Internet Radio Adaptor with

DAB and Bluetooth

DAB20C

User Manual

(Additional powered speaker/

active speaker is required to use this product)

Please read this user manual carefully before using the receiver.

Table of Contents

Summary of Contents for Wintal DAB20C

Page 1 Internet Radio Adaptor with DAB and Bluetooth DAB20C User Manual (Additional powered speaker/ active speaker is required to use this product) Please read this user manual carefully before using the receiver.
Page 3: Table Of Contents
Contents Location of Controls ...........1 Remote Control ..........2 Remote control character list .......3 Getting started ...........6 Connecting to your WiFi network ......7 Internet Radio ............9 Media Center ...........12 FM mode ............14 DAB Mode ............15 Information Center ...........16 DLNA ...............17 Bluetooth ............17 Conﬁguration ...........18 Trouble Shooting ..........29 Technical Speciﬁcation ........33...
Page 4: Location Of Controls
Location of Controls 1. 2.8'' TFT color screen 2. Infrared remote sensor 3. 3.5mm antenna input socket Two types of antenna are supplied with the radio. One is wire type and the other is the rod antenna. Apply one of them to get the best result on the reception of DAB and FM radio 4.
Page 5: Remote Control
Remote control : Mute : Standby button 3. 0-9: Favorite station key / input letters and numbers for WiFi Encryption code : Preset the current playing station to Favorite : Recall the favorite list 6. ▲: Cursor up 7. t : Cursor left / back to previous menu 8.
Page 6: Remote Control Character List
Remote control character list Key“0”―― 0,‘DEL’ Key“1”―― ‘1’->‘@’->‘ ’(space)->‘！’-> “ (double quotes) ->‘#’->‘$’->‘%’->‘&’-> ’（single quotes）->‘(’ ->‘)’->‘*’->‘+’->‘， ’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’- >‘=’->‘>’->‘?’- >‘[’->‘\’->‘]’->‘^’->‘_’->‘`’->‘{’->‘|’->‘}’->‘~’ Key “2”―― 2,A,B,C,a,b,c Key“3”―― 3,D,E,F,d,e,f Key“4”―― 4,G,H,I,g,h,i Key“5”―― 5,J,K,L,j,k,l Key“6”―― 6,M,N,O,m,n,o Key“7”―― 7,P,Q,R,S,p,q,r,s Key“8”―― 8,T,U,V,t,u,v Key“9”―― 9,W,X,Y,Z,w,x,y,z To enter the password, press " ▲ " or " ▼ " button to select the characters.
Page 7 Before you start Please ensure the following is ready: • You have a broadband internet connection. • A wireless (Wi-Fi) broadband router is connected to the internet successfully. The radio supports Wireless B, G and N connection (Wireless N router can also be used with the setting on B or G).
Page 8 Warning - 05 -...
Page 9: Getting Started
Getting started Connect the mains adaptor to the radio unit, one end to the DC IN on the radio and the other end to the mains wall outlet. Caution: Use only the mains adaptor supplied with the radio. Connecting a power supply with a different rating will cause permanent damage to the radio and may be hazardous.
Page 10: Connecting To Your Wifi Network
Connecting to your WiFi network The following screen will appear. You can choose <Yes> to proceed to search for the available WiFi network. If your router has the WPS function, you can select <Yes(WPS)> to proceed. 01:01 Would you like to configure Network now? Yes(WPS) It will then start scanning the network.
Page 11 Connecting to your WiFi network The radio will start connecting to the network. After the wiﬁ network is connected successfully, it will display the main menu as follow: 08:58 Internet Radio You can now start enjoying the internet radio. - 08 -...
Page 12: Internet Radio
Internet Radio Choose <Internet Radio> from the menu, you can see different functions as below: To start listening the radio stations worldwide, select <Radio Station/Music>. My Favorite This is to show the list of your Favorite stations which have been assigned to the presets. To preset a station: While you are playing the favorite station, simply hold and press the...
Page 13 Internet Radio You can edit your favorite list anytime. Go to Internet radio> My Favourite or press the on the remote, When it displays the list of favorite stations then press the ► button. The following options will display: iRadio Delete Shift Up Shift Down...
Page 14 Internet Radio History The radio will memorize the last listened 10 stations. Service Search Stations You can ﬁnd your desire radio station by entering the name of the radio. Add New Radio Station If you cannot ﬁnd your desire station from the Radio station list and you have the URL address, you can input the link here and add to your favorite list.
Page 15: Media Center
Media Center UPnP (Universal Plug and Play) The device supports UPnP and is DLNA-compatible. This provides the opportunity to stream music from your other network devices. However, this requires you to have a compatible device in your network that can function as a server.
Page 16 Media Center 3. It may take a few seconds for the radio to complete the scan for available UPnP servers. If no UPnP servers are found, it will show [Empty List]. 4. After a successful scan is done, select your UPnP server.
Page 17: Fm Mode
FM Mode You can listen to the ordinary FM radios without wiﬁ connection. Take out the wire antenna supplied in the package, plug it into the antenna socket on the rear side of the adaptor, extend it perpendicular to the radio unit or in other direction / length of the antenna may be required to optimize the reception level.
Page 18: Dab Mode
DAB Mode You can listen to ordinary DAB channels without wiﬁ connection. Take out the wire antenna supplied in the package, plug it into the antenna socket on the rear side of the adaptor, extend it perpendicular to the radio unit or in other direction / length of the antenna may be required to optimize the reception level.
Page 19: Information Center
