INTRODUCTION
A local area
WiFi
network allows users to easily exchange data between computers located in the same room
or in different rooms, share an Internet connection and/or a printer among several computers, play network
games and, above all, does away with the need for kilometers worth of cables.
By following the instructions in this manual, you will be able to install a local area WiFi network and secure it.
MORE DETAILED INFORMATION
Once installation of the drivers for your key is complete, you can access a more detailed manual, in PDF
format, directly on your computer by clicking Start - All Programs - Hercules Wireless N USB mini. In it, you
will find all of the information you need to learn how to configure and use your Hercules Wireless N USB mini.
HERCULES WIRELESS N USB MINI INSTALLATION
Before connecting your Hercules Wireless N USB mini, you must first install Hercules WiFi
Station N, which includes the drivers and the WiFi Station N application, a utility for detecting networks
and configuring network settings.
1 -Installing the WiFi Station N pack and the USB key
To install Hercules WiFi Station N, proceed as follows:
- Insert the included installation CD-ROM into your CD-ROM drive.
The installation menu appears automatically.
If the installation menu does not launch automatically:
- Double-click My Computer or Computer (Windows Vista).
- Double-click
- If necessary, double-click Setup.exe
- Click Install WiFi Station N.
- Follow the on-screen instructions.
Windows XP/2000/Vista
- When the installation Assistant prompts you to connect
your WiFi adapter, connect your Hercules Wireless N
USB mini to a USB port. For information on the
different ways to connect the Hercules Wireless N USB
mini to your computer, please refer to the PDF manual
- Chapter 2.2 Connecting Hercules Wireless N USB
mini to your computer.
.
.
Hercules HWNUm-300
Quick Start Guide – 1/6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HWNUm-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hercules HWNUm-300

  • Page 1 Start - All Programs - Hercules Wireless N USB mini. In it, you will find all of the information you need to learn how to configure and use your Hercules Wireless N USB mini.
  • Page 2 CD-ROM. NB 2: It is possible not to press the button on the Hercules Wireless N USB mini key using the method known as PIN. The WiFi Station N software gives you access to a user interface, and will guide you through this procedure.
  • Page 3 Hercules HWNUm-300 The list of networks connection method: Please launch the WiFi Station N software if it is not already running, and refer to the main page; a scan of available WiFi networks is carried out automatically. The List of detected networks lists all security-enabled, non security-enabled or hidden networks, of Infrastructure or Ad hoc type.
  • Page 4: Technical Support

    Hercules HWNUm-300 TECHNICAL SUPPORT If you encounter a problem with your product, please go to http://ts.hercules.com and select your language. From there you will be able to access various utilities (Frequently Asked Questions (FAQ), the latest versions of drivers and software) that may help to resolve your problem. If the problem persists, you can contact the Hercules products technical support service (“Technical Support”):...
  • Page 5: Warranty

    Where authorized by applicable law, the full liability of Guillemot and its subsidiaries (including for indirect damages) is limited to the repair or replacement of the Hercules product. The consumer’s legal rights with respect to legislation applicable to the sale of consumer goods are not affected by this warranty.
  • Page 6: Important Note

    Hercules HWNUm-300 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
