Summary of Contents for BH HI POWER SK Series

  • Page 1 G-690 / G-690TV LINE sportkoncept Instrucciones de montaje y utilización Instructions for assembly and use Instructions de montage et utilisation Montage und gebrauchsanleitung Instruções de montagem e utilização Istruzioni di montaggio e uso Montage-en gebruiksinstrukties...
  • Page 2 G-690 / G-690TV LINE sportkoncept (E) Fig. 1 A)- Monitor. a) - Tornillo de M-10x70 Cantidad 8 B)- Cuerpo principal. b) - Tornillo de M-5x10 Cantidad 14 C)- Manillar Apoyamanos. c) - Tuerca de M8 Cantidad 4 D)- Barandilla Izquierda. d) - Tornillo de M-4x10 Cantidad 2 E)- Barandilla Derecha.
  • Page 3 G-690 / G-690TV LINE sportkoncept Fig. 2 Fig. 3 Fig. 4...
  • Page 4 G-690 / G-690TV LINE sportkoncept Fig. 5 Fig. 6 Fig. 7 Fig. 8...
  • Page 5: Indicaciones De Seguridad

    G-690 / G-690TV LINE sportkoncept ESPAÑOL -Utilice el modelo SK únicamente de la forma INDICACIONES DE SEGURIDAD indicada en este manual. No utilice accesorios PRECAUCIONES anexos que no estén recomendados por el Este aparato de ejercicio ha sido diseñado y fabrican-te;...
  • Page 6: Instrucciones De Montaje

    G-690 / G-690TV LINE sportkoncept -Nunca lance ni inserte ningún objeto en ninguna de las aperturas de la máquina. -No utilizar la máquina al aire libre. Mantenga las toallas y las manos lejos de las partes móviles. -No realice tareas de mantenimiento y/o reparación mas allá...
  • Page 7: Mantenimiento

    G-690 / G-690TV LINE sportkoncept Barandilla derecha; (F) Tapa trasera del monitor; (c),apriete fuertemente. (G) Botellin; (a) Tornillo de M-10x70; (b) Tornillo M- 5x10; (c) Tuerca de M8; (d) Tornillo M-4x10; (e) COLOCACIÓN DEL MONITOR. Tornillo M-4x12; (f) Interruptor; (g) Lave punta en Coja el monitor (A) y conexione los terminales cruz;...
  • Page 8 G-690 / G-690TV LINE sportkoncept INSTRUCCIONES DE USO AJUSTE DE BANDA Un mal asentamiento de la unidad en los cuatro CONDICIÓN FÍSICA puntos de apoyo puede producir un desplazamien- Estar en forma física, significa vivir plenamente. En to lateral de la banda (X). Un riguroso control de la sociedad moderna se sufre de una gran tensión.
  • Page 9 G-690 / G-690TV LINE sportkoncept NOTA FINAL PROGRAMA DE EJERCICIO Esperamos que disfrute de su unidad. Con su Antes de comenzar cualquier programa de programa controlado de ejercicios se dará cuenta ejercicio y teniendo en cuenta qué programas de de las ventajas, de sentirse mejor, con más vigor y ejercicio varían en función de la edad y del estado con más resistencia a la tensión.
  • Page 10 G-690 / G-690TV LINE sportkoncept LOCALIZACION DE FALLOS Y AVERIAS SÍNTOMAS COMPROBACIONES SOLUCIONES 1)Asegúrese de que la máquina está 1)Enchufe el cable a la red. 1. No se enciende el enchufada a la red, el interruptor general en Coloque el interruptor en posición monitor posición 1 y la llave de seguridad puesta.
  • Page 11 G-690 / G-690TV LINE sportkoncept (GB) Fig 1 A)- Monitor. a) - Screw M-10x70 Quantity 8 B)- Main body. b) - Screw M-5x10 Quantity 14 C)- Handrail Handlebar. c) - Nut M8 Quantity 4 Left-hand focus bar. d) - Screw M-4x10 Quantity 2 Right-hand focus bar.
  • Page 12: Safety Instructions

    G-690 / G-690TV LINE sportkoncept ENGLISH manual. Do not use accessories that are not SAFETY INSTRUCTIONS recommended by the manufacturer, as these may cause injuries. PRECAUTIONS This bicycle has been designed and constructed to -The SK can only be used by one person at a provide maximum safety.
  • Page 13 G-690 / G-690TV LINE sportkoncept Should this occur: -Do not overexert yourself or exercise beyond 1.- Set switch (L), located on the casing, to the “0” your capabilities. Stop exercising immediately if you (OFF) position Fig B. are in pain or feel strange, and seek professional 2.- Press the circuit button (C) to reset the unit.
  • Page 14: Maintenance

