USSC
1
MAY BE INSTALLED IN A MANUFACTURED HOME (MOBILE HOME)
Distributed By:
WARNING: If the information in these instructionsare not followed exactly, a fire or explosion mayresult causing property damage, personal injury,or loss of life.~Do not store or use gasoline or other flammablevapor
Save this manual forfuture reference.This appliance is only for use withthe type of gas indicated on therating plate. This appliance is notconvertible for use with othergases.
MODEL:
DV20MODEL
Advertisement
Table of Contents
Related Manuals for United States Stove Company LONGVIE DV12
Summary of Contents for United States Stove Company LONGVIE DV12
- Page 1 USSC MAY BE INSTALLED IN A MANUFACTURED HOME (MOBILE HOME) Distributed By: WARNING: If the information in these instructionsare not followed exactly, a fire or explosion mayresult causing property damage, personal injury,or loss of life.~Do not store or use gasoline or other flammablevapor Save this manual forfuture reference.This appliance is only for use withthe type of gas indicated on therating plate.
-
Page 2: Local Codes
GAS SPECIFICATIONS FUEL Natural Liquid Propane Natural Liquid Propane Natural Gas - DV12 - 5.8” w.c. Propane / LP Gas - DV12 - 10.8” w.c. 3/8” NPT MIN. PRESSURE 7” W.C.P. 11.0” W.C.P. Batterymarch Park Quincy, MA 02269 MAXIMUM INPUT... -
Page 3: Safety Rules
Due to high temperatures, the appliance should located out of traffic and away from furniture and draperies. Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the same room as the appliance Clothing or other flammable material should not be placed on or near the appliance. - Page 4 Also take into consideration the other minimum distances shown on Diagram Nº 1. MINIMUM CLEARANCES TO Diagram Nº 1 Sides Model - DV12 Diagram Nº 2 Model - DV20 7 Inches / 18cm (to top of carpeting, tile, etc.) 24.Inches / 61cm...
-
Page 5: Ventilation Installation
Slide the heater and ventilation assembly through the hole until the heater reaches the wall. For the model DV12, se- cure to the wall with the three(3) screws provided. For the model DV 20, secure to the wall with the four(4) screws pro- vided. - Page 6 VENTILATION INSTALLATION Minimum wall thickness: 4-1/2” (11.5cm) Maximum wall thickness: 13-1/2” (35 cm) Diagram Nº 5 Diagram Nº 7 IMPORTANT: The appliance’s vent cap should be at least 24 in.(61 cm) from any outside adjacent or intersecting wall. IMPORTANT: The appliance’s venting system should be inspected at least once a year and cleaned if necessary.
- Page 7 Clearance above grade, veranda, porch, deck, or balcony Clearnace to window or door that may be opened Clearance to permanently closed window Vertical clearance to ventilated soffit lo- cated above the terminal within a horizon- tal distance of 2 feet (61 cm) from the cen- ter line of the terminal Clearnace to unventilated soffit Clearance to outside corner...
- Page 8 VENTILATION INSTALLATION continued... Diagram Nº 8 USSC...
-
Page 9: Gas Connection
A qualified gas appliance installer must connect the heater to the gas supply. Consult all local codes. Use new black iron or steel pipe only. Internally tinned copper tubing can be used in some areas when permitted by local codes. Only use pipe of 1/2" or greater diameter to allow full gas volume to heater. -
Page 10: Operating Instructions
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. This appliance has a pilot which can be light with the equipped piezo ignitor. When lighting the pilot, follow these instructions exactly. -
Page 11: Maintenance Instructions
As with all fuel burning appliances, it is important to conduct periodic maintenance functions that will allow for contin- ued safe, efficient operation of the unit. We suggest that before every heating season, or at least once a year, conduct the following minimum service functions. -
Page 12: Wiring Schematic
Diagram Nº 11. Correct Flame Pattern Optional Blower - DVBS (DV12) and DVBL (DV20) CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Permanently lubricated bearing system. - Page 13 DV20 - REPAIR PARTS USSC...
- Page 14 PART # 2478 17501 2484 2482 2472 16374 15901 2471 10.1 16377 11.1 16376 12.1 2472 13.1 2473 14.1 16360 15.1 15756 16.1 2466 17.1 2465 18.1 19.1 2463 20.1 2464 21.1 12455 22.1 11699 23.1 11698 24.1 16365 25.1 11626 26.1 2477...
- Page 15 DV12 - REPAIR PARTS USSC...
- Page 16 17767 31.2 32.2 17912 33.2 11634 34.2 11315 DV12 - REPAIR PARTS LIST DESCRIPTION Glass Support Combustion Chamber Glass Ceramic Fibre Glass Gasket (Long) Ceramic Fibre Glass Gasket (Short) Combustion Chamber Ceramic Fibre Washer (D57 / D43) Air Intake Tube...
- Page 17 BURNER ASSEMBLY - REPAIR PARTS USSC...
- Page 18 Control Rod Set Screw (1/8” x 15) Eurosit Valve By Pass 50 (for model DV12-LP) Eurosit Valve By Pass 90 (for model DV20-LP) Eurosit Valve By Pass 70 (for models DV20-N and DV12-N) Eurosit Gas Control Valve - Liquid Propane Eurosit Gas Control Valve - Natural Gas Inlet Fitting 3/8”...
- Page 19 Outgoing Flue Gases Tube - DV20 (Internal) Air Incoming Tube - DV20 (External) Enameled Vent Cap - DV20 Connecting Rod Connecting Rod Nut Outgoing Flue Gases Tube - DV12 (Internal) Air Incoming Tube - DV12 (External) Enameled Vent Cap - DV12 QTY.
- Page 20 The PART NUMBER The PART DESCRIPTION The MODEL NUMBER: The SERIAL NUMBER _____________________ Save this manual for future reference. United States Stove Company DV12, DV20 Owner's Manual DV12 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380...
