AC-MXMV122-UHD
Video Flux User Manual
AC-MXMV122-UHD
Video Flux features 16 available (12 at a time) input
options including composite, component, VGA, and
HDMI. It also has the ability to do 4K Quad View or
completely customize-able Multi-view.
pg. 1
AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
support@avproedge.com
Advertisement
Related Manuals for AVProEdge AC-MXMV122-UHD
Summary of Contents for AVProEdge AC-MXMV122-UHD
- Page 1 Video Flux features 16 available (12 at a time) input options including composite, component, VGA, and HDMI. It also has the ability to do 4K Quad View or completely customize-able Multi-view. pg. 1 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
-
Page 2: Product Overview
HDMI from 480i up to full-HD (on Consumer CEA) and WUXGA (VESA). The AC-MXMV122-UHD is a single unit that is ideal for applications requiring up to 4 separate video sources on a single display in applications such as Digital Signage, Teleconferencing, Highway checkpoint Control Rooms, Multi-View outdoor... - Page 3 AC-MXMV122-UHD Features The AC-MXMV122-UHD is a powerful Video Processing device in a 1U rack-mount chassis, with low power consumption (less than 20W). Four video inputs, widely compatible to any SD/HD Digital (HDMI/DVI) and SD/HD Analog in AV (CVBS) / YPbPr and VGA input.
- Page 4 AC-MXMV122-UHD Application Examples pg. 4 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 5 4 inputs in the screen windows when using the Multi-View configuration. Seamless Matrix Mode pg. 5 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
-
Page 6: Operation Controls And Functions
This mode allows the creation of matrix systems with more video inputs that can be routed to either of the two output screens. Note that in this mode, the first two HDMI inputs of the right-hand AC-MXMV122-UHD are used to cascade the outputs from the left-hand AC-MXMV122-UHD. - Page 7 PIP mode. Repeated presses of the same button cycles the main and PIP images through the four inputs. The AC-MXMV122-UHD can be cascaded to create a larger system such as an N input seamless switcher, Nx2 seamless matrix or MxN Multiviewer. The RS232 control signals can also be cascaded by using an RS232 cable from the pass through RS232 port to the RS232 input port of the next AC-MXMV122-UHD.
- Page 8 The checksum value is the negated sum of all values before the Checksum field. The first byte of the header denotes the type of data: AAH for a command to the AC-MXMV122-UHD, or ABH for a reply from the AC-MXMV122-UHD.
- Page 9 The following commands can only be used while in MODE1 & MODE2 & MODE3 3800H Select input video 4 BYTES Refer to Table source for the four inputs pg. 9 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 10 MV mode base on Table 9 A852H Read colour of 0 BYTES MCU will reply image border line base on Table 6 pg. 10 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@ .com...
- Page 11 AA + ID + 06 00 00 00 38 38 ~~~~~~ (256 BYTES) + checksum >AC-MXMV122-UHD: If the AC-MXMV122-UHD fails to read the EDID data from the sink device, the reply to the PC is: AC- MXMV122-UHD ->PC: AB+ ID + 06 00 00 00 38 B8 00 + checksum If the AC-MXMV122-UHD successfully reads the EDID, the reply to the PC is: AC-MXMV122-UHD ->PC:...
- Page 12 High byte of the right-bottom corner Y coordinate of the third priority image Low byte of the left-top corner X coordinate of the lowest priority image pg. 12 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 13 IN3 in Single Input Mode at 1080p IN4 in Single Input Mode at 1080p Table 8 - Set Quad-View or Single Input View pg. 13 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@ .com...
- Page 14 Table 14 - Select Internal EDID Data Byte number Description Note Mode Index 1-HD MV 2-3:2 seamless matrix 3-4KMV Table 15 - Set System Operating Mode pg. 14 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 15 R = Right ending pixel position T = Top starting line position B = Bottom starting line position) Table 20 - Demo Mode List Setting pg. 15 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@ .com...
- Page 16 0 = Demo Mode A 1 = Demo Mode B 2 = Demo Mode C 3 = Demo Mode D Table 21 - Recall Demo Mode pg. 16 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 17 Damage caused by mistreatment of the product Please direct any questions or problems you may have to your local dealer before contacting AVProConnect. pg. 17 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 18 AC-MXMV122-UHD pg. 18 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 19 AC-MXMV122-UHD pg. 19 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
- Page 20 2222 E 52nd St N ~ Sioux F a lls , SD 57104 1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 605-274 -6 05 5 pg. 20 AVProEdge ~ 2222 E 52nd St N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproedge.com...