    G-690 / G-690TV LINE sportkoncept ATTACHING MONITOR NOTE: To prevent accidents DO NOT move the SUPPORT PLATE.- treadmill across uneven floors. Take the monitor support plate (Q), passing the cables through the central hole (O). Use the MAINTENANCE holding screws (b) to attach it to the handrail Use the bottle of lubricant (h) to lubricate the inside handlebar.
  • Page 15: Exercise Program

    G-690 / G-690TV LINE sportkoncept screw (R) in a clockwise direction has the same physiotherapy, always remember that your effect on the position of the belt as one turn of the exercise should be gradual, planned, varied and left screw (L) in an anticlockwise direction. not too demanding.
  • Page 16: Fault Finding Chart

    G-690 / G-690TV LINE sportkoncept FAULT FINDING CHART PROBLEM CHECKS SOLUTIONS 1) Make sure that the machine is 1) Plug the machine into the 1. The monitor does plugged in, the ON/OFF switch in mains supply. not switch on. position I and that the safety key is Set the switch to position I and inserted.
  • Page 17 G-690 / G-690TV LINE sportkoncept (F) Fig 1 A)- Moniteur. a) - Vis de M-10x70 Nombre 8 B)- Corps principal. b) - Vis de M-5x10 Nombre 14 C)- Guidon appuie-mains. c) - Écrou de M8 Nombre 4 D)- Main courante gauche. d) - Vis de M-4x10 Nombre 2 D)- Main courante droite.
  • Page 18: Consignes De Sécurité

    G-690 / G-690TV LINE sportkoncept FRANÇAIS utilisation et assurez-vous que la selle est en bon CONSIGNES DE SÉCURITÉ état. PRÉCAUTIONS L’appareil doit être conservé dans d’excellentes Cet appareil d’exercice a été conçu et fabriqué de conditions d’utilisation. façon à ce qu’il puisse offrir une sécurité maximale. Néanmoins, l’utilisateur est tenu de prendre - Le modèle SK ne doit être utilisé...
  • Page 19: Montage

    G-690 / G-690TV LINE sportkoncept débrancher l’appareil. - Portez des vêtements et des chaussures appropriés pour l’exercice. Ne portez pas de - Tenir le cordon de branchement à l’écart des vêtements amples. Si vous portez des cheveux longs, attachez-les. surfaces chaudes. - Ne pas utiliser l’appareil dans des lieux où...
  • Page 20: Entretien

    G-690 / G-690TV LINE sportkoncept moniteur; (B) Corps principal; (C) Guidon appuie- MISE EN PLACE DU MONITEUR mains; D) Main courante gauche; (E) Main Prenez moniteur connectez courante droite ; (F) Couvercle arrière du moniteur; connecteurs Fig.4 (Mod.G-690 Tv TV) k; m; o; qui (G) Bouteille;...
  • Page 21 G-690 / G-690TV LINE sportkoncept Après avoir lubrifié, si le tapis est glissant, vérifiez importantes du tapis. la tension. Pour tendre le tapis, Fig.7, prenez la clé Allen (m) et avec la machine fonctionnant à 4 MODE D’EMPLOI km/h, vissez d’un tour les vis (R et L) dans le sens des aiguilles d’une montre.
  • Page 22 G-690 / G-690TV LINE sportkoncept de se sentir mieux, avec plus de force et de résistance à la tension. Vous pourrez constater PROGRAMME D’EXERCICE vous-même qu’il est intéressant de rester en forme Avant de commencer tout programme d’exercice et avec BH. étant donné...
  • Page 23 G-690 / G-690TV LINE sportkoncept DÉFAILLANCES OU PANNES SYMPTÔMES VÉRIFICATIONS SOLUTIONS 1) Vérifiez si la machine est branchée au 1) Branchez le câble à la prise 1. Le moniteur ne courant électrique, si l’interrupteur général se de courant. s’allume pas. trouve sur la position 1 et si la clé...
  • Page 24 G-690 / G-690TV LINE sportkoncept (D) Fig 1 A)- Monitor. a) - Schraube M-10x70 Menge 8 B)- Hauptrahmen. b) - Schraube M-5x10 Menge 14 C)- Lenkstange Handauflage. c) - Mutter M8 Menge 4 D)- Linke Handstange. d) - Schraube M-4x10 Menge 2 E)- Rechte Handstange.
  • Page 25: Allgemeine Hinweise

