CA8000D-Series
Models CA8000D, CA8000DX, CA8000DE, CA8000DXE, CA8000DEC
Professional Amplifier
User Instruction Manual
© 2016 Bogen Communications, Inc.
All specifications subject to change without notice.
Apogee Sound International, LLC reserves the right
to make changes or improvements in manufacturing
and design that may affect specifications.
54-2234-01C 1802
Advertisement
Table of Contents
Related Manuals for Apogee Sound CA8000DEC
Summary of Contents for Apogee Sound CA8000DEC
- Page 1 CA8000D-Series Models CA8000D, CA8000DX, CA8000DE, CA8000DXE, CA8000DEC Professional Amplifier User Instruction Manual © 2016 Bogen Communications, Inc. All specifications subject to change without notice. Apogee Sound International, LLC reserves the right to make changes or improvements in manufacturing and design that may affect specifications.
- Page 2 CA8000D-Series Models CA8000D, CA8000DX, CA8000DE, CA8000DXE, CA8000DEC Professional Amplifiers Before using Apogee CA8000D-Series Professional Amplifiers, please view the product’s documentation to familiarize yourself with the products’ features and operation. Visit http://www.apogeesound.com and navigate to the products’ dedicated page. Or enter the appropriate URL listed below: •...
-
Page 3: Table Of Contents
3.2 Input Attenuators ..................4 3.3 Indicators ....................4-5 4. Cleaning ......................5 5. Specifications, Features, and Diagrams..........6-9 5.1 Technical Specifications ................6 5.2 Unit Function List ..................7 5.3 Figures ....................8 5.4 Block Diagram..................9 6. Warranty ....................10 CA8000D-Series Models CA8000D, CA8000DX, CA8000DE, CA8000DXE, CA8000DEC... - Page 4 This Page Intentionally Left Blank...
-
Page 5: Introduction
In order to obtain maximum functionality, it is important to carefully read this manual before connecting and using the amplifier. If any repair or maintenance task should ever be needed, please contact Apogee Sound International. We want to be sure that your product is serviced by authorized professionals, so it will continue to meet the highest standards of quality. -
Page 6: Installation
2. Installation 2.1 Location / Assembly / Ventillation • The CA8000D-Series amplifier is a 2 RU high (3.5”) x 19'' wide rack module. It is important to recognize that the amplifier is a heat source and should not be placed next to other equipment that is susceptible to heat, nor should the amplifier itself be exposed to high temperatures from other nearby equipment. -
Page 7: Auxillary Ground Lug
2. Installation 2.4 Auxillary Ground Lug All CA8000D-Series amplifiers are equipped with a signal ground lug. This lug is NOT intended as a primary AC power ground, which instead should be connected to the building ground by means of the power cord. The ground lug is electrically tied to the chassis and can be useful as a means of reducing the chassis ground impedance, thereby eliminating ground loops between devices when setting up a sound system. -
Page 8: Operation And Usage
3. Operation and Usage 3.1 Start Up Pushing the POWER SWITCH illuminates the LED Power Indicator and activates the start-up sequence. Initially, both red CLIP LEDs will illuminate during start-up, while the amplifier performs a diagnostic check and stabilizes all internal voltages. After approximately 10 seconds, the CLIP LEDs will turn off indicating that the amplifier is now ready for use. -
Page 9: Cleaning
3. Operation and Usage 3.3 Indicators (cont’d) TEMP (thermal protection indicator). This indicator illuminates to warn that the tunnel cooling temperature has risen above 90 degrees centigrade. If this occurs, the amplifier will be temporarily shut down by the thermal monitor circuit in order to protect it from damage. -
Page 10: Specifications, Features, And Diagrams
(482.6mm x 88mm x 470mm) Weight:........................50 lbs. (22.7kg) † Internally Configured CA8000D CA8000DX CA8000DE CA8000DXE CA8000DEC (120V~)* (120V~ + DLX24i)* (240V~)* (240V~ + DLX24i)* (220V~)** * Listed to UL Standard 60065 for US/Canada and CE compliant ** CCC certified for China... -
Page 11: Unit Function List
5. Specifications, Features, & Diagrams 5.2 Unit Function List CA8000D Front Panel 1. Input Attenuators with Tamper-proof Covers 2. Combined Clip and Protection Indicator: CLIP/PROT 3. Thermal Protection Indicator: THERMAL 4. Signal Present Indicator: SIGNAL 5. Illuminated Mains Switch: POWER ON CA8000D Rear Panel 6. -
Page 12: Figures
5. Specifications, Features, & Diagrams... -
Page 13: Block Diagram
5. Specifications, Features, & Diagrams... -
Page 14: Warranty
6. Warranty; Exclusion of Certain Damages The Apogee CA8000D-Series Power Amplifiers are warranted to be free from defects in material and workmanship for 3 (three) years from the date of sale to the original purchaser. Any part of the product covered by this warranty that, with normal installation and use, becomes defective (as confirmed by Bogen upon inspection) during the applicable warranty period, will be repaired or replaced by Apogee, at Apogee’s option, provided the product is shipped insured and prepaid to the Apogee Factory Service Department. - Page 15 N O T E S...
- Page 16 www.apogee-sound.com...
