect one end (usually micro USB) to your mobile device and the other end to HDMI 1. Turn on both the mobile device and the Sceptre display and press the MHL button and things displayed on the mobile device will be displayed on the display. -
Page 48: Direct Function Buttons
Sceptre Sound Bar The Sceptre Sound Bar is an add-on speakers designed to connect to any flat panel display or UHD display including Sceptre’s own. These direct function buttons above help eliminate the use of the Sound Bar remote. -
Page 49: Hdmi Arc (Audio Return Channel) Explained
HDMI ARC (Audio Return Channel) Explained This Sceptre display has the feature ARC (Audio Return Channel) on HDMI 4. ARC is a feature that enables a display, via a single HDMI cable, to send audio data to an AV receiver or surround sound DVD / Blu-ray player. This feature eliminates the necessity of having a separate S/PDIF audio connection for sending display audio to the receiver. -
Page 50: Ratings Explained
L - Adult Language D - Sexually Suggestive Dialog MPAA Rating G (MPAA) General audiences. All ages admitted. PG (MPAA) Parental guidance suggested. Some material may not be suitable for children. - 50 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 51 NC-17 (MPAA) No one 17 and under admitted. X (MPAA) X is an older rating that is unified with NC-17 but may be encoded in the data of older movies. - 51 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
-
Page 52: Aspect Ratio Explained
16:9 ratio. Because of the zoom, the top and bottom are cut off as well. DOT BY DOT This mode is only available under PC. It will map dot by dot to the screen. Any resolution will be proportionate. - 52 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 53: Shortcuts To Browsing Channels
Use the ▲ or ▼ buttons to select the channel you want to jump to and press ENTER to confirm. You can also use the FAV+/- keys to switch up and down the favorites list automatically. - 53 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 54: How Do I Clean The Display
Wipe the display with a dry micro-fiber cloth or 100% cotton cloth afterwards. - 54 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... -
Page 55: Troubleshooting
ATSC/NTSC TUNER Please adjust your picture setup and make sure the saturation and the RGB are not turned all the way down. For adjustment NO COLOR controls refer to page 27. - 55 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 56 I CANNOT CHANGE Your display syncs time automatically according to your local THE TIME TV channel. This function only works while the display’s tuner MANUALLY is connected to an ANTENNA. - 56 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
- Page 57 For total control you will need to use the cell phone’s touch DISPLAY’S REMOTE screen. The display’s remote have limited functions and its WON’T CONTROL controls are dependent on the program you are using. THE CELL PHONE - 57 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
- Page 58 HDMI 1.4 or higher. Make sure RESOLUTION 3840 the drivers are upgraded to the newest version possible. x 2160 WHILE CONNECTED TO HDMI - 58 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
-
Page 59: Call Us If You Need Help
For more information on warranty services or repairs after the warranty period, please contact our support department at the number below. For technical help, contact our Sceptre Technical Support Group via email or phone. Please have your Sceptre Product Number (P/N), Serial Number (S/N), and date of purchase available before you call. -
Page 60: U405Cv-Ums Specification
Brightness / Contrast / Color / Tint / Sharpness (2)Audio Sound Mode Dynamic / Standard / Soft / User Auto Volume Control Tone Bass / Treble / Balance SPDIF Out Yes (Optical) Speakers 10 watt per channel - 60 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 61 *The product’s specifications may change without notice or obligation. TV tuner is optional. **This manual’s pictures and words are for references only and are subject to change without notice or obligation. Sceptre Inc. is not liable for the misuse or misinterpretation of this manual. - 61 - www.SCEPTRE.com...
-
Page 62: U515Cv-Ums Specification
Brightness / Contrast / Color / Tint / Sharpness (2)Audio Sound Mode Dynamic / Standard / Soft / User Auto Volume Control Tone Bass / Treble / Balance SPDIF Out Yes (Optical) Speakers 10 watt per channel - 62 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 63 *The product’s specifications may change without notice or obligation. TV tuner is optional. **This manual’s pictures and words are for references only and are subject to change without notice or obligation. Sceptre Inc. is not liable for the misuse or misinterpretation of this manual. - 63 - www.SCEPTRE.com...
-
Page 64: U550Cv-Ums Specification
Brightness / Contrast / Color / Tint / Sharpness (2)Audio Sound Mode Dynamic / Standard / Soft / User Auto Volume Control Tone Bass / Treble / Balance SPDIF Out Yes (Optical) Speakers 10 watt per channel - 64 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 65 *The product’s specifications may change without notice or obligation. TV tuner is optional. **This manual’s pictures and words are for references only and are subject to change without notice or obligation. Sceptre Inc. is not liable for the misuse or misinterpretation of this manual. - 65 - www.SCEPTRE.com...
-
Page 66: U650Cv-Ums Specification
Brightness / Contrast / Color / Tint / Sharpness (2)Audio Sound Mode Dynamic / Standard / Soft / User Auto Volume Control Tone Bass / Treble / Balance SPDIF Out Yes (Optical) Speakers 10 watt per channel - 66 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual... - Page 67 *The product’s specifications may change without notice or obligation. TV tuner is optional. **This manual’s pictures and words are for references only and are subject to change without notice or obligation. Sceptre Inc. is not liable for the misuse or misinterpretation of this manual. - 67 - www.SCEPTRE.com...
-
Page 68: Limited Product Warranty
(SCEPTRE reserves the right to determine “wear and tear” on any and all products); unsatisfactory visual or audio performance not caused by a manufacturing defect;... - Page 69 Dead Pixel Policy SCEPTRE sets limit on the LCD at 3 dead pixels in a cluster adjacent to each other, or 5 dead pixels in a combination of color and brightness. Any number of dead or bad pixels under the limit is considered to be within normal performance specification of the LCD and is not considered defective.
-
Page 70: Disclaimer, Trademarks, & Copyright Information
SCEPTRE is a trademark or registered trademark of Sceptre Group. Sceptre, Inc. shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 71: Fcc Compliance Statement
European Notice Products with the CE marking comply with both the EMC Directive (89/336/EEC), (93/68/EEC) and the Low Voltage Directive (72/23/EEC) issued by the Commission of the European Community. - 71 - www.SCEPTRE.com SCEPTRE U500 UHD TV User Manual...