    G-690 / G-690TV LINE sportkoncept Deutsch Möbel auf. Vor jeder Benutzung ist das Gerät zu SICHERHEITSHINWEISE überprüfen und sicherzustellen, dass das Band in einwandfreiem Zustand sind. Vorsichtsmaßnahmen Dieses Trainingsgerät wurde so entwickelt und Sorgen Sie dafür, dass sich das Gerät stets in konstruiert, dass er maximale Sicherheit bietet.
  • Page 26 G-690 / G-690TV LINE sportkoncept - Tragen Sie geeignete Kleidung und Schuhwerk für die Übungen. Benutzen Sie keine weite - Ziehen Sie den Stecker nicht am Kabel aus der Kleidung. Lange Haare sollten zusammen- Steckdose. gebunden werden. - Achten Sie darauf, dass das Kabel nicht mit - Handhaben Sie den Rahmen des Geräts nicht heißen Flächen in Berührung kommt.
  • Page 27 G-690 / G-690TV LINE sportkoncept durch das Innere der Handauflage und ziehen Sie MONTAGEHINWEISE sie aus der mittleren Öffnung (O) (Abb. 3). Nehmen Sie das Gerät aus der Kiste und stellen Anschlieβend führen Sie die Klemme (P), die aus Sie es auf den Boden (vgl. Abb. 1). dem oberen Teil des rechten Handlaufs (E) ACHTUNG: Es ist ratsam, dass die Montage von herauskommt, durch das Innere der Handauflage...
  • Page 28: Wartung

    G-690 / G-690TV LINE sportkoncept Seite Geräts Umdrehung WARTUNG Uhrzeigersinn. Prüfen Sie dann die Position des Zur optimalen Wartung Ihres Geräts und zur Bandes. Wenn diese nach einer Minute nicht Reduzierung der Reibungen zwischen Laufband vollkommen zentriert ist, wiederholen Sie die und Brett schmieren Sie den Innenteil (Abb.
  • Page 29 G-690 / G-690TV LINE sportkoncept konsumieren, verlieren wir an Körpergewicht. Im werden. Ruhezustand verbrennt unser Körper rund 70 Abschließend ist es wichtig, die Muskeln zu Kalorien pro Stunde, um die Lebensfunktionen entspannen. Dazu ist es ausreichend, 2-3 Minuten aufrecht zu erhalten. Die Tabelle zeigt den bei geringer Geschwindigkeit zu laufen, bis der Energieverbrauch einer durchschnittlichen Person Pulsschlag auf 65% absinkt.
  • Page 30 G-690 / G-690TV LINE sportkoncept AUFFINDEN VON FEHLERN UND PROBLEMEN SYMPTOME MASSNAHMEN LÖSUNGEN 1) Vergewissern Sie sich, dass das 1) Stecken Sie das Kabel in die 1. Der Monitor schaltet Gerät ans Netz geschlossen ist und der Steckdose. nicht ein Hauptschalter auf Position 1 steht.
  • Page 31 G-690 / G-690TV LINE sportkoncept (P) Fig 1 A)- Monitor. a) - Parafuso de M-10x70 Quantidade 8 B)- Corpo principal. b) - Parafuso de M-5x10 Quantidade 14 C)- Volante com apoio de mãos. c) - Porca de M8 Quantidade 4 D)- Grade Esquerda.
  • Page 32: Indicações De Segurança

    G-690 / G-690TV LINE sportkoncept PORTUGUÊS - Só deverá utilizar o modelo SK segundo a forma INDICAÇÕES DE SEGURANÇA indicada neste manual. Não utilize acessórios anexos que não tenham sido recomendados pelo PRECAUÇÕES fabricante; estes acessórios poderão causar-lhe Este aparelho de exercício foi desenhado e danos.
  • Page 33: Instruções De Montagem