Information Center Weather The radio provides weather information and can display in Standby mode. To enable this feature, follow the steps below: Go to main menu, choose Information Center> Weather Information, choose the region you want it to display the weather information.
Page 20: Dlna
Once it enters into Bluetooth mode, it will be discoverable from other Bluetooth devices. 1. Turn on Bluetooth on the Bluetooth device and look up the device named “DAB20C” from the list. Select it to start pairing. 2. If the connection is successful, it will show “Connected”...
Page 21: Configuration
Conﬁguration Time Display You can choose the time display at Analog or Digital. Manage my mediaU You can tailor made your own favorite station list using your computer. 1) Go to http://www.mediayou.net/ and sign up to become a member. 2) Then you have to ﬁnd out the Mac Address to register on the Media U website.
Page 22 Conﬁguration You can then organize your own favorite stations or add any new station which is currently not found on the station list. Once the changes are done, your radio will synchronize the changes immediately and you will ﬁnd your favorite list under <My MediaU> on the radio menu. Note: If you are going to add URL which is not on Media U database, ensure the URL is an audio streaming URL or contact Media U to add it for you.
Page 23 Conﬁguration It allows maximum 5 users to register with the same radio and you can switch to listen the favorite list under one user at a time. To ﬁnd your added station / custom favorite list on the radio, go to Conﬁguration > Manage my mediaU > Enable.
Page 24 Conﬁguration Important: Whenever any update is done on your <My Media U> account, you have to disable the My Media U and enable it again to refresh and get the latest updated list. (Conﬁguration> Manage my mediaU > Disable > Enable) Network Wireless Network Conﬁguration...
Page 25 Conﬁguration If manual setup is selected, you will see an added item Daylight Saving Time (DST) setting appeared on the list. Alarm Dual alarm clock There are 2 alarm clocks available and settings as follow: Scheduling alarm: You can schedule the alarm repeated for every day, particular day in the week or just once.
Page 26 Conﬁguration Timer The Timer can be set for 99:59. Use “ ◄ ” “ ► ” or “ ▲ ” “ ▼ ” to adjust the time you desire. Press <OK> to start the timer. Whenever you want to pause, press <OK> and to resume it, press it again.
Page 27 Conﬁguration Power Management This function is to allow the radio to go to Standby if there is no internet signal received in order to save power. The default setting is 30 minutes. When the radio does not receive any internet signal, the radio will go into Standby after 30 minutes.
Page 28 Conﬁguration DAB/FM Setup FM Mode Option to choose hearing in Stereo or mono. Note: As the radio is a mono, this option does not apply. FM Threshold Option to adjust the scanning threshold to pick up stronger or weaker FM stations. There are two types of threshold, Seek Threshold and Stereo Threshold.
Page 29 Conﬁguration usually caused by interference or weak reception over You can choose to enable or disable this feature. After the scan is done on FM or DAB, choose a channel to play. If the same channel is available on Internet, there will be an icon appeared as follow: ABC dig Now playing: Don’t...
Page 30 Conﬁguration Device DLNA Setup The radio can play music from DLNA compatible devices which connected to the same wiﬁ network as the radio. The radio will be discovered by the DLNA devices with the name as “AirMusic”. This is the name by default.
Page 31 Conﬁguration Equalizer Select your prefer equalizer to suit your listening preference. Resume When Power On The radio will resume playing the last listened station when you power it on next time if ON is selected in this option. The ON is set by default. Software update Upgrade information will pop up on the display when there is update version available.
Page 32: Trouble Shooting
Trouble Shooting 1. If you have trouble connecting the radio to your wireless network, these steps may help to resolve the problem: - Conﬁrm that a Wi-Fi or Ethernet Wired connected PC can access the internet (i.e. can browse the web) using the same network.
Page 33 Trouble Shooting 2. If your radio can connect to the network successfully, but is unable to play particular stations, it may be due to one of the following reasons: - The station is not broadcasting at this time of the day (remember it may be located in a different time zone).
Page 34 Trouble Shooting you accessing shared ﬁles. - If you have a third party ﬁrewall (Like Norton, or Zone Alarm) that will have its own control panel and you will need to consult the manual for your ﬁrewall. - If your PC is connected to a managed network, with a server sometimes the PC being searched for needs to be set to Home group.
Page 35 Trouble Shooting 6. What is Buffering? When playing a stream, the Internet Radio/Media player, downloads a small amount of the stream before it starts playing. This is used to ﬁll in any gaps in the stream that may occur if the internet or the wireless network is busy. If a stream gets blocked or experiences Internet congestion while transferring it may stop/interfere with the quality of play.
Page 36: Technical Specification
171 x 55 x 105 mm (L x D x H) Unit Dimension Remark: Speciﬁcation may vary without notice In the box * DAB20C radio * Power adapter * Remote control(without batteries) * Antenna lead * 3.5 mm to RCA lead...
Page 37 WEEE and Recycling The European laws do not allow any more the disposal of old or defective electric or electronic devices with the household waste. Return your product to a municipal collection point for recycling to dispose of it. This system is financed by the industry and ensures environmentally responsible disposal and the recycling of valuable raw materials.