    G-690 / G-690TV LINE sportkoncept - Nunca lance nem introduza nenhum objecto - Não deverá utilizar a máquina ao ar livre. em nenhuma das aberturas da máquina. Mantenha as toalhas e as mãos afastadas das partes móveis. -Não realize tarefas de manutenção e/ou reparação para além das indicadas neste manual.
  • Page 34 G-690 / G-690TV LINE sportkoncept (l) Comando à distância (Mod. G-690 Tv); (m) COLOCAÇÃO CHAPA TRASEIRA Chave de Allen. DO MONITOR. Posicione a tampa traseira do monitor (F). Aperte Siga cada um dos passos descritos nesta os parafusos (e). montagem. NIVELAÇÃO.
  • Page 35 G-690 / G-690TV LINE sportkoncept sofrer alguma deslocação lateral. VANTAGENS DE PRATICAR EXERCÍCIO Se a banda se desvia para a direita o para a Um exercício regular por baixo de um certo nível e esquerda, pare a unidade. de uma duração de 15/20 minutos, é aeróbio. O exercício aeróbio é...
  • Page 36 G-690 / G-690TV LINE sportkoncept Antes de começar uma sessão é importante INSPECÇÕES E MANUTENÇÃO realizar um aquecimento de uns 2-3 minutos com Apague a unidade e desligue o cabo da rede uma velocidade suave. Isto protegerá os seus eléctrica. músculos e preparará...
  • Page 37 G-690 / G-690TV LINE sportkoncept LOCALIZAÇÃO DE FALHAS OU DE AVARIAS SINTOMAS COMPROVAÇÕES SOLUÇÕES Verifique se a máquina está ligada à 1) Ligue o cabo à rede. 1. O monitor não rede, se o interruptor geral está na posição 1 Coloque o interruptor na po- acende e se a chave de segurança está...
  • Page 38 G-690 / G-690TV LINE sportkoncept (I) Fig 1 A)- Monitor. a)-.Vite di M-10x70 Quantità ..8 B)- Corpo principale. b)- Vite di M 5x10 Quantità 14 C)- Manubrio Appoggiamani. c)- Dado di M8 Quantità.. 4 D)- Corrimano Sinistro. d)- Vite di M-10x70 Quantità...
  • Page 39: Consigli Di Sicurezza

    G-690 / G-690TV LINE sportkoncept ITALIANO -Mantenga l’ apparecchio in ottime condizioni d’ CONSIGLI DI SICUREZZA uso. AVVERTENZA - Usi il modello SK solamente come viene indicato Questa macchina per gli esercizi è stato progettato in questo manuale. Non introduca accessori che e costruito in modo tale da proporzionare la non siano stati raccomandati dal fabbricante, questi massima sicurezza.Nonostante ciò, è...
  • Page 40: Istruzioni Di Montaggio

    G-690 / G-690TV LINE sportkoncept - Non forzi la struttura della macchina. Non si - Mantenga il cordone della spina lontano da appoggi sulla mensola del monitor elettronico ne superfici calde. sulle carcasse della macchina. -Non utilizzare la macchina in luoghi in cui si fa - Non lanci ne inserisca mai nessun oggetto in uso di aerosoli.
  • Page 41: Manutenzione

    G-690 / G-690TV LINE sportkoncept (a) Vite di M-10x70; (b) Vite M-5x10; (c) dado di LIVELLAMENTO. M8; (d) Vite M-4x10; (e) Vite M-4x12; (f) Una volta collocata la cinta per correre nella zona Interruttore; (g) Chiave a croce; (h) Contenitore definitiva, per la realizzazione degli esercizi, lubrificante;...
  • Page 42 G-690 / G-690TV LINE sportkoncept Se il nastro si inclina verso destra o verso sinistra, VANTAGGI DELL’ fermi l’ apparecchio. ALLENAMENTO FISICO Un allenamento regolare al di sotto di un certo SPOSTAMENTO DEL NASTRO VERSO livello e con una durata di 15/20 minuti, si DESTRA trasforma in aerobico.
  • Page 43 G-690 / G-690TV LINE sportkoncept minuti velocità moderata. Questo ISPEZIONI E MANUTENZIONE proteggerà suoi muscoli preparerà Spenga l’ apparecchio e stacchi il cavo dalla rete adeguatamente il suo sistema cardio respiratorio. elettrica. El passo seguente sarà durante 15-20 minuti ad Pulisca la polvere dalle superfici del tapis roulant un ritmo che porti le pulsazioni del battito cardiaco con un panno od un asciugamano umido,...
  • Page 44 G-690 / G-690TV LINE sportkoncept LOCALIZZAZIONI DI GUASTI O DANNI SINTOMI VERIFICHE SOLUZIONI 1)Si assicuri che l’ apparecchio sia collegato 1)Colleghi il cavo alla rete 1. Non si accende il alla rete elettrica, l’ interruttore generale si trovi elettrica. monitor in posizione 1 e la chiave di sicurezza sia 2)Collochi l’...
  • Page 45 G-690 / G-690TV LINE sportkoncept (NL) Fig 1 A)- Monitor. a) – Schroef M-10x70 8 stuks B)- Hoofdframe. b) – Schroef M-5x10 14 stuks C)- Stuurhandgreep. c) - Moer M8 4 stuks Linkerfocusbalk. d) – Schroef M-4x10 2 stuks Rechterfocusbalk. e) –...
  • Page 46: Algemene Instructies

    G-690 / G-690TV LINE sportkoncept Nederlands - Installeer en gebruik de SK op een effen en VEILIGHEIDSINSTRUCTIES stabiel oppervlak. Plaats het toestel niet in de buurt van muren of meubilair. Controleer het apparaat VOORZORGSMAATREGELEN voor elk gebruik en ga na of de band in goede staat Deze fiets is ontworpen en gebouwd om maximale veiligheid te waarborgen.
  • Page 47: Montage Instructies

    G-690 / G-690TV LINE sportkoncept - Zet de machine nooit aan wanneer er zich iemand op bevindt. - Breng het elektrisch snoer niet in de buurt van warme oppervlaktes. -Draag gepaste kledij schoeisel voor - Gebruik het toestel niet op plaatsen waar er lichaamsbeweging.
  • Page 48 G-690 / G-690TV LINE sportkoncept Hoofdframe; Stuurhandgreep; en o, Fig.4,( Mod. G-690 Tv TV ) die uit de monitor Linkerfocusbalk; Rechterfocusbalk; komen, met aansluitstukken l, n en p, die uit de Achterkantbedekking van monitor; (G) Fles; (a) stuurhandgreep komen. Duw alle verbindingen van Schroef M-10x70;...
  • Page 49 G-690 / G-690TV LINE sportkoncept grote spanning van de band te voorkomen. Als de band na smering begint te slippen, GEBRUIKSAANWIJZINGEN controleert u de spanning van de band. Om de band op spanning te brengen, Fig.7, neemt u de LICHAMELIJKE CONDITIE stiftsleutel (m) en terwijl het apparaat is ingesteld Over een goede lichamelijke conditie beschikken is op 4km/uur, draait u de schroeven (R &...
  • Page 50 G-690 / G-690TV LINE sportkoncept maximale hartslagfrequentie bereikt, welke men OEFENPROGRAMMA niet mag overschrijden overeenkomstig de leeftijd. Voordat u begint met welk trainingsprogramma dan Aan het einde van iedere oefening is het belangrijk ook en aangezien trainingsprogramma’s variëren de spieren tot rust te laten komen. Hiervoor kunt u naar gelang leeftijd en lichamelijke conditie, is het volstaan door, gedurende 2-3 minuten, met een raadzaam eerst uw arts te raadplegen, omdat deze...
  • Page 51 G-690 / G-690TV LINE sportkoncept STORINGS- EN FOUTMELDINGEN SYMPTOMEN CONTROLE HANDELINGEN OPLOSSINGEN 1) Controleer of het apparaat is aangesloten 1) Sluit aan op het lichtnet. 1. De monitor schakelt op het lichtnet, de hoofdschakelaar op stand 2) Zet de hoofdschakelaar op niet in 1 staat en de veiligheidssleutel correct stand 1 en plaats de veilig-...
  • Page 52 G-690 / G-690TV LINE sportkoncept G-690...
  • Page 53 G-690 / G-690TV LINE sportkoncept G-690 Tv...
  • Page 54 G-690 / G-690TV LINE sportkoncept Para pedido de repuesto: Indicar el modelo de la máquina Nº correspondiente a la pieza Cantidad To order replacement parts: State the machine model Corresponding parts nº Quantity Pour toute commande pièces détachées Indiquer le modèle de la machine Numéro de la píese Quantité...
  • Page 55 G-690 / G-690TV LINE sportkoncept BH HIPOWER SPAIN EXERCYCLE,S.A. (Manufacturer) P.O.BOX 195 01080 VITORIA (SPAIN) Tel.: +34 945 29 02 58 Fax: +34 945 29 00 49 e-mail: hipower@bhfitness.es www.bhfitness.com BH HIPOWER PORTUGAL BH HIPOWER FRANCE BH HIPOWER UK MAQUINASPORT, S.A. Tel.: +33 (0)1429 61885 Unit 1A Brittania Business Park Zona Industrial Giesteira...
